Accessories included -
Antenna - Built-in
Antenna - Antenna gain level (max) - 4 dBi
Antenna - Antenna type - Internal
Antenna gain - 4 dBi
Antenna type - MU-MIMO
ARTIKEL1 - WAX300H 802.11AX WIFI 6
ARTIKEL2 - ON-WALL NEBULAPRO ACCESSPOINT
Brand - Zyxel
BrandPartCode - WAX300H-EU0101F
Category - Wireless Access Points
Category 1 - Netzwerk
Category 2 - Accesspoints
Certificates - Radio FCC Part 15C FCC Part 15E ETSI EN 300 328 EN 301 893 LP0002 EN 60601-1-2 EMC FCC Part 15B EN 301 489-1 EN 301 489-17 EN55022 EN55024 EN61000-3-2/-3 BSMI CNS13438 Safety EN 60950-1 IEC 60950-1 BSMI CNS14336-1
Certification - RadioFCC Part 15C, FCC Part 15E; ETSI EN 300 328, EN 301 893;
LP0002, EN 60601-1-2EMCFCC Part 15B, EN 301 489-1; EN 301 489-17, EN55022, EN55024,
EN61000-3-2/-3, BSMI CNS13438SafetyEN 60950-1, IEC 60950-1; BSMI CNS14336-1
Color - White
Connections - Ethernet (RJ-45)
Connections - Power Port
Description - Guaranteed Strong Wi-Fi Connection in Every Corner of Your Hotel Room Greet every guest with an easy login, and flicker-free Wi-Fi is as important as a warm smile. Designed specifically for hotel rooms, Zyxel WAX300H features the latest Wi-Fi 6 technology to provide excellent performance for guests to connect to the Internet in their rooms. The AP also supports 160MHz channels, doubling the bandwidth compared to 80MHz channels to support more bandwidth-hungry applications and provide faster speeds. Outstanding Wi-Fi 6 Performance with 160MHz Channel Support The AX3000 AP (2x2:2 in 2.4GHz and 5GHz) powered by PoE delivers a maximum data rate of 3000Mbps on 160MHz channels to provide smoother and faster connectivity for hotel guests and in-room services. 3 Gigabit Downlink Ports for Connecting Devices 3 downlink ports for connecting multiple devices to the network (including one PSE downlink port supporting PoE power (5W) for wired applications when the AP is powered by 802.3at) Versatile Mounting Options The versatile yet low-profile mounting design allows the AP to blend seamlessly and tastefully into any décor, whether mounted directly on an electrical box, in a remote location, or even simply on a desk. For Desktop Mounting The ACCESSORY-ZZ0107F is a desktop mount kit that is perfectly compatible with Zyxels WAX300H AP as an additional option. Flexible Management NebulaFlex Pro allows users to switch between a standalone local controller or an intuitive Nebula cloud-managed mode as needed. Extending Modern In-Room Services with a Box The Zyxel WAX300H is not only a wireless access point but also a switch that can support a wide range of in-room services from wired to wireless without requiring additional power ports. Four Ethernet ports (1 uplink + 3 downlink) transmit data at Gigabit speeds, allowing multiple devices to connect to the network. One downlink port provides PoE power for wired services such as VoIP phones, minimizing the budget and cabling effort. Nebula WiFi Aid helps manage and provide the best Wi-Fi user experience Todays business and leisure travelers expect fast Wi-Fi connections when they enter a hotel and consider Internet connectivity as their top convenience. Nebula offers hotel IT/network administrators a powerful WiFi Aid tool that provides comprehensive data and insight into guest Wi-Fi connection issues and the ability to more proactively analyze them before guests even complain. Versatile Mounting Options The Zyxel WAX300H easily blends into any décor and can be mounted directly on an electrical box or in another hidden location, even on a desk. For the best aesthetics, the Ethernet cable can be routed out of the cable duct, making the WAX300H slim and easy to fit in tight spaces. For Desktop Mounting, the ACCESSORY-ZZ0107F is a desktop mount kit that is perfectly compatible with the Zyxel WAX300H Access Point, which is an additional option.
