Accessories included -
Audio compression - G.711
BNC inputs - 4
BNC outputs - 0
Brand - Dahua Technology
BrandPartCode - DH-XVR5104HS-I3
Category - Digital Video Recorders (DVR)
Channels - 4
Connectors - 1 x HDMI
Connectors - 2 x RCA
Connectors - 2 x USB 2.0
Connectors - BNC
Connectors - RJ-45
Connectors - RS-485
Connectors - SATA
Description - XVR5104HS-I3 Dahua Technology, the world's leading intelligent video- and service provider-oriented IoT solution, has debuted a new XVR series, the XVR5000-I3 series featuring max.full-channel SMD Plus.This series has been developed to reduce false alarms and human surveillance costs, bringing great value to customers looking for products with accurate human/vehicle alarms for enhanced security of various indoor and outdoor areas.
dimensionalWeight - 1929
dimension depth - 88 mm
dimension height - 312 mm
Dimensions - 260.0 mm × 237.9 mm × 47.6 mm
dimension weight - 1386 g
dimension width - 332 mm
ean - 6939554930348
guarantee - 24
guarantee_type - normal
Hard drive - Built-in memory - No
Hard drive - HDD interface - SATA
Hard drive - Maximum HDD capacity - 16 TB
Hard drive - Number of HDDs supported - 1
HDD interface - SATA
LongDesc - Launched by Dahua Technology, WizSense is a series of AI products and solutions that adopt independent AI chip and deep learning algorithm. It focuses on human and vehicle with high accuracy, enabling users to fast act on defined targets. Based on Dahua's advanced technologies,WizSense provides intelligent, simple and inclusive products and solutions.Dahua Technology, a world-leading video-centric smart IoT solution and service provider, debuted its new XVR series, XVR5000-I3 Series featuring max.full-channel SMD Plus to benefit customers from AIupgrade (The number of channels differs depending on the model. Please refer to the specifications below for information on the number of channels.). This series has been developed to reduce false-alarm rates and the cost of human surveillance, thus bringing great value to customers in search of products with accurate human/vehicle alarm to raise the security level of various indoor and outdoor facilities.
LongProductName - 4 Channels, 1920 x 1080, RS-485, USB, HDMI, VGA, RJ-45, 1U, 1000 g
LongSummaryDescription - Dahua Technology XVR5104HS-I3. Product colour: Black, Maximum video resolution: 1920 x 1080 pixels, Video compression formats: H.264, H.264+, H.265, H.265+. Video input channels: 4 channels, Audio input: 1 RCA, Audio output: 1 RCA. Ethernet interface type: Fast Ethernet, Supported network protocols: HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; SMTP; NTP; DHCP; DNS; DDNS; P2P. HDD interface: SATA, Maximum HDD capacity: 16 TB. Power supply type: DC, DC voltage: 12 V, Power consumption (typical): 4 W
Max. capacity of disks - 16 TB
name - Hybrid recorder 4-channel XVR5104HS-I3
Network - Ethernet interface type - Fast Ethernet
Network - Ethernet LAN - Yes
Network - Ethernet LAN (RJ-45) ports - 1
Network - Supported network protocols - HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; SMTP; NTP; DHCP; DNS; DDNS; P2P
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - -10 - 55 °C
Other features - Power supply: 12 VDC, 1.5 A Power consumption: 4W Operating temperature: -10 °C to +55 °C (+14 °F to +131 °F) Operating humidity: 0%-90% (RH) Installation: desktop Certifications: FCC: Part 15 Subpart B, CE: CE-LVD: EN 60950-1/IEC 60950-1, CE-EMC: EN 61000-3-2; EN 61000-3-3; EN 55032; EN50130; EN 55024
Packaging data - Package depth - 315 mm
