MikroTik CSS610-8P-2S+IN

10/100/1000/2500 Mbps ports - None
10Base-T / 100Base-TX / 1000Base-T Ports - 8
Accessories included - Rack holders for CSS610-8G-2S+IN K-48 mounting kit IEC cable
Application - Home and small office
brand - MikroTik
category - MikroTik > Komutatori > Cloud Router Switch PoE
Category 1 - Netzwerk
Category 2 - Switching Hubs
Category Code - SWI
Certificates -
Chassis type - Rack
Code - CSS610-8P-2S+IN
Description - CSS610-8P-2S+IN is one of the most versatile switches on the market. It fits perfectly into a wide variety of configurations: from home networks and small offices to hotels, call centers and so on. The unique combination of size, features and price offers incredible scalability potential. There are two SFP+ ports for 10-gigabit fiber connectivity and eight Gigabit Ethernet ports with support for 802.3af/at and passive PoE output (one power supply is enough to provide both). This switch is all about hassle-free and easy setup. The compact form factor means easier shipping and handling, and the lightweight SwOS means easier setup. You can even configure this switch in your web browser! It provides all the basic features of a managed switch and more: you can manage port forwarding, broadcast storm control, apply MAC filters, configure VLANs, mirror traffic, apply bandwidth limits, and even customize some MAC address and IP header fields.
Description - CSS610-8P-2S+IN is one of the most well-rounded switches on the market. It is a perfect fit for the most diverse setups: from home networks and small offices to hotels, call centers and so on. The unique combination of size, features, and price offers unbelievable scalability potential. There are two SFP+ ports for 10 Gigabit fiber connectivity and eight Gigabit Ethernet ports with 802.3af/at and passive PoE-out (you only need a single PSU to provide both). This switch is all about nice and easy setups. The compact form-factor means easier shipping and handling, while the lightweight SwOS means easier configuration. You can even configure this switch from your web browser! It gives you all the core functionality of a managed switch, and even more: you can manage port-to-port forwarding, broadcast storm control, apply MAC filters, configure VLANs, mirror traffic, apply bandwidth limitations, and even adjust some MAC and IP header fields. But the real blessing is the combination of SFP+ and PoE-out Ethernet ports. With this setup, you can do all kinds of things on a tight budget. CSS610 has an impressive total PoE-out budget of 140 W, so you can use even in the most intense scenarios – like hotels, conference halls, or call centers! Use the PoE-out ports to connect the IP-phones while the SFP+ ports connect your primary server to the ISP. Or power a bunch of network cameras and instantly upload the footage to the cloud. And manage a cluster of wireless access points at the same time. Also, scalability is no longer a problem.
Design > Form factor - Rack Mountable
dimension depth - 60 mm
dimension height - 390 mm
Dimensions - 272 x 216 x 50 mm
dimension weight - 2000 g
dimension width - 260 mm
EAN - 4752224007216
ean - 4752224007216
Environment requirements - Tested ambient temperature: -40°C to 70°C
Fan - No
Features > Mesh Support - No
Features > Mobile Broadband - No mobile broadband
Features > MU-MiMO - No
Full Description Line - 8x10Base-T / 100Base-TX / 1000Base-T|2xSFP+|Dimensions 272 x 216 x 50 mm|Unit Net Weight 0.7 kg
guarantee - 12
guarantee_type - normal
height - 0.073 m
L2 features -
L3 features -
length - 0.39 m
Link - https://mikrotik.com/product/css610_8p_2s_in
Management, monitoring, configuration -
Management features > Switch type - Router Switch
Manufacturer - MikroTik
Mean time between failures (MTBF) - 200000 h
Model - CSS610-8P-2S+IN
mpn - CSS610-8P-2S+IN
MPN - CSS610-8P-2S+IN
Name - 8P+2 Mikrotik CSS610-8P-2S+IN SFP+ POE M
Name - Cloud Router Switch | CSS610-8P-2S+IN | No Wi-Fi | 10/100/1000 Mbit/s | Ethernet LAN (RJ-45) ports 8 | Mesh Support No | MU-MiMO No | No mobile broadband
name - MikroTik Cloud Smart Sw itch 8P CSS610-8P-2S+IN
Network architecture - GigabitEthernet
Networking > PoE in - 802.3af/at
Number of 10/100 Mbps ports - None
Number of 10/100/1000 Mbps ports - 8
Number of 10Gb ports - None
Number of COMBO ports - None
Number of PoE++ ports - 1
Number of PoE+ ports - None
Number of PoE ports (PoE & PoE+) - None
Number of QSFP+ ports - None
Number of SFP+ ports - 2
Number of SFP56 ports - None
Number of SFP ports - None
Operational conditions > Operating temperature (T-T) - -40°C to 70°C °C
Other features -
Other features > Ethernet LAN (RJ-45) ports - 8
Other functions -
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 300.00 mm
Package features > Gross height (mm) - 75.00 mm
Package features > Gross width (mm) - 170.00 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 452 pc(s)
Package features > Paper/Pasteboard - 180.00 g
Package features > Plastic (No PET) - 20.00 g
Package features > Tare weight (kg) - 0.20 kg
Package features > Volume (m3) - 0.00 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - Yes
PDF - https://www.blobs.lt/products/3/9/2/0/7/3/88f14b015b2158021d1a85e9646b991c/original.pdf
Performance > Ethernet LAN data rates - 10/100/1000 Mbit/s
Ports & interfaces > Predominant port type - 10/100/1000 Mbps (RJ-45)
Ports & interfaces > SFP+ ports quantity - 2
Power > Power consumption (max) - 162 W
Power > Voltage - 48-57 V
Power consumption - 162 W
Power supply -
Primary port count - 8
producer - MikroTik
Producer product family - Cloud Router Switch
Producer product name - CSS610-8P-2S+IN
QoS -
Security -
SFP+ Ports - 2
Shipping Box Depth Shipping/Package Box Dimensions - 38 cm
Shipping Box Height Shipping/Package Box Dimensions - 25 cm
Shipping box quantity - 1
Shipping Box Weight Shipping/Package Box Dimensions - 1.981 kg
Shipping Box Width Shipping/Package Box Dimensions - 6.5 cm
Software > Operating system installed - SwitchOS Lite
Supported protocols and standards -
Switch class - Managed
Technical details > Gross weight - 0.90 kg
Technical details > Net weight - 0.70 kg
Technical details > Producer - MikroTik
Technical details > Software type - SwitchOS Lite
title - MikroTik CSS610-8P-2S+IN
Unit Box Height - 0.25
Unit Box Length - 0.38
Unit Box Width - 0.065
Unit Brutto Volume - 0.006175 cubm
Unit Gross Weight - 1.98 kg
Unit Net Weight - 0.7 kg
Vendor Homepage - mikrotik.com/product/css610_8p_2s_in#fndtn-specifications
vendpn - CSS610-8P-2S+IN
VLAN -
Warranty - 12
Warranty - 12 month(s)
Warranty - 12 months
Weight - 1.98
weight - 2.2 kg
width - 0.26 m
Wireless LAN features > Wi-Fi band - No Wi-Fi
