APC Smart-UPS SRT6KRMXLI 6000VA, 6000W, IEC, 4U

Accessories included - - CD z oprogramowaniem
- Instrukcja użytkownika
- Klamry do montażu w szafach przemysłowch
- Sprzęt do montażu urządzeń w szafie
- Wsporniki montażowe do szaf przemysłowych
- Czujnik temperatury
- Karta gwarancyjna
Active power - 6000 W
Alarm - Audible and visible alarms prioritized by severity
Apparent power - 6 kVA
ARTIKEL1 - SRT6KRMXLI-6W 6KVA 230V RCK MNT
ARTIKEL1 - SRT 6000VA RM 230V
ARTIKEL2 - IN
ARTIKEL2 - WITH 6 YEAR WARRANTY PACKAGE
Battery - Automatic battery test - Yes
Battery - Battery capacity - 902 VAh
Battery - Battery life (max) - 5 year(s)
Battery - Battery recharge time - 1.5 h
Battery - Battery technology - Sealed Lead Acid (VRLA)
Battery - Cold start - Yes
Battery - Hot-swap battery - Yes
Battery - Typical backup time at full load - 2.5 min
Battery - Typical backup time at half load - 8.7 min
Battery recharge time, h - 3
BatteryType -

Maintenance-free sealed Lead-Acid battery with suspended electrolyte

leakproof

Brand - APC
BrandPartCode - SRT6KRMXLI
Breite - 0.8
Breite - 0.62
Category - Root/Accessories | Exploitation/Power supply/UPSs and power strips/UPSs
Category - Uninterruptible Power Supplies (UPSs)
Certification - CE, CE Mark
Charging time - 3 h
Chassis type - Rack
Color - Black
Connections - Contact Closure
Connections - RJ-45 10/100 Base-T
Connections - RJ-45 Serial
Connections - SmartSlot
Connections - USB
Connectors - 1 x USB (Typ B)
Connectors - RJ-45
Connectors - SmartSlot
ControlPanel - Multi-function LCD status and control console
Depth - 719 mm
Depth, mm - 719
Description - APC SMART-UPS SRT 6000VA RM 230V
Description - Zasilacz awaryjny o mocy wyjściowej 6000VA wyposażony w 6 gniazd IEC 320 C13 IEC 320 C13, 4 gniazda IEC 320 C19 IEC 320 C19 , 2 IEC Jumpers oraz Hard Wire 3-wire (H N + G). Posiada bezobsługowy szczelny akumulator kwasowo-ołowiowy z elektrolitem w postaci żelu oraz ochronę przeciwprzepięciową.
Design - Certification - REACH, CE, CE Mark, EAC, EN/IEC 62040-1, EN/IEC 62040-2, IRAM, RCM, VDE
Design - Display type - LCD
Design - Form factor - Rackmount
Design - International Protection (IP) code - IP20
Design - LED indicators - Status
Design - Product colour - Black
Design - Rack capacity - 4U
dimension depth - 620 mm
dimension height - 375 mm
Dimensions - 17.4 x 43.2 x 71.9 cm.
dimension weight - 81600 g
dimension width - 953 mm
ean - 731304308515
EAN - 0731304308515
EANCode - 0731304308515
Eans - 0731304308515
Environment requirements - - Środowisko operacyjne: 0 - 40 °C
- Wilgotność względna podczas pracy: 0 - 95% no%
- Wysokość n.p.m. podczas pracy: 0-900 metry
- Temperatura (przechowywanie): -15 - 45 °C
- Wilgotność względna (przechowywanie): 0 - 95% no%
- Wysokość n.p.m. (przechowywanie): 0-4500 metry
- Poziom hałasu w odległości 1 m od powierzchni urządzenia: 55.00 dBA
- Odprowadzanie ciepła: 1300.00 BTU/godz.
- Klasa ochrony: IP 20
Features - Audible alarm(s) - Yes
Features - Auto-restart - Yes
Features - Crest factor - 3:1
Features - Efficiency - 94.4%
Features - Emergency Power Off (EPO) - Yes
Features - Input frequency - 40 - 70 Hz
Features - Input operation voltage (max) - 275 V
Features - Input operation voltage (min) - 100 V
Features - Noise level - 55 dB
Features - Number of output phases - 1
Features - Output frequency regulation - 50/60 Hz
Features - Output operation voltage (max) - 240 V
Features - Output operation voltage (min) - 220 V
Features - Output power - 6000 W
Features - Output power capacity - 6 kVA
Features - Surge energy rating - 480 J
Features - Surge protection - Yes
Features - UPS topology - Double-conversion (Online)
Features - Waveform - Sine
Filters / protection - Surge
FormFactor - Rack
Form factor - Rack
Frequency range, Hz - 50/60 +/- 3
Gewicht - 45
Gewicht - 56
GrossWeight - 68.250 kg
Gross Weight Kg - 67
GRUPPE1 - Power Protection
GRUPPE2 - Power Equipment Accs
GRUPPE2 - UPS (Uninterruptable Power Supply)
GTIN - 731304308515
GTIN - 0731304308515
guarantee - 36
guarantee_type - external
Height - 174 mm
Height - 620.000000
Height, mm - 130
HERSTELLER - APC
Hoehe - 0.37
Hoehe - 0.53
HSTNUMMER - SRT6KRMXLI
HSTNUMMER - SRT6KRMXLI-6W
Input connection - Hard Wire 3 wire (1PH+N+G)
InputConnections - Hard Wire 3 wire (1PH+N+G)
InputFrequency - 40 - 70 Hz (auto sensing)
Input frequency, Hz - 45 - 65
InputVoltage - 230 V
InterfacePorts - Contact Closure, RJ-45 10/100 Base-T, RJ-45 Serial, Smart-Slot, USB
Laenge - 1.2
Length - 380.000000
Logistics data - Harmonized System (HS) code - 85078000
Logistics data - Products per pallet - 6 pc(s)
LongDesc -
LongDesc - APC Smart-UPS On-Line,6000 Watts /6000 VA,Input 230V /Output 230V, Interface Port Contact Closure, RJ-45 10/100 Base-T, RJ-45 Serial, Smart-Slot, USB, Extended runtime model, Rack Height 4 UIncludes: CD with software, Installation guide, Rack Mounting brackets, Rack mounting hardware, Rack Mounting support rails, Temperature Probe, Warranty card
LongProductName - Smart-UPS SRT 6000VA RM 230V
LongSummaryDescription - APC Smart-UPS On-Line. UPS topology: Double-conversion (Online), Output power capacity: 6 kVA, Output power: 6000 W. AC outlet types: C13 coupler, C19 coupler, Power plug: Terminal, AC outlets quantity: 10 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery capacity: 902 VAh, Typical backup time at full load: 2.5 min. Form factor: Rackmount, Product colour: Black, Rack capacity: 4U. Width: 432 mm, Depth: 719 mm, Height: 174 mm
Manufacturer - APC
Manufacturer Code - SRT6KRMXLI
Manufacturer Name - APC by Schneider Electric
ManufacturerPartNumber - SRT6KRMXLI
MANUFDATASHEET - http://www.apc.com/products/resource/include/techspec_index.cfm?base_sku=SRT6KRMXLI&tab=models
Maximum power, W - 6000
Name - APC Smart SRT6KRMXLI
name - SRT6KRMXLI Smart-UPS SRT 6000VA Rack 230V
No. of batteries - 1
Noise level, dB - 55
Nominal input voltage, V - 230 (220, 240)
Nominal output voltage, V - 230 (220, 240)
Number of phases input - 1 (230V)
Operating relative humidity range, % - 0 - 95
Operating temperature range (T-T), °C - 0 - 40
Operational conditions - Non-operating altitude - 0 - 15000 m
Operational conditions - Operating altitude - 0 - 3000 m
Operational conditions - Operating relative humidity (H-H) - 0 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 95%
Operational conditions - Storage temperature (T-T) - -15 - 45 °C
Other features -
Other features - Packaging content - Web/SNMP Management Card
OutputConnections -

