APC Smart-UPS SRT6KXLI 6000VA, 6000W, IEC

Accessories included - - CD with software
- Documentation CD
- Installation guide
- Removable support feet
- Temperature Probe
- USB cable
- Warranty card
- Web/SNMP Management Card
Active power - 6000 W
Apparent power - 6 kVA
ARTIKEL1 - APC SMART-UPS SRT 6000VA 230V
ARTIKEL2 - IN
Backup time (100% load) - 1.5 min
Battery - Automatic battery test - Yes
Battery - Battery capacity - 902 VAh
Battery - Battery life (max) - 5 year(s)
Battery - Battery recharge time - 1.5 h
Battery - Battery technology - Sealed Lead Acid (VRLA)
Battery - Cold start - Yes
Battery - Hot-swap battery - Yes
Battery - Typical backup time at full load - 2.5 min
Battery - Typical backup time at half load - 8.7 min
Battery recharge time, h - 3
Brand - APC
BrandPartCode - SRT6KXLI
Category - Uninterruptible Power Supplies (UPSs)
Category 1 - Energie & USV
Category 2 - USV & Stromversorgung
Certification - CE, CE Mark
Charging time - 3 h
Chassis type - Tower
Color - Black
Connections - Contact Closure
Connections - RJ-45 10/100 Base-T
Connections - RJ-45 Serial
Connections - SmartSlot
Connections - USB
Connectors - 1 x USB (Typ B)
Connectors - RJ-45
Connectors - SmartSlot
Depth, mm - 719
Description - APC SMART-UPS SRT 6000VA 230V
Description - APC Smart-UPS SRT 6000VA 230V
APC Smart-UPS On-Line, 6000 Watts/6000 VA, input 230V /output 230V, Interface Port Contact Closure, RJ-45 10/100 Base-T, RJ-45 Serial, Smart-Slot, USB, Extended runtime model
Design - Certification - REACH, CE, CE Mark, EAC, EN/IEC 62040-1, EN/IEC 62040-2, IRAM, RCM, VDE
Design - Display type - LCD
Design - Form factor - Rackmount/Tower
Design - International Protection (IP) code - IP20
Design - LED indicators - Status
Design - Product colour - Black
Designation - CE+WEEE
dimension depth - 800 mm
dimension height - 450 mm
Dimensions - - Height: 432 mm
- Width: 174 mm
- Depth: 719 mm
dimension weight - 67000 g
dimension width - 200 mm
ean - 731304301660
EAN - 0731304301660
EANCode - 0731304301660
Environment requirements - - Operating Environment: 0 - 40 °C
- Operating Relative Humidity: 0 - 95% no %
- Operating Elevation: 0-3000 meters
- Storage Temperature: -15 - 45 °C
- Storage Relative Humidity: 0 - 95% no %
- Storage Elevation: 0-15000 meters
- Audible noise at 1 meter from surface of unit: 55.0 dBA
- Online thermal dissipation: 1300.0 BTU/hr
- Protection Class: IP 20
Features - Audible alarm(s) - Yes
Features - Auto-restart - Yes
Features - Crest factor - 3:1
Features - Efficiency - 94.4%
Features - Emergency Power Off (EPO) - Yes
Features - Input frequency - 40 - 70 Hz
Features - Input operation voltage (max) - 275 V
Features - Input operation voltage (min) - 100 V
Features - Noise level - 55 dB
Features - Number of output phases - 1
Features - Output frequency regulation - 50/60 Hz
Features - Output operation voltage (max) - 240 V
Features - Output operation voltage (min) - 220 V
Features - Output power - 6000 W
Features - Output power capacity - 6 kVA
Features - Output voltage Total Harmonic Distortion (THD) - 3%
Features - Surge energy rating - 480 J
Features - Surge protection - Yes
Features - UPS topology - Double-conversion (Online)
Features - Waveform - Sine
Form factor - Tower
Frequency range, Hz - 50/60 +/- 3
Gewicht - 55
GRUPPE1 - Power Protection
GRUPPE2 - UPS (Uninterruptable Power Supply)
GTIN - 731304301660
GTIN - 0731304301660
guarantee - 36
guarantee_type - external
Height - 630.000000
Height, mm - 432
HERSTELLER - APC
HSTNUMMER - SRT6KXLI
Input connection - Hard Wire 3 wire (1PH+N+G)
Input frequency, Hz - 45 - 65
Input power ports - Hard Wire 3-wire (1PH + N + G)
Laenge - 1
Length - 380.000000
Logistics data - Harmonized System (HS) code - 85078000
Logistics data - Products per pallet - 6 pc(s)
LongDesc - This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. This 6kVA on-line tower UPS provides pure sine wave power and extended runtime to support critical electronics during power disruptions. It comes with hard wire 3-wire (1P+N+E) input, 6x IEC 320 C13 and 4x IEC 320 C19 outlets, and 2x IEC jumper cables. The UPS has an embedded Network Management Card for UPS network-based monitoring and management. The UPS comes with PowerChute Network Shutdown that provides graceful shutdown of physical servers, virtual machines, and HCI clusters. It has an additional SmartSlot for optional accessory card such as Dry Contact I/O card. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. The UPS has a 3-year warranty, and the built-in lead-acid battery has a 2-year warranty. The UPS is compatible with SRTRK2 (4-post) and SRTRK3 (2-post) rail kits sold separately. Designed for IT professionals or network administrators providing wide input voltage window, tight output voltage regulation, frequency regulation, internal bypass, and input power factor correction.
