APC Smart-UPS SRT1000RMXLI-NC 1000VA, 1000W, IEC, 2U

Accessories included - Software CD Communication cable Power cord suitable for your country Documentation on a CD User's manual Network Management Card Clamps for mounting in industrial cabinets Equipment for mounting devices in the cabinet Mounting brackets for industrial cabinets Temperature sensor USB cable Warranty Card
Active power - 1000 W
Alarm - Audible and visible alarms prioritized by severity
Apparent power - 1000 VA
ARTIKEL1 - SMART-UPS SRT 1000VA RM 230V
ARTIKEL2 - NETWORK CARD IN
Backup time (100% load) - 8.5 min
Battery - Battery life (max) - 5 year(s)
Battery - Battery recharge time - 1 h
Battery - Battery technology - Sealed Lead Acid (VRLA)
Battery - Battery voltage - 48 V
Battery - Hot-swap battery - Yes
BatteryType -

Maintenance-free sealed Lead-Acid battery with suspended electrolyte

leakproof

Brand - APC
BrandPartCode - SRT1000RMXLI-NC
Breite - 0.61
Category - Uninterruptible Power Supplies (UPSs)
Category 1 - Energie & USV
Category 2 - USV & Stromversorgung
Charging time - 3 h
Chassis type - Rack
Color - Black
ControlPanel - Multi-function LCD status and control console
Depth - 505 mm
Description - APC SMART-UPS SRT 1000VA RM 230V NETWORK CARD
Description - APC Smart-UPS SRT 1000VA RM 230V Network Card Power protection with double conversion online with scalable sustaining time, for high density environments.
Design - Cable length - 1.5 m
Design - Certification - CE, EAC
Design - Display type - LCD
Design - Form factor - Rackmount
Design - International Protection (IP) code - IP20
Design - LED indicators - Status
Design - Product colour - Black
dimension depth - 250 mm
dimension height - 610 mm
Dimensions - 432 x 505 x 85 mm 2U
dimension weight - 46000 g
dimension width - 750 mm
ean - 731304340263
EAN - 0731304340263
EANCode - 0731304340263
Environment requirements - Operating temperature: 0 - 40 ° C Relative humidity during operation: 0 - 95% (without condensation) Height m.p. during operation: 0-3000 m Temperature (storage): (-20) - 50 ° C Relative humidity (storage): 0 - 95% (without condensation) Height m.p. (storage): 0-15000 m
Features - Audible alarm(s) - Yes
Features - Crest factor - 3:1
Features - Emergency Power Off (EPO) - Yes
Features - Input frequency - 40/70 Hz
Features - Input operation voltage (max) - 150 V
Features - Input operation voltage (min) - 50 V
Features - Output frequency - 50/60 Hz
Features - Output operation voltage (max) - 240 V
Features - Output operation voltage (min) - 220 V
Features - Output power - 1000 W
Features - Output power capacity - 1 kVA
Features - Surge energy rating - 432 J
Features - UPS topology - Double-conversion (Online)
Features - Waveform - Sine
Filters / protection - Overload
Filters / protection - Surge
Filters / protection - Voltage drop
FormFactor - Rack
Gewicht - 30.6
GrossWeight - 29.600 Kg
GRUPPE1 - Power Protection
GRUPPE2 - UPS (Uninterruptable Power Supply)
GTIN - 731304340263
GTIN - 0731304340263
guarantee - 36
guarantee_type - external
Height - 85 mm
Height - 240.000000
HERSTELLER - APC
Hoehe - 0.24
HSTNUMMER - SRT1000RMXLI-NC
I/O connectors - 1 x RJ-45 LAN
I/O connectors - 1 x USB 2.0
InputConnections -

British BS1363A

IEC-320 C14

Schuko CEE 7/EU1-16P

InputFrequency - 40 - 70 Hz (auto sensing)
Input power ports - IEC-C14
Input power ports - Type F Schuko
Input power ports - Type G British
Input power ports - Wtyczka sieciowa
InputVoltage - 230V
InterfacePorts -

