Accessories included - Charger Mounting plate Mounting screws
Antenna - Built-in
Antenna - Antenna features - Integrated antenna
Antenna - Antenna gain level (max) - 4 dBi
Antenna - Antennas quantity - 3
Antenna - Antenna type - Internal
Antenna gain - 4 dBi
ARTIKEL1 - NWA90AX PRO 802.11AX
ARTIKEL2 - WIFI 6 NEBULAFLEX ACCESSPOINT
Brand - Zyxel
BrandPartCode - NWA90AXPRO-EU0102F
Breite - 0
Category - Root/Electronics/Networks and communication/Access points
Category - Wireless Access Points
Category 1 - Netzwerk
Category 2 - Accesspoints
Certificates - Radio: FCC Part 15C FCC Part 15E ETSI EN 300 328 EN 301 893 LP0002 EN 60601-1-2 EMC: FCC Part 15B EN 301 489-1 EN 301 489-17 EN55022 EN55024 EN61000-3-2/-3 BSMI CNS13438 Security: Safety EN 60950-1 IEC 60950-1 BSMI CNS14336-1
Certification - FCC Part 15C, FCC Part 15E; ETSI EN 300 328, EN 301 893;
LP0002, EN 60601-1-2, FCC Part 15B, EN 301 489-1;
EN 301 489-17, EN55022, EN55024, EN61000-3-2/-3, BSMI CNS13438, EN 60950-1, IEC 60950-1; BSMI CNS14336-1
Color - White
Connections - Ethernet (RJ-45)
Connections - Power Port
Description - 802.11ax (Wi-Fi 6) Dual-Radio PoE Access Point NWA90AX PRO Multi-gig Wi-Fi 6 access point for small businesses. Offering AX3000 Wi-Fi speeds with a 2.5G Ethernet uplink port, the Zyxel NWA90AX Pro delivers powerful and fastest Wi-Fi 6 speeds for small businesses, SoHo and home offices. Small business owners looking for an affordable Wi-Fi 6 access point with multi-gig connectivity, Zyxel NWA90AX Pro is undoubtedly the perfect choice for them to support more connected devices and applications at the fastest speeds. AP AX3000 (3x3:2 in 5Ghz; 2x2:2 in 2.4Ghz) provides a maximum data transfer rate of 3000Mbps, and the 2.5G uplink port enables multi-gig connectivity for small business networks. Get multi-gigabit performance with a 2.5 Gbps PoE port to handle your most demanding wireless requirements. The Multi-gig Connection Stabilizer Pad secures the connection between the Cat 5E cable and the RJ45 connector to provide a 2.5G connection for maximum throughput. Captive Portal and support for IEEE 802.1X authentication provide enterprise-grade security. Easy self-installation/configuration with the right feature set, perfect for small businesses and SOHO. NebulaFlex allows users to switch between standalone mode or intuitive Nebula cloud management depending on their needs. Boost your Wi-Fi performance To better take advantage of faster speeds in the 5Ghz band, Zyxel NWA90AX Pro is equipped with 3x high-gain antennas to amplify Wi-Fi signals and extend coverage, especially to previously hard-to-reach areas. In addition to Wi-Fi signal amplification, the NWA90AX Pro also features high-quality multi-gig Ethernet connections. Because it can run on regular Cat5e cabling, the 2.5G uplink port breaks the 1.0G bottleneck without the need for re-cabling, making it easy to create an affordable, high-speed networking environment for your business or home. Secure authentication to protect business networks With captive portal support and IEEE802.1x authentication, NWA90AX Pro not only offers small business users enterprise-level security to protect their networks, but also the flexibility to customize wireless usage logging for marketing and business recognition. Configure your wireless network in minutes! No specialized networking knowledge required - NWA90AX Pro is designed to be easily configured and installed in places such as small hotels, retail stores, restaurants and home offices. Simple configuration allows you to set up a network for customers and employees in minutes. The AP can be managed both via the Nebula Cloud network platform and the local device interface. Easy deployment with Zyxel's Smart Mesh Zyxel's Smart Mesh technology automatically creates dynamic wireless connections between access points and alleviates complicated, cumbersome cabling when deploying Wi-Fi. Smart Mesh technology can save you additional cabling by enabling wireless connectivity between access points for extended coverage and flexible deployment. Manage your way! NWA90AX Pro with NebulaFlex offers flexible management capabilities, so you can freely choose between the device's local web interface or Nebula's easy cloud management interface. Nebula cloud management interface so you never have to worry about forgetting your IP address or losing your account and passwords when managing in the cloud. Anytime and anywhere thanks - Nebula Mobile App Easily enable devices with QR code scanning and installation wizard Network and device status at a glance Wi-Fi sharing via QR code or mobile messaging apps Access control of network clients Live troubleshooting tools Push notifications about unusual network events Resellers, managed service providers (MSPs) and network administrators will find simplicity, scalability, flexibility, IT risk reduction and cost savings in Zyxel's cloud network management platform, Nebula, which is a single-vendor solution. Nebula offers efficient, effortless and scalable network connectivity that works together to remove the complexity and security risks often associated with a multi-vendor networking approach. Connect, protect and manage security, switches, wireless and LTE/5G with our centralized cloud platform, Nebula. Serving customers with over 80 Nebula-enabled devices through an ever-growing portfolio, Zyxel is unrivaled in its approach to introducing new and existing products through NebulaFlex. Since implementationfrom the home office to ensuring connectivity in distributed network setups, Zyxel's Nebula-enabled product portfolio can meet all types of budgets, functionality and scalability both now and in the future.