Description - ZYXEL WAX300H, SINGLE PACK EXCL POWER ADAPTOR, 1 YEAR NCC PRO PACK LICENSE BUNDLED, EU AND UK, UNIFIED AP,ROHS
Design - Placement - Wall
Design - Product colour - White
dimensionalWeight - 257
dimension depth - 60 mm
dimension height - 190 mm
Dimensions - 173 x 97 x 29 mm
Dimensions W x D x H, mm - 173 x 97 x 29
dimension weight - 500 g
dimension width - 120 mm
ean - 4718937632237
EANCode - 4718937632237
Environment requirements - Operational Temperature 0°C to 50°C Humidity 10% to 90% (non-condensing) Storage Temperature -40°C to 70°C Humidity 10% to 90% (non-condensing)
Ethernet LAN (RJ-45) ports quantity - 4
Features - 2.4 GHz - Yes
Features - 5 GHz - Yes
Features - 6 GHz - No
Features - Band steering - Yes
Features - Maximum data transfer rate - 2400 Mbit/s
Features - Maximum data transfer rate (2.4 GHz) - 575 Mbit/s
Features - MIMO - Yes
Features - MIMO type - Multi User MIMO
Frequency range, GHz - 2.4, 5
GRUPPE1 - Network
GRUPPE2 - Wireless Lan Broadba
GTIN - 4718937632237
guarantee - 24
guarantee_type - external
Height - 54.000000
HERSTELLER - ZYXEL
HSTNUMMER - WAX300H-EU0101F
I/O ports - 1 x 10/100/1000 Mbit/s
I/O ports - 3 x 10/100/1000 Mbit/s PoE
Length - 123.000000
LongDesc - Guaranteed strong Wi-Fi connection in every corner of your hotel roomGreet every guest with easy log-in and flicker-free WiFi is as important as warm smiles. Designed for hotel guest rooms, the Zyxel WAX300H features the latest WiFi 6 technology to provide a superb performance for in-room guests connecting online.The access point also supports the use of 160MHz channels, doubling the throughput compared to 80MHz channels to accommodate more bandwidth-hungry applications and provide faster speeds.Superb WiFi 6 performance with 160MHz channels supportAX3000 (2x2:2 in 2.4Ghz and 5Ghz) PoE-powered access point provides maximum data rate of 3000 Mbps with 160MHz channels support to enable seamless and faster connectivity for hotel guests and in-room services.Extending modern in-room services with a boxZyxel WAX300H is not only a wireless AP, but also a switch which can support a wide range of in-room services from wired to wireless without the need for extra electrical power ports.The four Ethernet ports (1 uplink + 3 downlinks) transfer data at Gigabit speeds, allowing you to connect multiple devices to your network. One of the downlink ports provides PoE power for wired services like VoIP phones to keep the budget and cabling effort to the minimum.Nebula WiFi Aid assists management and deliver the best WiFi user experienceToday’s business and leisure travelers expect to connect high-speed WiFi when stepping into a hotel and would consider internet connectivity the top amenity.Nebula offers the hotel IT/network admins a powerful tool, WiFi Aid to give comprehensive data and insights to their hotel guests’ WiFi connection issues and the ability to look into them more actively even before their guests make a complaint.Versatile mounting optionsZyxel WAX300H easily blends into tasteful decorations and can be mounted directly on an outlet box or any obscure locations, even simply on desktop.For the best aesthetics, the Ethernet cable can run out from the cable channel that keeps WAX300H slim and fit in a limited space.For desktop mount, the ACCESSORY-ZZ0107F is a desk mount kit perfectly made compatible for Zyxel’s WAX300H access point for an additional option.