Packaging data - Package height - 89 mm
Packaging data - Package weight - 1.4 kg
Packaging data - Package width - 333 mm
Performance - Analog signal format system - NTSC
Performance - Analog signal format system - NTSC, PAL
Performance - Analog signal format system - PAL
Performance - Audio formats supported - G.711 A-law
Performance - Audio formats supported - G.711 A-law, G.711 μ-law, PCM
Performance - Audio formats supported - G.711 μ-law
Performance - Audio formats supported - PCM
Performance - Audio system - 2-way
Performance - Backup function - Yes
Performance - Certification - FCC: Part 15 Subpart B
CE: CE-LVD: EN 60950-1/IEC 60950-1
CE-EMC: EN 61000-3-2; EN 61000-3-3; EN 55032; EN50130; EN 55024
Performance - Certification - FCC: Part 15 Subpart BCE: CE-LVD: EN 60950-1/IEC 60950-1CE-EMC: EN 61000-3-2; EN 61000-3-3; EN 55032; EN50130; EN 55024
Performance - Channels quantity - 4 channels
Performance - Dual stream support - Yes
Performance - Maximum frame rate - 60 fps
Performance - Maximum resolution of supported cameras - 6 Mpix
Performance - Maximum video resolution - 1920 x 1080 pixels
Performance - Operating system installed - Embedded LINUX
Performance - Playback resolutions supported - 1920 x 1080, 1280 x 1024, 1280 x 720
Performance - Product colour - Black
Performance - PTZ control - Yes
Performance - Rack capacity - 1U
Performance - Supported cameras - AHD
Performance - Supported cameras - CVBS
Performance - Supported cameras - HDCVI
Performance - Supported cameras - IP
Performance - Supported cameras - TVI
Performance - Video capturing speed - 30 fps
Performance - Video compression formats - H.264
Performance - Video compression formats - H.264+
Performance - Video compression formats - H.264, H.264+, H.265, H.265+
Performance - Video compression formats - H.265
Performance - Video compression formats - H.265+
Performance - Video loss detection - Yes
Performance - Video motion detection - Yes
Performance - Video streaming - Yes
Ports & interfaces - Audio input - 1 RCA
Ports & interfaces - Audio output - 1 RCA
Ports & interfaces - BNC input ports - 4
Ports & interfaces - BNC output ports - 1
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - RS-485 ports - 1
Ports & interfaces - USB 2.0 ports quantity - 2
Ports & interfaces - VGA (D-Sub) output ports - 1
Ports & interfaces - Video input channels - 4 channels
Power - DC voltage - 12 V
Power - Power consumption (typical) - 4 W
Power - Power supply type - DC
producer - Dahua
producerCode - XVR5104HS-I3
productName - Dahua Technology XVR5104HS-I3 Black
ProductName - XVR5104HS-I3
productSize - Normal
RCA inputs - 1
RCA outputs - 1
Recording modes -
Resolution - 1280 x 720 (HD)
Resolution - 1280 x 1024 (SXGA)
Resolution - 1920 x 1080 (FHD 1080)
ShortSummaryDescription - Dahua Technology XVR5104HS-I3, Black, 1920 x 1080 pixels, H.264, H.264+, H.265, H.265+, G.711 A-law, G.711 μ-law, PCM, 30 fps, 1920 x 1080, 1280 x 1024, 1280 x 720
sizeX - 335
sizeY - 90
sizeZ - 320
Special functions -
Title - Dahua Technology XVR5104HS-I3 Black
URL - https://www.dahuasecurity.com/products/All-Products/HDCVI-Recorders/WizSense-Series/I3-Series/5M-N/1080P-Series/XVR5104HS-I3
vendpn - 6939554930348
Video compression - H.264
Video compression - H.265
Viewing modes -
WarrantyInfo -
warrantyLength - 36
warrantyType - G
Weight - 1.4 kg
weight - 1390
Weight & dimensions - Depth - 237.9 mm
Weight & dimensions - Height - 47.6 mm
Weight & dimensions - Weight - 1 kg
Weight & dimensions - Width - 260 mm
