Brand - GIGABYTE
BrandPartCode - GV-N3050WF2OC-6GD
Card's length - 160 to 200 mm
Category - Graphics Cards
Category 1 - Grafikkarten
Category 2 - NVidia PCI-Express Grafikkarten
Category Code - VGP
Chipset - NVIDIA GeForce RTX 3050
Cooling system - Dual Slot Fansink
CUDA Cores - 2304
Description - GeForce RTX™ 3050 WINDFORCE OC 6G - NVIDIA Ampere Streaming Multiprocessors - 2nd Generation RT Cores - 3rd Generation Tensor Cores - Powered by GeForce RTX™ 3050 - Integrated with 6GB GDDR6 96-bit memory interface - WINDFORCE cooling system - CORE CLOCK - 1477 MHz (Reference Card: 1470 MHz)
Design - Cooling technology - GIGABYTE WINDFORCE 2X
Design - Cooling type - Active
Design - Number of fans - 2 fan(s)
Design - Product colour - Black, Grey
Dimensions - 191 x 111 x 36 mm
DisplayPort Input/Output connectors - 2
EAN - 4719331354244
Full Description Line - NVIDIA GeForce RTX 3050|Graphics memory size 6 GB|GDDR6|96 bit|PCIE 4.0 16x|Memory clock 14000 MHz|GPU clock 1477 MHz|7680x4320|Cooling Dual Slot Fansink|2xHDMI|2xDisplayPort|Included Accessories Quick guide
GPU clock - 1477 MHz
Graphics connector - PCIE 4.0 16x
Graphics memory size - 6 GB
Graphics memory type - GDDR6
GTIN - 4719331354244
HDMI Input/Output connectors - 2
Included Accessories - Quick guide
LongDesc - WINDFORCE COOLING SYSTEMThe WINDFORCE cooling system features two unique blade fans, alternate spinning and 3D active fan, which together provide high efficiency heat dissipation.ALTERNATE SPINNINGReduce the turbulence of adjacent fans and increase air pressure. GIGABYTE turns the adjacent fans in the opposite direction, so that the airflow direction between the two fans is the same, reducing the turbulence and enhancing the airflow pressure.UNIQUE BLADE FANThe airflow is spilt by the triangular fan edge, and guided smoothly through the 3D stripe curve on the fan surface, effectively enhancing the airflow.3D ACTIVE FANThe 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game. It allows gamers to enjoy gameplay in complete silence when the system is running light or idle.GRAPHENE NANO LUBRICANTGraphene nano lubricant can extend the life of sleeve bearing fan by 2.1 times, close to the life of double ball bearing, and is quieter.ULTRA DURABLEULTRA COOLINGLower RDS(on) MOSFETs are specially designed to produce lower switching resistance for faster electric current charging and discharging at extremely low temperature.LOW POWER LOSSMetal Choke hold energy much longer than common iron-core chokes at high frequency, thus effectively reduce core energy loss and EMI interference.LONGER LIFELower ESR Solid Capacitors ensure better electronic conductivity for excellent system performance and longer lifespan.FRIENDLY PCB DESIGNFully automated production process ensures top quality of the circuit boards and eliminates sharp protrusions of the solder connectors seen on the conventional PCB surface. This friendly design prevents your hands from getting cut or inadvertently damaging components when making your build.GIGABYTE CONTROL CENTERGIGABYTE CONTROL CENTER (GCC) is a unified software for all GIGABYTE supported products. It provides an intuitive interface that allows users to adjust clock speed, voltage, fan mode and power target in real-time.
LongProductName - NVIDIA GeForce RTX 3050, 1477MHz, 6GB GDDR6, 96 bit, 14000MHz, PCI Express 4.0, 1 x HDMI (2.1), 1 x DP (1.4a), CUDA, DirectX 12 Ultimate, OpenGL 4.6
LongSummaryDescription - GIGABYTE GeForce RTX 3050 WINDFORCE OC 6G. Graphics processor family: NVIDIA, Graphics processor: GeForce RTX 3050, Processor frequency: 1477 MHz. Discrete graphics card memory: 6 GB, Graphics card memory type: GDDR6, Memory bus: 96 bit, Memory clock speed: 14000 MHz. Maximum resolution: 7680 x 4320 pixels. DirectX version: 12 Ultimate, OpenGL version: 4.6. Interface type: PCI Express 4.0. Cooling type: Active, Number of fans: 2 fan(s)
Manufacturer - Gigabyte
Max resolution - 7680x4320
Memory - Discrete graphics card memory - 6 GB
Memory - Graphics card memory type - GDDR6
Memory - Memory bus - 96 bit
Memory - Memory clock speed - 14000 MHz
Memory bus - 96 bit
Memory clock - 14000 MHz
Model - GV-N3050WF2OC-6GD 1.0
MPN - GV-N3050WF2OC-6GD
Name - RTX 3050 6GB Gigabyte Windforce OC GDDR6
Packaging content - User guide - Yes
Packaging data - Package type - Box
Performance - DirectX version - 12 Ultimate
Performance - Dual Link DVI - No
Performance - NVIDIA G-SYNC - Yes
Performance - OpenGL version - 4.6
Performance - TV tuner integrated - No
Ports & interfaces - DisplayPorts quantity - 1
Ports & interfaces - DisplayPort version - 1.4a
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 2.1
Ports & interfaces - Interface type - PCI Express 4.0
Power - Minimum system power supply - 300 W
Power connectors - none
Processor - CUDA - Yes
Processor - CUDA cores - 2304
Processor - Graphics processor - GeForce RTX 3050
Processor - Graphics processor family - NVIDIA
Processor - Maximum displays per videocard - 4
Processor - Maximum resolution - 7680 x 4320 pixels
Processor - Parallel processing technology support - Not supported
Processor - Processor frequency - 1477 MHz
ProductName - GeForce RTX 3050 WINDFORCE OC 6G
ShortSummaryDescription - GIGABYTE GeForce RTX 3050 WINDFORCE OC 6G, GeForce RTX 3050, 6 GB, GDDR6, 96 bit, 7680 x 4320 pixels, PCI Express 4.0
Title - GIGABYTE GeForce RTX 3050 WINDFORCE OC 6G NVIDIA 6 GB GDDR6
Unit Brutto Volume - 0.003465 cubm
Unit Gross Weight - 0.827 kg
Unit Net Weight - 0.7 kg
URL - https://www.gigabyte.com/pt/Graphics-Card/GV-N3050WF2OC-6GD#kf
Vendor Homepage - www.gigabyte.com/Graphics-Card/GV-N3050WF2OC-6GD#kf
Warranty - 36 months
WarrantyInfo -
Weight - 0.649
Weight & dimensions - Depth - 191 mm
Weight & dimensions - Height - 36 mm
Weight & dimensions - Width - 111 mm