RJ-45 Serial

Smart-Slot

USB

Laenge - 0.75
Length - 747.000000
Logistics data - Harmonized System (HS) code - 85078000
Logistics data - Products per pallet - 12 pc(s)
LongDesc -
LongDesc - This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. This 1000VA on-line 2U rackmount UPS provides pure sine wave power and extended runtime to support critical electronics during power disruptions. It comes with IEC 320 C14, BS1363A British and Schuko CEE 7/EU1-16P inputs, and 6x IEC 320 C13 outlets. The UPS has a preinstalled Network Management Card for UPS network-based monitoring and management. It comes with BS1363A British, IEC 60320 C20, and Schuko CEE 7/EU1-16P inputs, 6x IEC 320 C13/60320 C13 outlets. The UPS has a 3-year warranty, and the built-in lead-acid battery has a 2-year warranty. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. The UPS has a 3-year warranty, and the built-in lead-acid battery has a 2-year warranty. It conforms to CE and EAC. Designed for IT professionals or network administrators providing wide input voltage window, tight output voltage regulation, frequency regulation, internal bypass, and input power factor correction.
LongProductName - Smart-UPS On-Line, 1000VA/1000W, Rackmount 2U, 230V, 6x C13 IEC outlets, Network Card, Extended runtime, W/ rail kit
LongSummaryDescription - APC Smart-UPS On-Line, 1000VA/1000W, Rackmount 2U, 230V, 6x C13 IEC outlets, Network Card, Extended runtime, W/ rail kit. UPS topology: Double-conversion (Online), Output power capacity: 1 kVA, Output power: 1000 W. Serial interface type: RJ-45. Battery technology: Sealed Lead Acid (VRLA), Battery voltage: 48 V, Battery life (max): 5 year(s). Form factor: Rackmount, Product colour: Black, Cable length: 1.5 m. Width: 432 mm, Depth: 505 mm, Height: 85 mm
Manufacturer - APC
ManufacturerPartNumber - SRT1000RMXLI-NC
MANUFDATASHEET - https://www.apc.com/shop/ai/en/products/APC-Smart-UPS-SRT-1000VA-RM-230V-Network-Card/P-SRT1000RMXLI-NC
MPN - SRT1000RMXLI-NC
Name - APC Smart-UPS SRT1000RMXLI-NC On-Line 1000W 1000VA Rackmontage 2HE inkl. Netzwerkkarte
name - SRT1000RMXLI-NC SmartUP SRT1kVA/1kW 230V Rack N
No. of batteries - 1
Number of phases input - 1 (230V)
Operational conditions - Operating relative humidity (H-H) - 0 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 95%
Operational conditions - Storage temperature (T-T) - -20 - 50 °C
Other features -
OutputConnections - (6) IEC 320 C13 (Battery Backup)
OutputFrequency - 50/60Hz +/- 3 Hz
Output power ports - 6 x IEC-C13
OutputVoltage - 220 V, 240 V
PackageContents -

CD with software

Comms cable

Country-specific detachable power cord

Documentation CD

Installation guide

Network Management Card

Rack Mounting brackets

Rack mounting hardware

Rack Mounting support rails

Temperature Probe

USB cable

Warranty card

PeriodofWarranty - 2 Y
Ports & interfaces - Serial interface - Yes
Ports & interfaces - Serial interface type - RJ-45
Ports & interfaces - SmartSlot - Yes
Ports & interfaces - USB 2.0 ports quantity - 1
Ports & interfaces - USB port - Yes
PowerVAW - 1000 VA
PowerW - 1000 W
ProdDesc - APC Smart-UPS SRT 1000VA RM 230V Network Card
producer - APC
ProductName - Smart-UPS On-Line, 1000VA/1000W, Rackmount 2U, 230V, 6x C13 IEC outlets, Network Card, Extended runtime, W/ rail kit
ProductPicture - http://www.tdbaltic.ee/images/ds4/SRT1000RMXLI-NC-01.jpg
ProductPicture2 -
ProductPicture3 -
ProductPicture4 -
RechargeTime - 3 h
RJ45 - Yes
Runtime - 21.1/8.4
ShortSummaryDescription - APC Smart-UPS On-Line, 1000VA/1000W, Rackmount 2U, 230V, 6x C13 IEC outlets, Network Card, Extended runtime, W/ rail kit, Double-conversion (Online), 1 kVA, 1000 W, Sine, 50 V, 150 V
SmartSlot - Yes
Software - PowerNet MIB v4.2.8
Special functions -
Stck_Kart - 1
Stck_Pal - 1
Storno - Y
Technical details - Compliance certificates - RoHS
Technical details - Sustainability certificates - Green Premium
Title - APC Smart-UPS On-Line, 1000VA/1000W, Rackmount 2U, 230V, 6x C13 IEC outlets, Network Card, Extended runtime, W/ rail kit
Topology - Online
UPS Architecture - on-line double conversion
UPS devices and accessories - Yes
URL - https://www.apc.com/
USB - Yes
vendpn - SRT1000RMXLI-NC
Voltage - 230 V
Warranty - 2 years
WarrantyInfo - 3 years
WaveformType - Sine wave
Weight - 21 kg
Weight - 21.000 Kg
Weight - 30.5
Weight - 36.000000
Weight & dimensions - Depth - 505 mm
Weight & dimensions - Height - 85 mm
Weight & dimensions - Package depth - 749 mm
Weight & dimensions - Package height - 246 mm
Weight & dimensions - Package weight - 29.6 kg
Weight & dimensions - Package width - 594 mm
Weight & dimensions - Weight - 21 kg
Weight & dimensions - Width - 432 mm
Width - 432 mm
Width - 605.000000
