10Base-T / 100Base-TX Ports - 2
Accessories included - - EAP115
- Mounting kit
- Installation Guide
Antenna - Built-in
Antenna - Antenna direction type - Omni-directional
Antenna - Antenna features - Integrated antenna
Antenna - Antenna gain level (max) - 1.8 dBi
Antenna - Antennas quantity - 2
Antenna - Antenna type - Internal
Antenna > Antennas quantity - 2
Antenna > Antenna type - 2xInternal
Antenna Gain - 1.8 dB
Antenna gain - 1.8 dBi
Antenna Type - Omni-Directional
ARTIKEL1 - EAP115-WALL 300 MBIT/S WLAN N
ARTIKEL2 - ACCESS POINT F/WALL MOUNTING
Brand - TP-Link
BrandPartCode - EAP115-Wall V1
Breite - 0.12
Category - Root/Electronics/Networks and communication/Access points
Category - Wireless Access Points
Category Code - WAP
Category_1 - Network and Servers
Category_2 - Network - WiFi Access Points
Certificates - Compliance certificates - CE, RoHS
Code - EAP115-Wall
Color - White
Data transmission speed - 300 Mbps
Description - 300Mbps Wireless N Wall-Plate Access Point - Easy-mount construction allows installation into any standard EU-type data wall-box - Compact, low-profile design fits discreetly with any existing interior style - Free Auranet Controller Software enables administrators to easily manage hundreds of EAPs - Support Power over Ethernet (802.3af) for convenient and affordable installation - Enterprise class Wi-Fi security helps to decrease network security threats - Captive portal provides one convenient method of authentication for Wi-Fi guests
Description - Wireless access point can be mounted on the ceiling, standard N 300Mb/s EAP115
- The management software allows for centralized management of a wireless network
- User-friendly cluster mode allows you to manage 24 devices (EAP115) without additional hardware or software
- Support PoE
- Easy to install on a wall or ceiling
- Authentication using the welcome page
- Multi-SSID allows you to create subnets for different users
- Business-class security to protect WiFi network against attacks
Design - Cable lock slot - No
Design - Certification - CE, RoHS
Design - Internal - No
Design - LED indicators - Yes
Design - Placement - Wall
Design - Product colour - White
Design - Reset button - Yes
dimensionalWeight - 156
dimension depth - 55 mm
dimension height - 135 mm
Dimensions - 86,8 x 86,8 x 30,2 mm
Dimensions - 86.8x86.8x30.2 mm
dimension weight - 200 g
dimension width - 125 mm
EAN - 6935364093457
ean - 6935364093457
EANCode - 6935364093457
Eans - 6935364093457
EAN_code - 6935364093457
Features - 2.4 GHz - Yes
Features - 5 GHz - No
Features - 6 GHz - No
Features - Automatic channel selection - Yes
Features - Cabling technology - 10/100Base-T(X)
Features - Ethernet LAN data rates - 10
Features - Ethernet LAN data rates - 10,100 Mbit/s
Features - Ethernet LAN data rates - 100 Mbit/s
Features - Frequency band - 2.4 - 2.4835 GHz
Features - Maximum data transfer rate - 300 Mbit/s
Features - Maximum data transfer rate (2.4 GHz) - 300 Mbit/s
Features - Networking standards - IEEE 802.11b
Features - Networking standards - IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Features - Networking standards - IEEE 802.11g
Features - Networking standards - IEEE 802.11n
Features - Quality of Service (QoS) support - Yes
Features - Rate limiting - Yes
Features - Transmitting power - 15 dBmW
Features - Transmitting power (CE) - 20 dBm
Features - Virtual LAN features - Port-based VLAN, VLAN mapping
Features - VLAN support - Yes
Features - Wi-Fi Multimedia (WMM)/(WME) - Yes
Features - Wireless isolation - Yes
Features > MU-MiMO - No
Full Description Line - Omada|EAP115-WALL|Type Wireless Access Point|Data transmission speed 300 Mbps|IEEE 802.11a|IEEE 802.11b|IEEE 802.11g|IEEE 802.11n|Antenna Type Omni-Directional|Antenna Gain 1.8 dB|Number of antennas 2|Wireless Frequency Range 2.4GHz|Dimensions 86.8x86.8x30.2 mm
Gewicht - 0.21
GRUPPE1 - Network
GRUPPE2 - Wireless Lan Ap
GTIN - 6935364093457
GTIN - 6935364096670
guarantee - 60
