Mercusys MR80X AX3000 Dual-Band Wi-Fi 6 Router

Accessories included - MR80X router Power supply Quick Installation Guide RJ45 Ethernet cable
Annex - Not applicable
Antenna - Fixed external
Antenna - Antenna design - External
Antenna - Antenna gain level (max) - 5 dBi
Antenna - Antennas quantity - 4
Antenna > Antennas quantity - 4
Antenna > Antenna type - External
Antenna Gain - 5 dB
Antenna gain - 5 dBi
Antenna Type - Omni-Directional
Category - Root/Electronics/Networks and communication/Routers
Category Code - WRO
Code - MR80X
Color - Black
Data transmission speed - 300 Mbps
Description - AX3000 Dual-Band Wi-Fi 6 Router OPTIMAL WIFI 6 SPEEDS – Optimal WiFi 6 speeds reaching up to 3 Gbps for faster browsing, streamings, and downloading, all at the same time. MORE DEVICES, MORE FUN – Supports MU-MIMO and OFDMA to reduce congestion and quadruple the average throughput. WiFi THAT GOES FARTHER – 4× multi-directional high-gain antennas with Beamforming boost stable connections throughout your home for strong WiFi signals in every corner OVERALL SECURITY PROTECTION – The latest WPA3 provides improved WiFi security GIGABIT WIRED CONNECTIONS – Make full use of your internet access and transfer data at dizzying speeds for peak performance ECO-FRIENDLY POWER SAVING – Target Wake Time (TWT) reduces power consumption for your mobile and IoT devices during data transmissions LESS WIFI INTERFERENCE – Minimizes the interference from neighboring signals to improve transmission efficiency with BSS coloring
Description - MR80X WIFI 6 SPEEDS: WiFi 6 speeds of up to 3 Gbps ensure fast internet browsing, streaming and downloading at the same time. MORE DEVICES, MORE FUN: MU-MIMO and OFDMA support reduces congestion and increases throughput. WIFI THAT GOES FURTHER: 4 high-gain omnidirectional antennas and Beamforming technology spread a stable WiFi signal throughout your home. COMPLETE SECURITY PROTECTION: The latest WPA3 encryption standard keeps your wireless network secure. GIGABIT WIRELESS CONNECTIONS: Make the most of your internet connection and transfer data at stunning speeds. ENERGY SAVING Target Wake Time: (TWT) reduces the power consumption of your mobile and IoT devices during data transmission. LESS WIFI INTERFERENCE: Minimises interference from neighbouring networks and improves transmission performance with BSS Colouring. SMART CONNECT: Intelligently selects the best available bandwidth for each device.
Design - LED indicators - LAN, WAN
Design - Product colour - Black
Design - Product type - Tabletop router
dimensionalWeight - 1883
dimension depth - 65 mm
dimension height - 390 mm
Dimensions - 41,7 x 208,8 x 171,6 mm
Dimensions - 208.8 × 171.6 × 41.7 mm
dimension weight - 890 g
dimension width - 290 mm
EAN - 6957939000646
ean - 6957939000646
Eans - 6957939000646
Features > Mesh Support - Yes
Features > Mobile Broadband - No mobile broadband
Features > MU-MiMO - Yes
Full Description Line - Wireless Router|Data transmission speed 300 Mbps|IEEE 802.11a|IEEE 802.11b|IEEE 802.11g|IEEE 802.11n|IEEE 802.11ac|IEEE 802.11ax|WPA - Wi-Fi Protected Access|WPA2 - Wi-Fi Protected Access|WPA3|Antenna Type Omni-Directional|Antenna Gain 5 dB|Wireless Frequency Range 5 GHz;2.4 GHz|Dimensions 208.8 × 171.6 × 41.7 mm
guarantee - 36
guarantee_type - normal
I/O ports - 1 x WAN (RJ-45)
