Accessories included - - Urządzenie CPE210
- Pasywny adapter PoE 24V 1A
- Paski do montażu
- Przewód zasilający
- Skrócona instrukcja obsługi
Antenna - Built-in
Antenna - Antenna direction type - Directional
Antenna - Antenna features - Integrated antenna
Antenna - Antenna gain level (max) - 9 dBi
Antenna - Antennas quantity - 1
Antenna - Antenna type - Internal
Antenna - Polarization - Dual polarization
Antenna > Antenna type - 1xInternal
Antenna gain - 9 dBi
Antenna Type - Built-in
ARTIKEL1 - CPE210 OUTDOOR 2.4GHZ 300MBPS
ARTIKEL2 - HIGH POWER WLAN ACCESS POINT
Brand - TP-Link
BrandPartCode - CPE210
BrandPartCode - CPE210 V3.20
Breite - 0.14
Built-in flash memory - 8 MB
Built-in RAM memory - 64 MB
Category - Root/Electronics/Networks and communication/Access points
Category - Wireless Access Points
Category Code - WOD
Category_1 - Network and Servers
Category_2 - Network - Switches and Hubs
Certificates - Certification - - FCC/UL/IC/GS/PSB/C-tick/SAA/S-Mark/KC-mark
- RoHS, IPX5
Certificates - Certification - CE/FCC/UL/IC/GS/PSB/C-tick/SAA/S-Mark/KC-mark
CE, FCC, RoHS
Code - CPE210
Color - White
Data transmission speed - 300 Mbps
Description - - Built-in 9dBi 2x2 dual-polarized directional MIMO antenna - Adjustable transmission power from 0 to 27dBm/500mw - System-level optimizations for more than 5km long range wireless transmission - TP-LINK Pharos MAXtream TDMA (Time-Division-Multiple-Access) technology improves product performance in throughput, capacity and latency performance, ideal for PTMP applications - Centralized Management System – Pharos Control - AP / Client / Repeater / AP Router / AP Client Router (WISP) operation modes - Passive PoE Adapter supports up to 60 meter (200 feet) Power over Ethernet deployment and allows the device to be reset remotely
Description - Zewnętrzne urządzenie CPE 2,4GHz 300Mbps Wyróżnione funkcje:
- Wbudowana kierunkowa antena MIMO 2x2 o wzmocnieniu 9dBi
- Regulowana moc nadajnika
- System zoptymalizowany pod kątem transmisji na długie dystanse
- Technologia TP-LINK Pharos MAXtream TDMA poprawia wydajność przesyłu danych i zmniejsza opóźnienia w transmisji, do zastosowań w połączeniach typu punkt-wielopunkt
- Centralny system zarządzania - Pharos Control
- Tryby pracy Access Point / Client / Repeater / AP Router / WISP
- Dołączony adapter Pasywnego PoE pozwala na zasilenie urządzenia oddalonego do 60 metrów oraz na jego zdalny reset
Design - International Protection (IP) code - IPX5
Design - LED indicators - Status
Design - LED indicators - Yes
Design - Placement - Pole
Design - Placement - Wall
Design - Product colour - White
Design - Reset button - Yes
dimensionalWeight - 1093
dimension depth - 110 mm
dimension height - 270 mm
Dimensions - 224 x 79 x 60 mm
dimension weight - 920 g
dimension width - 130 mm
EAN - 6935364071677
ean - 6935364082253
EANCode - 6935364071677
Eans - 6935364071677
EAN_code - 6935364071677
Features - 2.4 GHz - Yes
Features - 5 GHz - No
Features - 6 GHz - No
Features - Automatic channel scanning - Yes
Features - Automatic channel selection - Yes
Features - Bandwidth - 2.4 GHz
Features - Dynamic Frequency Selection (DFS) - Yes
Features - Frequency band - 2.4 - 2.483 GHz
Features - Maximum data transfer rate - 300 Mbit/s
Features - Maximum data transfer rate (2.4 GHz) - 300 Mbit/s
Features - Maximum outdoor range - 5000 m
Features - MIMO - Yes
Features - MIMO type - Multi User MIMO
Features - Networking standards - IEEE 802.11b
Features - Networking standards - IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Features - Networking standards - IEEE 802.11g
Features - Networking standards - IEEE 802.11n
Features - Receiver sensitivity - 802.11b:
11M: -95dBm, 5.5M: -96dBm, 2M: -96dBm, 1M: -96dBm
-802.11g:
54M: -79dBm, 48M: -80dBm, 36M: -84dBm, 6-24M: -88dBm
802.11n:
MCS15: -76dBm, MCS14: -78dBm, MCS13: -80dBm,
MCS12: -84dBm, MCS11: -87dBm, MCS10: -91dBm,
MCS9: -93dBm, MCS8: -96dBm, MCS7: -76dBm,
MCS6: -78dBm, MCS5: -80dBm, MCS4: -84dBm,
MCS3: -87dBm, MCS2: -91dBm, MCS1: -93dBm, MCS0: -96dBm
Features - VLAN support - Yes
Features - Wireless isolation - Yes
Features > Mesh Support - No
Features > Mobile Broadband - No mobile broadband
Features > MU-MiMO - Yes