LongProductName - WiFi 6 Dual-Radio NebulaFlex Pro Wall-Plate Access Point
LongSummaryDescription - Zyxel WAX300H. 2.4 GHz, 5 GHz, Maximum data transfer rate: 2400 Mbit/s. Security algorithms: WPA, WPA2, WPA3. Power over Ethernet (PoE). Product colour: White
Management, monitoring, configuration - IPv6 VLANs WMM U-APSD Management Operation Mode Cloud Nebula Managed Controller Managed Standalone ZON Tool Discover Zyxel Switches, APs and Gateways Centralized and Batch Configurations: IP Configuration Renew IP Address Reboot Device Locate Device Access Web GUI Firmware Upgrade Password Configuration Web UI/CLI
Management features - Command-line interface (CLI) - Yes
Management features - Firmware upgradeable - Yes
Manufacturer - Zyxel
Manufacturer - ZYXEL COMMUNICATIONS A/S
ManufacturerPartNumber - WAX300H-EU0101F
MPN - WAX300H-EU0101F
name - Access Point WAX300H-EU0101F
Name - Zyxel WIFI6 AX3000 WAX300H
Network architecture - GigabitEthernet
Number of antennas - 4
Operating frequency - 2,4 GHz
Operating frequency - 5 GHz
Operating temperature range (T-T), °C - 0 - 50
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 50 °C
Operational conditions - Storage relative humidity (H-H) - 10 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Other features -
PeriodofWarranty -
Ports & interfaces - Ethernet LAN (RJ-45) ports - 4
Ports & interfaces - USB 2.0 ports quantity - 1
Power - Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) Support - Yes
Power supply - PoE (802.3at): power draw 19 W(include 5W for PoE PSE)
producer - Zyxel
producerCode - WAX300H-EU0101F
productName - Acces Point Wi-Fi 6 Zyxel WAX300H 2.4GHz(2x2)/5GHz(2x2) PoE+ 4x1G
ProductName - WAX300H
productSize - Normal
Security - Encryption WPA WPA2 WPA3 Authentication IEEE 802.1X RADIUS Antenna Access Management L2 Isolation MAC Filtering Rogue AP Detection
Security - Auto Wireless Distribution System (WDS) - Yes
Security - MAC address filtering - Yes
Security - Remote Authentication Dial-In User Service (RADIUS) - Yes
Security - Security algorithms - WPA, WPA2, WPA3
Security algorithms supported - WPA/WPA2/WPA3
ShortSummaryDescription - Zyxel WAX300H, 2.4 GHz, 5 GHz, 2400 Mbit/s, WPA, WPA2, WPA3
sizeX - 195
sizeY - 55
sizeZ - 120
Software -
Special functions - Band Control WDS/Mesh*2 DCS Advanced Cell Coexistence
Standards - 802.11a
Standards - 802.11ac
Standards - 802.11ax
Standards - 802.11b
Standards - 802.11g
Standards - 802.11n
Stck_Kart - 10
Stck_Pal - 500
Storage temperature range (T-T), °C - -40 - 70
Storno - Y
System Requirements -
Title - Zyxel WAX300H 2400 Mbit/s White Power over Ethernet (PoE)
URL - https://www.zyxel.com/global/en/products/wireless/ax3000-wifi-6-dual-radio-nebulaflex-pro-wall-plate-access-point-wax300h/overview
vendpn - WAX300H-EU0101F
WarrantyInfo -
warrantyType - W
Weight - 0.490000
Weight - 310 g
weight - 490
Weight & dimensions - Depth - 120 mm
Weight & dimensions - Height - 53 mm
Weight & dimensions - Weight - 483 g
Weight & dimensions - Width - 195 mm
Weight, g - 310
Width - 193.000000
Wireless standard - 802.11 a
Wireless standard - 802.11 ac
Wireless standard - 802.11 ax
Wireless standard - 802.11 b
Wireless standard - 802.11 g
Wireless standard - 802.11 n