LongProductName - Smart-UPS On-Line, 6kVA/6kW, Tower, 230V, 6x C13+4x C19 IEC outlets, Network Card+SmartSlot, Extended runtime, W/O rail kit
LongSummaryDescription - APC Smart-UPS On-Line, 6kVA/6kW, Tower, 230V, 6x C13+4x C19 IEC outlets, Network Card+SmartSlot, Extended runtime, W/O rail kit. UPS topology: Double-conversion (Online), Output power capacity: 6 kVA, Output power: 6000 W. AC outlet types: C13 coupler, C19 coupler, Power plug: Terminal, AC outlets quantity: 10 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery capacity: 902 VAh, Typical backup time at full load: 2.5 min. Form factor: Rackmount/Tower, Product colour: Black, Display type: LCD. Width: 174 mm, Depth: 719 mm, Height: 432 mm
Manufacturer - APC
ManufacturerPartNumber - SRT6KXLI
Maximum power, W - 6000
MPN - SRT6KXLI
Name - APC Smart-UPS SRT 6000 VA SRT6KXLI
name - SRT6KXLI Smart-UPS SRT 6000VA Tower 230V
Noise level, dB - 55
Nominal input voltage, V - 230 (220, 240)
Nominal output voltage, V - 230 (220, 240)
Number of phases input - 1 (230V)
Operating relative humidity range, % - 0 - 95
Operating temperature range (T-T), °C - 0 - 40
Operational conditions - Non-operating altitude - 0 - 15000 m
Operational conditions - Operating altitude - 0 - 3000 m
Operational conditions - Operating relative humidity (H-H) - 0 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 95%
Operational conditions - Storage temperature (T-T) - -15 - 45 °C
Other features - - Nominal Output Voltage: 230V
- Output Voltage Distortion: Less than 2%
- Output Frequency (sync to mains): 50/60Hz +/- 3 Hz
- Other Output Voltages: 220, 240
- Load Crest Factor: 3 : 1
- Topology: Double Conversion Online
- Waveform type: Sine wave
- Output Connections
- Bypass: Internal Bypass (Automatic and Manual)
- Nominal Input Voltage: 230V
- Input frequency: 40 - 70 Hz (auto sensing)
- Input Connections: Hard Wire 3 wire (1PH+N+G)
- Input voltage range for main operations: 160 - 275 V
- Input voltage adjustable range for mains operation: 100 - 275 (half load) V
- Other Input Voltages: 220, 240
Other features - Packaging content - Removable support feet
Web/SNMP Management Card
Output interface - 6 x IEC 320 C13, 4 x IEC 320 C19, 2 x IEC Jumpers
Output power, W - 6000
Output power capacity (VA) - 6000
Output power ports - 1 x Hard Wire 3-wire (1PH + N + G)
Output power ports - 4 x IEC-C19
Output power ports - 6 x IEC-C13
Packaging data - Cables included - USB cable
Packaging data - Quick installation guide - Yes
Packaging data - Software CD - Yes
Packaging data - Temperature sensor - Yes
Packaging data - Warranty card - Yes
PeriodofWarranty - 3 Y
Ports & interfaces - AC outlets quantity - 10 AC outlet(s)
Ports & interfaces - AC outlet types - C13 coupler, C19 coupler
Ports & interfaces - Number of output IEC jumpers - 2
Ports & interfaces - Power plug - Terminal
Ports & interfaces - Serial interface - Yes
Ports & interfaces - Serial interface type - RJ-45
Ports & interfaces - SmartSlot - Yes
Ports & interfaces - USB port - Yes
producer - APC
ProductName - Smart-UPS On-Line, 6kVA/6kW, Tower, 230V, 6x C13+4x C19 IEC outlets, Network Card+SmartSlot, Extended runtime, W/O rail kit
Runtime - 2 min (full load) / 8 min (half load)
ShortSummaryDescription - APC Smart-UPS On-Line, 6kVA/6kW, Tower, 230V, 6x C13+4x C19 IEC outlets, Network Card+SmartSlot, Extended runtime, W/O rail kit, Double-conversion (Online), 6 kVA, 6000 W, Sine, 100 V, 275 V
Software - - 10/100 BaseT Connection
- Battery failure notification
- Green mode
- LCD graphics display
- Flash upgradeable firmware
- Rack/Tower convertible
- Plug-and-Play external batteries
- Save time with easy and convenient remote accessibility.