Full Description Line - Data transmission speed 300 Mbps|IEEE 802.11b|IEEE 802.11g|IEEE 802.11n|Antenna Type Built-in|Wireless Frequency Range 2.4~2.483GHz|Windows 8|Windows 7|Linux|MacOS|Windows 98|Windows 2000|Windows NT|Windows Vista|Included Accessories 24V 1A Passive PoE Adapter,Pole Mounting Straps,AC Power Cord,Installation Guide
Gewicht - 0.73
Gross Weight Kg - 0,92
GRUPPE1 - Network
GRUPPE2 - Wireless Lan Ap
GTIN - 6935364071677
guarantee - 36
guarantee_type - normal
HERSTELLER - TP-LINK
Hoehe - 0.11
HSTNUMMER - CPE210
I/O ports - 1 x 10/100 Mbit/s
IEEE 802.11b Network standard - Yes
IEEE 802.11g Network standard - Yes
IEEE 802.11n Network standard - Yes
Included Accessories - 24V 1A Passive PoE Adapter,
Pole Mounting Straps,
AC Power Cord,
Installation Guide
Laenge - 0.27
Link - https://www.tp-link.com/us/business-networking/outdoor-radio/cpe210/
Linux OS compatibility - Yes
Logistics data - Harmonized System (HS) code - 85176990
LongDesc - TP-LINK’s 2.4GHz 300Mbps 9dBi Outdoor CPE, the CPE210 is dedicated to cost effective solutions for outdoor wireless networking applications. With its centralized management application, it is flexible and ideal for point-to-point, point-to-multipoint and outdoor Wi-Fi coverage applications. Professional performance, coupled with user-friendly design, makes CPE210 an ideal choice for both business and home users.Enterprise HardwareWith Qualcomm Atheros enterprise level chipsets, high gain antennas and high quality material, specially designed enclosure, and PoE power supply, CPE210 is specially designed for outdoor use and can operate flawlessly in almost any climate, with operating temperatures ranging from -40℃ (-40℉) to +70 ℃ (158℉).Advanced Antenna SystemBuilt-in High Gain Dual-Polarized AntennaDedicated metal reflector ensures higher gainand lower noise interference5km+ Wireless Data TransmissionSpecially designed for outdoor uses, ideal for long distance wireless data transmission over 5km+, tested in the field.TP-LINK MAXtream TDMA TechnologyAs network scale increases, wireless competition and collisions among CPEs and base stations will be so enormous that the real throughput of the network will drop, resulting in a serious impact on end-user experience. To mitigate these effects, the CPE210 uses MAXtream TDMA Technology.Pharos Control – Centralized Management SystemCPE210 also comes equipped with centralized management software that helps users easily manage all the devices in their network from a single PC - Pharos Control. Functions like device discovery, status monitoring, firmware upgrading, and network maintenance can be managed using Pharos Control.PharOSUser-friendly web-based management system allows professionals to do more specific configurations.
LongDesc - TP-Link’s 2.4GHz 300Mbps 9dBi Outdoor CPE, the CPE210 is dedicated to cost effective solutions for outdoor wireless networking applications. With its centralized management application, it is flexible and ideal for point-to-point, point-to-multipoint and outdoor Wi-Fi coverage applications. Professional performance, coupled with user-friendly design, makes CPE210 an ideal choice for both business and home users.Enterprise HardwareWith Qualcomm Atheros level chipsets, high gain antennas and highquality material, specially designed enclosure, and PoE power supply, CPE210 isspecially designed for outdoor use and can operate flawlessly in almost any climate,with operating temperatures ranging from -40℃ (-40℉) to +70℃ (158℉).Advanced Antenna System Built-in High Gain Dual-Polarized Antenna Dedicated metal reflector ensures higher gain and lower noise interference5km+ Wireless Data TransmissionSpecially designed for outdoor uses, ideal for long distance wireless data transmission over 5km+, tested in the field.TP-Link MAXtream TDMA TechnologyAs network scale increases, wireless competition and collisions among CPEs and base stations will beso enormous that the real throughput of the network will drop, resulting in a serious impact on end-userexperience. To mitigate these effects, the CPE210 uses MAXtream TDMA Technology.Pharos Control – Centralized Management SystemCPE210 also comes equipped with centralized management software that helps users easilymanage all the devices in their network from a single PC - Pharos Control. Functions like device discovery,status monitoring, firmware upgrading, and network maintenance can be managed using Pharos Control.
