APC Smart-UPS SCL500RMI1UNC 500VA, 400W, IEC, 1U

Accessories included - Instrukcja instalacji,  Szyny nośne do montażu w stojaku,  Kabel USB
Active power - 400 W
Apparent power - 500 VA
ARTIKEL1 - APC SMART-UPS C LI-ON 500VA
ARTIKEL2 - SHORT DEPTH 230V NETWORK CARD
Battery - Battery technology - Lithium-Ion (Li-Ion)
Battery capacity - 30 VAh
Battery life (max), years - 8-10
Battery recharge time, h - 8 - 10
Battery technology - Lithium-Ion
Battery type - Lithium Ion
Brand - APC
BrandPartCode - SCL500RMI1UNC
Category - Uninterruptible Power Supplies (UPSs)
Certification - CSA C22.2 NO. 107.3, cULus, FCC Part 15 Class A, NOM, UL 1778, UL 1973
Charging time - 3 h
Chassis type - Rack
Color - Black
Connections - RJ-45 Serial
Connections - SmartSlot
Connections - USB
Depth, mm - 232
Description - APC SMART-UPS C LITHIUM ION, SHORT DEPTH 500VA, 230V WITH NETWORK CARD
Description - Inteligentna i wydajna ochrona zasilania sieciowego od poziomu podstawowego do skalowalnego środowiska wykonawczego. Idealny UPS do serwerów, punktów sprzedaży, routerów, przełączników, koncentratorów i innych.
Design - Form factor - Rackmount/Tower
Design - Product colour - Grey
Design - Rack capacity - 1U
dimension depth - 340 mm
dimension height - 170 mm
Dimensions - 4,4 x 43,2 x 23,2 cm
dimension weight - 6500 g
dimension width - 590 mm
ean - 731304402565
EANCode - 0731304402565
Environment requirements - Temperatura robocza: 0 - 40 ° C Wilgotność względna podczas pracy: 10 - 90 (bez kondensacji)% Wysokość robocza: 0-1968.3 metrów Temperatura przechowywania: -10 - 40 ° C Wilgotność względna podczas przechowywania: 10 - 90 (bez kondensacji)% Wysokość przechowywania: 0-14763,6 metrów Hałas słyszalny w odległości 1 metra od powierzchni urządzenia: 45,0 dBA
Features - Input frequency - 47/63 Hz
Features - Input operation voltage (max) - 253 V
Features - Input operation voltage (min) - 208 V
Features - Output operation voltage (max) - 230 V
Features - Output operation voltage (min) - 230 V
Features - Output power - 400 W
Features - Output power capacity - 0.5 kVA
Features - UPS topology - Line-Interactive
Features - Waveform - Pure sine
Filters / protection - Surge
Form factor - Rack
Frequency range, Hz - 50/60
GRUPPE1 - Power Protection
GRUPPE2 - UPS (Uninterruptable Power Supply)
GTIN - 0731304402565
GTIN - 731304402565
guarantee - 60
guarantee_type - external
Height - 180.000000
Height, mm - 44
HERSTELLER - APC
HSTNUMMER - SCL500RMI1UNC
I/O connectors - 1 x RJ-45 LAN
I/O connectors - 1 x USB 2.0
Input connection - NEMA 5-15P
Input frequency, Hz - 47 - 63
Input power ports - IEC-C14
Interface - RJ45
Interface - USB
Length - 590.000000
Logistics data - Harmonized System (HS) code - 85078000
LongDesc - Always stay online and prevent data lossAs soon as the power goes out, an APC Smart-UPS immediately provides emergency power to all connected equipment. Because an APC UPS does this automatically, you prevent unwanted failure of, for example, a PC, server or switch. With the APC PowerChute Network Shutdown software you can even have critical IT hardware shut down automatically and in a controlled manner when the battery of the UPS is almost empty. This way you prevent data loss, downtime and physical damage to hardware.SafetyIn addition, a Smart-UPS protects connected devices against peak voltage caused by lightning, among other things. This APC emergency power supply is ideally suited for (small) business use.Lithium-IonThe APC SCL500RMI1UNC uses a Li-Ion (LiFePO4) battery, which provides unique advantages:- Longer lifespan. A Li-Ion battery can last up to 10 years, making the UPS truly maintenance-free.- Can handle more than 10x as many charging cycles as a lead acid battery (VRLA).