guarantee_type - normal
HERSTELLER - TP-LINK
Hoehe - 0.05
HSTNUMMER - EAP115-WALL
I/O ports - 1 x 10/100 Mbit/s
I/O ports - 1 x 10/100 Mbit/s PoE
IEEE 802.11a Network standard - Yes
IEEE 802.11b Network standard - Yes
IEEE 802.11g Network standard - Yes
IEEE 802.11n Network standard - Yes
Laenge - 0.13
Link - https://www.tp-link.com/baltic/business-networking/wall-plate-ap/eap115-wall/
Logistics data - Harmonized System (HS) code - 85176990
LongDesc - Installation Made Easy- Detach the faceplate of the junction box* with a screwdriver.- Remove the faceplate of the EAP.- Connect an in-wall Ethernet cable to the Uplink+POE port.- Secure the access point to the wall using the nails provided.- Press the faceplate back into position.Perfectly FormedThe EAP115-Wall would blend seamlessly into any business setting with a refined, minimalist appearance. A slimline design includes casing that’s just 11 mm in thickness.Effortless DeploymentWith 802.3af Power over Ethernet supported there’s no need for additional wiring. Simply plug in existing Ethernet cables and you’re ready to go.Complete Wireless CoverageAn EAP in each room guarantees a strong wireless signal and allows guests to enjoy their own private Wi-Fi network.Cloud Centralized Management- Anytime, AnywhereOmada Cloud Controller OC200 and Omada Software Controller make it easy to manage and monitor the whole Omada network in real-time, while cloud service enables remote and secure access no matter where you find yourself.Easy Management with the Omada AppFollow configuration instructions on the free Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status and manage clients, all from the convenience of a smart phone or tablet.
LongProductName - 300Mbit/s-WLAN-Unterputz-Accesspoint, 2.4 - 2.4835 GHz, 9VDC/0.6A, 2.8W
LongSummaryDescription - TP-Link Omada 300Mbps Wireless N Wall-Plate Access Point. 2.4 GHz, Maximum data transfer rate: 300 Mbit/s. Security algorithms: 802.1x RADIUS, HTTPS, WPA, WPA-PSK, WPA2, WPA2-PSK. Ethernet LAN data rates: 10,100 Mbit/s. Power over Ethernet (PoE). Product colour: White
Management, monitoring, configuration - - Oprogramowanie EAP Controller
- Powiadomienia e-mail
- Wyłącznik diod
- Kontrola dostępu po adresach MAC
- SNMP v1,v2c
- Dziennik systemowy: Lokalny i zdalny
- Telnet
- Zarządzanie przez przeglądarkę HTTP/HTTPS
- L3 Management
- Multi-site Management
- Management VLAN
Management features - Syslog - Yes
Management features - Web-based management - Yes
Manufacturer - TP-Link
Manufacturer_code - EAP115-WALL
Model name - EAP115-WALL
name - EAP115-Wall Access Point N300 PoE
Name - TP-Link EAP115-Wall
Name - TP-LINK | Wireless N Wall-Plate Access Point | EAP115 | 802.11n | 300 Mbit/s | 10/100 Mbit/s | Ethernet LAN (RJ-45) ports 1 | MU-MiMO No | PoE in | Antenna type 2xInternal
Name - TP-Link Auranet EAP115-WALL
Network architecture - FastEthernet
Network Device Type - Wireless Access Point
Networking > Wi-Fi - Yes
Number of antennas - 2
Operating frequency - 2,4 GHz
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Other features -
Other features > Ethernet LAN (RJ-45) ports - 1
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 69.00 mm
Package features > Gross height (mm) - 246.00 mm
Package features > Gross width (mm) - 268.00 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 380 pc(s)
Package features > Paper/Pasteboard - 8.00 g
Package features > Plastic (No PET) - 245.00 g
Package features > Tare weight (kg) - 0.25 kg
Package features > Volume (m3) - 0.00 m³
Package features > WEE classification - CL109:5:2017-04-01
Package features > WEEE tax - Yes
Packaging content - Mounting kit - Yes
Packaging content - Quantity per pack - 1 pc(s)
Packaging content - Quick start guide - Yes
Packaging data - Package depth - 118 mm
Packaging data - Package depth - 130 mm
Packaging data - Package height - 47 mm
Packaging data - Package weight - 190 g
Packaging data - Package width - 118 mm