Description - ZYXEL NWA90AXPRO, STANDALONE / NEBULAFLEX WIRELESS ACCESS POINT, SINGLE PACK INCLUDE POWER ADAPTOR, EU AND UK, ROHS
Design - LED indicators - Yes
Design - Placement - Ceiling
Design - Product colour - White
dimensionalWeight - 437
dimension depth - 50 mm
dimension height - 150 mm
Dimensions - 140 x 140 x 37,5 mm
Dimensions W x D x H, mm - 140 x 140 x 37.5
dimension weight - 683 g
dimension width - 230 mm
ean - 4718937630592
EANCode - 4718937630592
Eans - 4718937630592
Environment requirements - Operating temperature: 0°C to 50°C/32°F to 122°F Operating humidity: 10% to 90% (non-condensing) Storage temperature: -40°C to 70°C/-40°F to 158°F Storage humidity: 10% to 90% (non-condensing)
Ethernet LAN (RJ-45) ports quantity - 1
Features - 2.4 GHz - Yes
Features - 5 GHz - Yes
Features - 6 GHz - No
Features - Ethernet LAN data rates - 1000 Mbit/s
Features - Ethernet LAN data rates - 1000,2500 Mbit/s
Features - Ethernet LAN data rates - 2500 Mbit/s
Features - Maximum data transfer rate - 2400 Mbit/s
Features - Maximum data transfer rate (2.4 GHz) - 575 Mbit/s
Features - Maximum data transfer rate (5 GHz) - 2400 Mbit/s
Features - MIMO - Yes
Features - MIMO type - Multi User MIMO
Features - Networking standards - IEEE 802.11a
Features - Networking standards - IEEE 802.11ac
Features - Networking standards - IEEE 802.11ax
Features - Networking standards - IEEE 802.11b
Features - Networking standards - IEEE 802.11g
Features - Networking standards - IEEE 802.11n
Features - Networking standards - IEEE 802.11n, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g
Features - VLAN support - Yes
Features - Wi-Fi Multimedia (WMM)/(WME) - Yes
Frequency range, GHz - 2.4/5
Gewicht - 0
GRUPPE1 - Network
GRUPPE2 - Wireless Lan Ap
GTIN - 4718937630592
guarantee - 24
guarantee_type - external
Height - 60.000000
HERSTELLER - ZYXEL
Hoehe - 0
HSTNUMMER - NWA90AXPRO-EU0102F
I/O ports - 1 x 10/100/1000/2500 RJ-45 port
Laenge - 0
Length - 235.000000
LongDesc - Multi-gig WiFi 6 access point for small businessesZyxel NWA90AX ProAX3000 Dual-Radio Multi-gig PoE Access Point with secure authentication supportMulti-gig WiFi 6 access point for small businessesDelivering AX3000 WiFi speed with 2.5G Ethernet uplink port, the Zyxel NWA90AX Pro provides the powerful and fastest WiFi 6 speed for small businesses, SoHo, and home offices.Small business owners looking for an affordable WiFi 6 access point with multi-gig connectivity, Zyxel’s NWA90AX Pro is no doubt the ideal choice for them to support more connected devices and applications with the fastest speeds.Boost your WiFi performanceTo better leverage the faster speeds in 5Ghz band, Zyxel NWA90AX Pro equips with 3x high-gain antennas to boost WiFi signals and extend coverage, especially to previously hard-to-reach areas.In addition to the WiFi boost, NWA90AX Pro also comes with the premium multi-gig Ethernet connections. As it can run on the common-type Cat5e cabling, a 2.5G uplink port breaks through the 1.0G bottleneck without re-cabling, making it easy to create an affordable high-speed network environment for your business or home.Secure authentication to protect business networksWith the support of captive portal and IEEE802.1x authentication, the NWA90AX Pro not only offers small business users the enterprise-level security to protect their networks, but also the flexible opportunity to customize wireless network usage login for marketing and business recognition.Set up your wireless network in minutes!No networking expertise required - The NWA90AX Pro is designed to be easily configured and installed in places like small hotels, retail stores, restaurants, or home offices.The simple configuration allows you to set up the network for your customers and employees in minutes. The AP can be managed either with Nebula Cloud networking platform or the device’s local interface.Easy deployment with Zyxel’s Smart MeshZyxel’s Smart Mesh technology automatically forms dynamic wireless links between access points and mitigates the complex, inconvenient cabling for WiFi deployment.The Smart Mesh technology can save you from extra wiring by enabling the wireless connectivity between APs for extended range and flexible deployment.Manage it your way!The NWA90AX Pro with NebulaFlex offers the flexible manageability for you to freely choose between the device’s local web interface or onboarding to our super easy Nebula cloud management interface that you never need to worry about forgetting the IP address or lost account and password when managing it on cloud.