- Smaller and lighter. Li-Ion batteries are smaller and weigh approximately 65% ​​less than VRLA batteries, saving space and simplifying installation.- Better battery performance than VRLA at ambient temperatures above 25° C. With VRLA this is at the expense of battery life (>5% decrease per degree increase).- 5 year manufacturer's warranty. Standard long warranty on the UPS including the battery.- Eliminate the costs of interim battery replacement; labor, materials, shipping and recycling.- Lower TCO: The above benefits reduce the total costs over the entire lifespan of the UPS by up to 47% (compared to a UPS with VRLA battery.)- Faster charging means full protection sooner.- Perfect for tight spaces, the limited depth of the ups allows it to easily fit into wall shelves and small cupboards.Battery lifeYou can easily read the expected battery life in the runtime graph, which you can find between the product images. You can easily see how long the UPS supplies emergency power at a certain load.Rack/tower/wall convertibleThe APC Smart-UPS SCL is rack/tower/wall convertible. This means that both the feet and the front post rack mounting brackets are included. This way you can mount the UPS horizontally in a rack, but also upright, i.e. vertically. This UPS is also suitable for wall mounting. The wall mount brackets make it easy to mount the UPS on the wall, for example in the meter cupboard.LongProductName - APC Smart-UPS Li-ion SCL500RMI1UNC - 4x C13, short depth, Rack/tower/wall mount, NMC, 500VA
LongSummaryDescription - APC Smart-UPS Li-ion SCL500RMI1UNC - 4x C13, short depth, Rack/tower/wall mount, NMC, 500VA. UPS topology: Line-Interactive, Output power capacity: 0.5 kVA, Output power: 400 W. AC outlet types: C13 coupler, AC outlets quantity: 4 AC outlet(s). Battery technology: Lithium-Ion (Li-Ion). Form factor: Rackmount/Tower, Product colour: Grey, Rack capacity: 1U. Width: 432 mm, Depth: 232 mm, Height: 44 mm
Manufacturer - APC
ManufacturerPartNumber - SCL500RMI1UNC
Maximum power, W - 400
name - Smart UPS SCL500RMI1UNC C 500VA/400W 1U NMC SC, AP9630, battery Li-Ion, SmartConnect
No. of batteries - 1
Noise level, dB - 45
Nominal input voltage, V - 208 - 253
Nominal output voltage, V - 120
Number of phases input - 1 (230V)
Operating relative humidity range, % - 10 - 90
Operating temperature range (T-T), °C - 0 - 40
Other features -
Output interface - 6 x NEMA 5-15R
Output power, W - 400
Output power capacity (VA) - 500
Output power ports - 4 x IEC-C13
Packaging data - Rack mount kit - Yes
PeriodofWarranty - 5 Y
Ports & interfaces - AC outlets quantity - 4 AC outlet(s)
Ports & interfaces - AC outlet types - C13 coupler
producer - APC
ProductName - APC Smart-UPS Li-ion SCL500RMI1UNC - 4x C13, short depth, Rack/tower/wall mount, NMC, 500VA
Rack height (units) - 1
ShortSummaryDescription - APC Smart-UPS Li-ion SCL500RMI1UNC - 4x C13, short depth, Rack/tower/wall mount, NMC, 500VA, Line-Interactive, 0.5 kVA, 400 W, Pure sine, 208 V, 253 V
Software -
Special functions -
Stck_Kart - 1
Stck_Pal - 8
Storage temperature range (T-T), °C - -10 - 40
Storno - N
Surge energy rating, J - 680
Technical details - Sustainability certificates - Green Premium
Title - APC Smart-UPS Li-ion SCL500RMI1UNC - 4x C13, short depth, Rack/tower/wall mount, NMC, 500VA
Transfer time (max) - 10 ms
UPS Architecture - line-interactive
UPS devices and accessories - Yes
URL -
vendpn - SCL500RMI1UNC
WarrantyInfo - 5 year repair or replace
Weight - 4.1 kg
Weight - 6.000000
Weight & dimensions - Depth - 232 mm
Weight & dimensions - Height - 44 mm
Weight & dimensions - Weight - 4.2 kg
Weight & dimensions - Width - 432 mm
Weight, kg - 4.22
Width - 340.000000
Width, mm - 432