Packaging data - Package width - 130 mm
Performance - Compatible operating systems - Windows XP, Windows Vista, Windows 7, Windows 8, Windows 10
Performance > 2.4 GHz - Yes
Performance > 5 GHz - No
Performance > Ethernet LAN data rates - 10/100 Mbit/s
Performance > Wi-Fi data rate (max) - 300 Mbit/s
Ports & interfaces - Ethernet LAN (RJ-45) ports - 2
Ports & interfaces - WAN connection - Ethernet (RJ-45)
Ports & interfaces > POE - PoE in
Power - Power consumption (typical) - 2.8 W
Power - Power over Ethernet (PoE) - Yes
Power - Power over Ethernet (PoE) type supported - Passive PoE
Power supply - PoE
producer - TP-LINK
Producer - TP-Link
producerCode - EAP115-Wall
ProducerCode - EAP115-Wall
Producer product family - Wireless N Wall-Plate Access Point
Producer product name - EAP115
ProductName - 300Mbps Wireless N Wall-Plate Access Point
productName - TP-Link 300Mbps Wireless N Wall-Plate Access Point
productSize - Normal
Protocols - Management protocols - SNMP, Telnet
Security - - Authentication using the welcome page
- Access Control
- MAC address filtering
- Isolation of wireless clients
- SSID to VLAN mapping
- Detect unauthorized AP
- Supports 802.1X
- Encryption 64/128/152-bit WEP / WPA / WPA2-Enterprise, WPA-PSK / WPA2-PSK
Security - Access Control List (ACL) - Yes
Security - MAC address filtering - Yes
Security - Number of SSID supported - 8
Security - Security algorithms - 802.1x RADIUS
Security - Security algorithms - 802.1x RADIUS, HTTPS, WPA, WPA-PSK, WPA2, WPA2-PSK
Security - Security algorithms - HTTPS
Security - Security algorithms - WPA
Security - Security algorithms - WPA-PSK
Security - Security algorithms - WPA2
Security - Security algorithms - WPA2-PSK
Security - Service Set Identifier (SSID) features - Multiple SSIDs
Series - Omada
Shipping Box Depth Shipping/Package Box Dimensions - 13 cm
Shipping Box Height Shipping/Package Box Dimensions - 12 cm
Shipping box quantity - 1
Shipping Box Weight Shipping/Package Box Dimensions - 0.194 kg
Shipping Box Width Shipping/Package Box Dimensions - 4.5 cm
ShortDescription -
ShortSummaryDescription - TP-Link Omada 300Mbps Wireless N Wall-Plate Access Point, 2.4 GHz, 300 Mbit/s, 802.1x RADIUS, HTTPS, WPA, WPA-PSK, WPA2, WPA2-PSK, 10,100 Mbit/s
sizeX - 130
sizeY - 50
sizeZ - 120
Software -
Special functions - - Multi-SSID (up to 8 SSID)
- Switch Wireless
- Automatic channel selection
- Control of transmission power
- QoS (WMM)
- Balancing bandwidth
- Schedule restart
- Schedule a wireless network
- Statistics wireless network based on the SSID/AP/Client
Standards - 802.3af
Standards - 802.11b
Standards - 802.11g
Standards - 802.11n
Stck_Kart - 36
Stck_Pal - 0
Storno - Y
Sustainability - Sustainability compliance - Yes
System Requirements -
Technical details > Gross weight - 0.59 kg
Technical details > Net weight - 0.33 kg
Technical details > Producer - TP-LINK
Technical_details - LAN: 2x 100Base-TX (PoE-PD) Wireless: WLAN 802.11b/?g/?n Transfer rate: 300Mbps (2.4GHz) Security: 64/?128/?152bit WEP, WPA, WPA2 Antennas: internal Connectors: not available Power consumption: 3W (operation) Dimensions: 87x87x30mm Special features: VLAN Warranty: three years
Title - TP-Link Omada 300Mbps Wireless N Wall-Plate Access Point
Unit Box Height - 0.12
Unit Box Length - 0.13
Unit Box Width - 0.045
Unit Brutto Volume - 0.000702 cubm
Unit Gross Weight - 0.194 kg
Unit Net Weight - 0.16 kg
URL - https://www.tp-link.com.au/products/details/cat-5694_EAP115-Wall.html
Vendor Homepage - www.tp-link.com.au/products/details/EAP115-Wall.html
vendpn - EAP115-Wall
Warranty - 60
Warranty - 60 month(s)
Warranty - 60 months
WarrantyInfo -
warrantyLength - 60
warrantyType - G
Weight - 0,22
weight - 224
Weight & dimensions - Depth - 86.8 mm
Weight & dimensions - Height - 30.2 mm
Weight & dimensions - Width - 86.8 mm
Wireless Frequency Range - 2.4GHz
Wireless LAN features > Wi-Fi band - 802.11n
Wireless LAN features > Wi-Fi standards - 802.11n/g/b/a