LongProductName - 2.4GHz 300Mbps 9dBi Outdoor CPE
LongProductName - 560MHz CPU, MIPS 74Kc, 64MB DDR2 RAM, 8MB Flash, IPX5
LongSummaryDescription - TP-Link 2.4GHz 300Mbps 9dBi Outdoor CPE. 2.4 GHz, Maximum data transfer rate: 300 Mbit/s. Security algorithms: 64-bit WEP, 128-bit WEP, 152-bit WEP, SSID, TKIP, WPA, WPA-PSK, WPA2, WPA2-PSK. Power over Ethernet (PoE). Product colour: White. Power consumption (max): 10.5 W
LongSummaryDescription - TP-Link CPE210. 2.4 GHz, Maximum data transfer rate: 300 Mbit/s. Security algorithms: AES, TKIP, WPA, WPA-PSK, WPA2, WPA2-PSK. Power over Ethernet (PoE). Product colour: White
MacOS OS compatibility - Yes
Management features - Firmware upgradeable - Yes
Management features - Management platform - Pharos Control
Management features - Web-based management - Yes
Manufacturer - TP-Link
Manufacturer Code - CPE210
Manufacturer Name - TP-LINK
Manufacturer_code - CPE210
Name - 2.4GHz 300Mbps 9dBi Outdoor CPE | CPE210 | 802.11n | 300 Mbit/s | 10/100 Mbit/s | Ethernet LAN (RJ-45) ports 1 | Mesh Support No | MU-MiMO Yes | No mobile broadband | Antenna type 1xInternal
name - CPE210 Outdoor 2,4GHz 300 MbPS
Name - TP-Link CPE210
Name - TP-Link Pharos CPE210 v2 1FE/N300/OAP - 2x2 9dBi, PoE, IPX5
Network architecture - FastEthernet
Number of antennas - 1
Operating frequency - 2,4 GHz
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - -30 - 70 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 95%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Other features -
Other features > Ethernet LAN (RJ-45) ports - 1
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 130 mm
Package features > Gross depth master carton - 560 mm
Package features > Gross height (mm) - 270 mm
Package features > Gross height master carton - 290 mm
Package features > Gross width (mm) - 105 mm
Package features > Gross width master carton - 550 mm
Package features > Net weight master carton - 14.76 kg
Package features > Packing quantity - 20 pc(s)
Package features > Palette Qty - 380 pc(s)
Package features > Paper/Pasteboard - 160.00 g
Package features > Plastic (No PET) - 40.00 g
Package features > Tare weight (kg) - 0.20 kg
Package features > Tare weight master carton - 1.518 kg
Package features > Volume (m3) - 0.0036855 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - Yes
Packaging content - Cables included - AC
Packaging content - Mounting kit - Yes
Packaging content - Quantity per pack - 1 pc(s)
Packaging data - Package depth - 270 mm
Packaging data - Package height - 106 mm
Packaging data - Package weight - 760 g
Packaging data - Package width - 132 mm
Performance - Built-in processor - Yes
Performance - Compatible operating systems - Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 8, Windows 7, MAC OS, NetWare, UNIX or Linux.
Performance - Flash memory - 8 MB
Performance - Internal memory - 64 MB
Performance - Processor architecture - MIPS 74Kc
Performance - Processor frequency - 560 MHz
Performance - Processor model - Qualcomm Atheros
Performance > Ethernet LAN data rates - 10/100 Mbit/s
Performance > Wi-Fi data rate (max) - 300 Mbit/s
Polarization - Linear horizontal
Polarization - Linear vertical
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces - Ethernet LAN (RJ-45) ports - 2
Power - AC input frequency - 50 - 60 Hz
Power - AC input voltage - 100 - 240 V
Power - Input current - 0.8 A
Power - Output current - 0.25 A
Power - Output current - 1 A
Power - Output voltage - 24 V
Power - Power consumption (max) - 10.5 W
Power - Power over Ethernet (PoE) - Yes
Power - Power over Ethernet (PoE) type supported - Passive PoE
Power supply - Pasywny adapter PoE 24V 1A
Processor - Qualcomm Atheros 560MHz, MIPS 74Kc
producer - TP-LINK
Producer - TP-Link
producerCode - CPE210
ProducerCode - CPE210
Producer product family - 2.4GHz 300Mbps 9dBi Outdoor CPE
Producer product name - CPE210
ProductName - 2.4GHz 300Mbps 9dBi Outdoor CPE
ProductName - CPE210