- Low operating and maintenance costs with proven reliability and intelligent battery management.
- Avoids costly power problems by keeping your IT equipment and data protected and available.
- Peace of mind that comes with full equipment compatibility and reliability of a leader
- Cold-start capable
- Generator compatible
- Safety-agency approved
- Frequency and voltage regulation
- Resettable circuit breaker
- Input power factor correction
- Power conditioning
- Scalable runtime
- Temperature-compensated battery charging
- Automatic internal bypass
- Automatic restart of loads after UPS shutdown
- Hot-swappable batteries
- Intelligent battery management
- Automatic self-test
- User-replaceable batteries
- Disconnected battery notification
- Predicitive failure notification
- Audible alarms
- Serial connectivity
- LED status indicators
- SmartSlot
- InfraStruXure Manager Compatible
- Network manageable
Special functions - - Graficzny wyświetlacz LCD
- Połączenie typu 10/100 BaseT
- Tryb ekologiczny
- Powiadomienie o awarii akumulatora
- Automatyczny wewnętrzny tor obejściowy
- Elastyczny czas podtrzymania
- Inteligentne zarządzanie akumulatorami
- Akumulatory wymienialne przez użytkownika "na gorąco"
- Automatyczne włączenie UPS-a po powrocie zasilania
- Ładowanie akumulatorów dostosowane do temperatury
- Zarządzalne sieciowo
- Kompatybilny z InfraStruXure Manager
- Gniazdo typu SmartSlot
- Wskaźnik statusu LED
- Port szeregowy
- Akumulatory zewnętrzne typu Plug&Play
- Możliwość zastosowania w 2 wersjach
- Oprogramowanie sprzętowe w pamięci flash
- Możliwość uaktualniania oprogramowania
- Akumulatory wymienialne przez użytkownika
- Automatyczny test
- Powiadamianie o przewidywanych awariach
- Powiadomienie o rozłączeniu akumulatora
- Alarmy dźwiękowe
- Regulacja częstotliwości napięcia
- Filtrowanie napięcia
- Korekta współczynnika mocy obciążenia
- Kompatybilny z generatorem
- Możliwość zimnego startu
- Wyłącznik obwodu z możlwiością resetu
Stck_Kart - 1
Stck_Pal - 6
Storage temperature range (T-T), °C - -15 - 45
Storno - Y
Surge energy rating, J - 480
Technical details - Compliance certificates - RoHS
Technical details - Sustainability certificates - ENERGY STAR
Title - APC Smart-UPS On-Line, 6kVA/6kW, Tower, 230V, 6x C13+4x C19 IEC outlets, Network Card+SmartSlot, Extended runtime, W/O rail kit
UPS Architecture - on-line double conversion
UPS devices and accessories - Yes
URL - https://www.apc.com/
vendpn - SRT6KXLI
WarrantyInfo - 3 years
Weight - 60 kg
Weight - 60.000000
Weight & dimensions - Depth - 719 mm
Weight & dimensions - Height - 432 mm
Weight & dimensions - Package depth - 960 mm
Weight & dimensions - Package height - 370 mm
Weight & dimensions - Package weight - 67 kg
Weight & dimensions - Package width - 610 mm
Weight & dimensions - Weight - 60 kg
Weight & dimensions - Width - 174 mm
Weight, kg - 60
Width - 960.000000
Width, mm - 174