I/O ports - 3 x 10/100/1000 Mbit/s
IEEE 802.11ac Network standard - Yes
IEEE 802.11a Network standard - Yes
IEEE 802.11ax Network standard - Yes
IEEE 802.11b Network standard - Yes
IEEE 802.11g Network standard - Yes
IEEE 802.11n Network standard - Yes
Link - https://www.mercusys.com/en/product/details/mr80x
Logistics data - Harmonized System (HS) code - 85176990
Management, monitoring, configuration - WAN: Dynamic IP address assignment/static IP address assignment/PPPoE/L2TP/PPTP Management: access control, local management, remote management DHCP: server, list of DHCP clients NAT functions: Port forwarding, Port Triggering, UPnP, DMZ Firewall: SPI Firewall, IP and MAC address binding Guest network: 2.4 GHz guest network, 5 GHz guest network VPN Server: OpenVPN, PPTP
Management features - Reset button - Yes
Management features - Wi-Fi Multimedia (WMM)/(WME) - Yes
Management features - WPS push button - Yes
Mobile network - 3G - No
Mobile network - 4G - No
Mobile network - 5G - No
Model - MR80X
Name - Dual-Band Wi-Fi 6 Router | MR80X AX3000 | 802.11ax | 2402+574 Mbit/s | Ethernet LAN (RJ-45) ports 3xGigabit LAN | Mesh Support Yes | MU-MiMO Yes | No mobile broadband | Antenna type External
Name - Mercusys MR80X
name - Router Mercusys MR80X WiFi 6 AX3000 3LAN 1WAN
Network - Cabling technology - 10/100/1000Base-T(X)
Network - Ethernet LAN - Yes
Network - Ethernet LAN data rates - 10
Network - Ethernet LAN data rates - 100
Network - Ethernet LAN data rates - 1000
Network - Ethernet LAN interface type - Gigabit Ethernet
Network - Networking standards - IEEE 802.11a
Network - Networking standards - IEEE 802.11ac
Network - Networking standards - IEEE 802.11ax
Network - Networking standards - IEEE 802.11b
Network - Networking standards - IEEE 802.11g
Network - Networking standards - IEEE 802.11n
Network - Number of guest networks (2.4 GHz) - 1
Network - Number of guest networks (5 GHz) - 1
Network - Port forwarding - Yes
Network - Port triggering - Yes
Network - VPN server - OpenVPN, PPTP
Network - VPN support - OpenVPN, PPTP supported
Network - Wireless radio - Yes
Network architecture - GigabitEthernet
Network Device Type - Wireless Router
Number of antennas - 4
Operating frequency - 2,4 GHz
Operating frequency - 5 GHz
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Other features -
Other features > Ethernet LAN (RJ-45) ports - 3xGigabit LAN
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 385 mm
Package features > Gross depth master carton - 595 mm
Package features > Gross height (mm) - 290 mm
Package features > Gross height master carton - 360 mm
Package features > Gross width (mm) - 65 mm
Package features > Gross width master carton - 410 mm
Package features > Net weight master carton - 8.99 kg
Package features > Packing quantity - 10 pc(s)
Package features > Palette Qty - 190 pc(s)
Package features > Paper/Pasteboard - 90.00 g
Package features > Plastic (No PET) - 10.00 g
Package features > Tare weight (kg) - 0.10 kg
Package features > Tare weight master carton - 1.493 kg
Package features > Volume (m3) - 0.00725725 m³
Package features > WEE classification - CL109:5:2017-04-01
Package features > WEEE tax - Yes
Packaging content - AC adapter included - Yes
Packaging content - Cables included - LAN (RJ-45)
Packaging content - Quick installation guide - Yes
Performance > 2.4 GHz - Yes