productName - TP-Link CPE210 300 Mbit/s White Power over Ethernet (PoE)
productSize - Normal
Protocols - Management protocols - TDMA
Protocols - Universal Plug and Play (UPnP) - Yes
Security - WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP), 64/128/152-bit WEP
Security - Auto Wireless Distribution System (WDS) - Yes
Security - IGMP snooping - Yes
Security - MAC address filtering - Yes
Security - Security algorithms - 64-bit WEP, 128-bit WEP, 152-bit WEP, SSID, TKIP, WPA, WPA-PSK, WPA2, WPA2-PSK
Security - Security algorithms - AES
Security - Security algorithms - AES, TKIP, WPA, WPA-PSK, WPA2, WPA2-PSK
Security - Security algorithms - TKIP
Security - Security algorithms - WPA
Security - Security algorithms - WPA-PSK
Security - Security algorithms - WPA2
Security - Security algorithms - WPA2-PSK
Security - Service Set Identifier (SSID) features - SSID broadcast
Security - Service Set Identifier (SSID) features - SSID broadcast, SSID broadcast on/off
Security - Service Set Identifier (SSID) features - SSID broadcast on/off
Shipping Box Depth Shipping/Package Box Dimensions - 27 cm
Shipping Box Height Shipping/Package Box Dimensions - 10.5 cm
Shipping box quantity - 1
Shipping Box Weight Shipping/Package Box Dimensions - 0.745 kg
Shipping Box Width Shipping/Package Box Dimensions - 13 cm
Short description - TP-LINK WLAN 300MBit Access Point 2,4GHz CPE210
ShortDescription - Wbudowana kierunkowa antena MIMO 2x2 o wzmocnieniu 9dBi
ShortSummaryDescription - TP-Link 2.4GHz 300Mbps 9dBi Outdoor CPE, 2.4 GHz, 300 Mbit/s, 64-bit WEP, 128-bit WEP, 152-bit WEP, SSID, TKIP, WPA, WPA-PSK, WPA2, WPA2-PSK
ShortSummaryDescription - TP-Link CPE210, 2.4 GHz, 300 Mbit/s, AES, TKIP, WPA, WPA-PSK, WPA2, WPA2-PSK
sizeX - 135
sizeY - 270
sizeZ - 150
Software -
Special functions -
Standards - 802.11a
Standards - 802.11b
Standards - 802.11g
Standards - 802.11n
Stck_Kart - 20
Stck_Pal - 20
Storno - Y
System Requirements - - Microsoft Windows 98SE, NT, 2000, XP, Vista, Windows 8, Windows 7, MAC OS, NetWare, UNIX, Linux.
- Zalecamy korzystanie z przeglądarek: Google Chrome, Safari oraz Firefox.
Technical details > Gross weight - 0.738 kg
Technical details > Net weight - 0.538 kg
Technical details > Other features - Passive PoE Adapter supports up to 60 meter (200 feet) Power over Ethernet deployment and allows the device to be reset remotely.
Technical details > Producer - TP-LINK
Technical_details - LAN: 2x 100Base-TX (PoE) Wireless: WLAN 802.11b/?g/?n Transfer rate: 300Mbps (2.4GHz) Security: 64/?128/?152bit WEP, WPA, WPA2 Antennas: internal Connectors: not available Power consumption: 10.5W (operation) Dimensions: 224x79x60mm Special features: Outdoor Warranty: three years
Title - TP-Link 2.4GHz 300Mbps 9dBi Outdoor CPE 300 Mbit/s White Power over Ethernet (PoE)
Title - TP-Link CPE210 300 Mbit/s White Power over Ethernet (PoE)
Type - Directional
Unit Box Height - 0.105
Unit Box Length - 0.27
Unit Box Width - 0.13
Unit Brutto Volume - 0.003685 cubm
Unit Gross Weight - 0.745 kg
Unit Net Weight - 0.5 kg
URL - https://www.tp-link.com/pk/business-networking/outdoor-radio/cpe210/v3.20/
URL - https://www.tp-link.com/us/business-networking/outdoor-radio/cpe210/#overview
Usage - Outside
Vendor Homepage - http://www.tp-link.com/lk/products/details/?categoryid=&model=CPE210
vendpn - CPE210
Warranty - 36
Warranty - 36 month(s)
Warranty - 36 months
WarrantyInfo -
WarrantyInfo - 2 year
warrantyLength - 36
warrantyType - G
Weight - 0,81
weight - 882
Weight & dimensions - Depth - 79 mm
Weight & dimensions - Height - 60 mm
Weight & dimensions - Width - 224 mm
Windows 7 OS compatibility - Yes
Windows 8 OS compatibility - Yes
Windows 98 OS compatibility - Yes
Windows 2000 OS compatibility - Yes
Windows NT OS compatibility - Yes
Windows Vista OS compatibility - Yes
Wireless Frequency Range - 2.4~2.483GHz
Wireless LAN features > Wi-Fi band - 802.11n
Wireless LAN features > Wi-Fi standards - 802.11b/g/n