LongProductName - NWA90AXPRO, 2.5GB LAN Port, 2x2:3x3 MU-MIMO, Standalone / NebulaFlex Wireless Access Point, Single Pack include Power Adaptor, EU and UK, ROHS
LongSummaryDescription - Zyxel NWA90AX PRO. 2.4 GHz, 5 GHz, Maximum data transfer rate: 2400 Mbit/s. Security algorithms: 802.1x RADIUS, EAP, WEP, WPA, WPA2, WPA2-Enterprise, WPA2-PSK, WPA3. Ethernet LAN data rates: 1000,2500 Mbit/s. Power over Ethernet (PoE). Product colour: White
Management, monitoring, configuration - Web UI/CLI Operation mode: Nebula cloud management Independent ZON Utility: Discovery of Zyxel switches, access points and gateways Centralized and batch configurations: IP configuration IP renewal Restart your device Locating devices Access to Web GUI Firmware update Password configuration
Management features - Firmware upgradeable - Yes
Management features - Web-based management - Yes
Manufacturer - Zyxel
Manufacturer - ZYXEL COMMUNICATIONS A/S
ManufacturerPartNumber - NWA90AXPRO-EU0102F
MPN - NWA90AXPRO-EU0102F
name - Access Piont Nebula NWA90AX PRO NWA90AXPRO-EU0102F
Name - Zyxel NWA90AXPRO-EU0102F
Name - Zyxel WIFI6 AX3000 NWA90AX Pro
Network architecture - GigabitEthernet
Operating frequency - 2,4 GHz
Operating frequency - 5 GHz
Operating temperature range (T-T), °C - 0 - 50
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 50 °C
Operational conditions - Storage relative humidity (H-H) - 10 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Other features -
Packaging data - Package depth - 155 mm
Packaging data - Package height - 60 mm
Packaging data - Package weight - 668 g
Packaging data - Package width - 240 mm
PeriodofWarranty - 24 M
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 100 - 240 V
Power - Input current - 0.3 A
Power - Output current - 2 A
Power - Output voltage - 12 V
Power - Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) Support - Yes
Power supply - Power adapter: AC 100 - 240V - 50/60 Hz 0.3A; Output: DC +12V 2A PoE (802.3at): power consumption 20.5 W
producer - Zyxel
Producer - Zyxel
producerCode - NWA90AXPRO-EU0102F
ProducerCode - NWA90AXPRO-EU0102F
productName - Access point Zyxel NWA90AX PRO 2400 Mbit/s PoE+/PoE++
ProductName - NWA90AX PRO
productSize - Normal
Protocols - Management protocols - SNMP
Security - Encryption: WEP WPA WPA2-PSK WPA3 Authentication: WPA WPA2-Enterprise EAP IEEE 802.1X RADIUS authentication Access management: L2 isolation MAC filtering Detecting rogue access points
Security - MAC address filtering - Yes
Security - Security algorithms - 802.1x RADIUS
Security - Security algorithms - 802.1x RADIUS, EAP, WEP, WPA, WPA2, WPA2-Enterprise, WPA2-PSK, WPA3
Security - Security algorithms - EAP
Security - Security algorithms - WEP
Security - Security algorithms - WPA
Security - Security algorithms - WPA2
Security - Security algorithms - WPA2-Enterprise
Security - Security algorithms - WPA2-PSK
Security - Security algorithms - WPA3
Security algorithms supported - WEP/WPA/WPA2-PSK/WPA3
ShortDescription -
ShortSummaryDescription - Zyxel NWA90AX PRO, 2.4 GHz, 5 GHz, 2400 Mbit/s, 802.1x RADIUS, EAP, WEP, WPA, WPA2, WPA2-Enterprise, WPA2-PSK, WPA3, 1000,2500 Mbit/s
sizeX - 235
sizeY - 60
sizeZ - 155
Software -
Special functions - MU-MIMO Band control WDS/Mesh Fast roaming: Pre-authentication, PMK caching and 802.11r/k/v DCS
Standards - 802.11a
Standards - 802.11ac
Standards - 802.11ax
Standards - 802.11b
Standards - 802.11g
Standards - 802.11n
Standards - IPv6
Stck_Kart - 18
Stck_Pal - 0
Storage temperature range (T-T), °C - -40 - 70
Storno - Y
System Requirements -
Title - Zyxel NWA90AX PRO 2400 Mbit/s White Power over Ethernet (PoE)
URL - https://www.zyxel.com/global/en/products/wireless/802-11ax-wifi-6-dual-radio-poe-access-point-nwa90ax-pro/overview
vendpn - NWA90AXPRO-EU0102F
WarrantyInfo -
warrantyLength - 24
warrantyType - F
Weight - 0.680000
Weight - 352 g
weight - 670
Weight & dimensions - Depth - 140 mm
Weight & dimensions - Height - 37.5 mm
Weight & dimensions - Weight - 352 g
Weight & dimensions - Width - 140 mm
Weight, g - 352
Width - 155.000000
Wireless standard - 802.11 ax