Performance > 5 GHz - Yes
Performance > Wi-Fi data rate (max) - 2402+574 Mbit/s
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 3
Ports & interfaces - USB port - No
Ports & interfaces > WAN connection - 1x Gigabit WAN Port
Power - External power adapter - Yes
Power - Power source type - AC
Power supply -
Producer - Mercusys
producer - TP-LINK
producerCode - MR80X
ProducerCode - MR80X
Producer product family - Dual-Band Wi-Fi 6 Router
Producer product name - MR80X AX3000
productName - Mercusys AX3000 Dual-Band Wi-Fi 6 Router
productSize - Normal
Protocols - DHCP client - Yes
Protocols - DHCP server - Yes
Protocols - Universal Plug and Play (UPnP) - Yes
Security - WEP WPA / WPA2-Personal WPA2 / WPA3-Personal
Security - DMZ support - Yes
Security - Firewall - Yes
Security - Firewall security - SPI Firewall, IP and MAC Address Binding
Security - Guest access - Yes
Security - NAT functionality - Port Forwarding, Port Triggering, UPnP, DMZ
Security - Network address translation (NAT) - Yes
Security - Security algorithms - WEP
Security - Security algorithms - WPA
Security - Security algorithms - WPA2
Security - Security algorithms - WPA3
Shipping Box Depth Shipping/Package Box Dimensions - 39 cm
Shipping Box Height Shipping/Package Box Dimensions - 7 cm
Shipping box quantity - 1
Shipping Box Weight Shipping/Package Box Dimensions - 0.87 kg
Shipping Box Width Shipping/Package Box Dimensions - 29.5 cm
ShortDescription -
sizeX - 345
sizeY - 390
sizeZ - 70
Software -
Special functions -
Standards - 802.11a
Standards - 802.11ac
Standards - 802.11ax
Standards - 802.11b
Standards - 802.11g
Standards - 802.11n
System Requirements -
Technical details > Gross weight - 0.899 kg
Technical details > Net weight - 0.799 kg
Technical details > Producer - Mercusys
Type - xDSL
Unit Box Height - 0.07
Unit Box Length - 0.39
Unit Box Width - 0.295
Unit Brutto Volume - 0.008053 cubm
Unit Gross Weight - 0.87 kg
Unit Net Weight - 0.3 kg
Vendor Homepage - www.mercusys.com/en/product/details/mr80x
vendpn - MR80X
WAN connection - DSL WAN - No
WAN connection - Ethernet WAN - Yes
WAN connection - SIM card slot - No
WAN connection - WAN connection type - RJ-45
Warranty - 36
Warranty - 36 month(s)
Warranty - 36 months
warrantyLength - 36
warrantyType - G
weight - 890
Weight & dimensions - Depth - 171.6 mm
Weight & dimensions - Height - 41.7 mm
Weight & dimensions - Width - 208.8 mm
Wireless Frequency Range - 5 GHz;2.4 GHz
Wireless LAN features - Top Wi-Fi standard - Wi-Fi 6 (802.11ax)
Wireless LAN features - Wi-Fi band - Dual-band (2.4 GHz / 5 GHz)
Wireless LAN features - Wi-Fi standards - 802.11a
Wireless LAN features - Wi-Fi standards - 802.11b
Wireless LAN features - Wi-Fi standards - 802.11g
Wireless LAN features - Wi-Fi standards - Wi-Fi 4 (802.11n)
Wireless LAN features - Wi-Fi standards - Wi-Fi 5 (802.11ac)
Wireless LAN features - Wi-Fi standards - Wi-Fi 6 (802.11ax)
Wireless LAN features - WLAN data transfer rate (first band) - 2402 Mbit/s
Wireless LAN features - WLAN data transfer rate (max) - 3000 Mbit/s
Wireless LAN features - WLAN data transfer rate (second band) - 574 Mbit/s
Wireless LAN features > Wi-Fi band - 802.11ax
Wireless LAN features > Wi-Fi standards - 02.11ax/ac/a/b/g/n
WPA - Wi-Fi Protected Access Security - Yes
WPA2 - Wi-Fi Protected Access Security - Yes
WPA3 Security - Yes