(1) Hard Wire 3-wire (H N + G)

(6) IEC 320 C13

(4) IEC 320 C19

(2) IEC Jumpers

OutputFrequency - 50/60Hz +/- 3 Hz
Output interface - 6 x IEC 320 C13, 4 x IEC 320 C19, 2 x IEC Jumpers
Output power, W - 6000
Output power capacity (VA) - 6000
Output power ports - 1 x Hard Wire 3-wire (1PH + N + G)
Output power ports - 4 x IEC-C13
Output power ports - 6 x IEC-C13
OutputVoltage - 230 V
PackageContents -

CD with software

Installation guide

Rack Mounting brackets

Rack mounting hardware

Rack Mounting support rails

Temperature Probe

USB cable

Warranty card

Web/SNMP Management Card

Packaging data - Bracket - Yes
Packaging data - Cables included - USB cable
Packaging data - Quick installation guide - Yes
Packaging data - Rack mount kit - Yes
Packaging data - Software CD - Yes
Packaging data - Temperature sensor - Yes
Packaging data - Warranty card - Yes
PeriodofWarranty - 3 Y
Ports & interfaces - AC outlets quantity - 10 AC outlet(s)
Ports & interfaces - AC outlet types - C13 coupler, C19 coupler
Ports & interfaces - Number of output IEC jumpers - 2
Ports & interfaces - Power plug - Terminal
Ports & interfaces - Serial interface - Yes
Ports & interfaces - Serial interface type - RJ-45
Ports & interfaces - SmartSlot - Yes
Ports & interfaces - USB port - Yes
PowerVAW - 6000 VA
PowerW - 6000 W
ProdDesc - Smart-UPS SRT 6000VA RM 230V
producer - APC
Producer - APC
ProducerCode - SRT6KRMXLI
ProductName - Smart-UPS On-Line
ProductPicture - http://www.tdbaltic.ee/images/ds4/SRT6KRMXLI-01.jpg
ProductPicture2 - http://www.tdbaltic.ee/images/ds4/SRT6KRMXLI-02.jpg
ProductPicture3 - http://www.tdbaltic.ee/images/ds4/SRT6KRMXLI-03.jpg
ProductPicture4 - http://www.tdbaltic.ee/images/ds4/SRT6KRMXLI-04.jpg
Rack height (units) - 4
RechargeTime - 1.5 h
RJ45 - Yes
Runtime - -
Runtime - 2 min (full load) / 8 min (half load)
ShortDescription -
Short description - APC Smart-UPS SRT 6000 VA RM SRT6KRMXLI
ShortSummaryDescription - APC Smart-UPS On-Line, Double-conversion (Online), 6 kVA, 6000 W, Sine, 100 V, 275 V
SmartSlot - Yes
Software - PowerChute Network Shutdown v3.0.1
Special functions - Zimny start
Stck_Kart - 1
Stck_Pal - 1
Stck_Pal - 6
Storage temperature range (T-T), °C - -15 - 45
Storno - N
Storno - Y
Surge energy rating, J - 480
Technical details - Sustainability certificates - RoHS, ENERGY STAR
Title - APC Smart-UPS On-Line uninterruptible power supply (UPS) Double-conversion (Online) 6 kVA 6000 W 10 AC outlet(s)
Topology - Online
UPS Architecture - on-line
UPS devices and accessories - Yes
URL - https://www.apc.com/products/resource/include/techspec_index.cfm?base_sku=SRT6KRMXLI
USB - Yes
vendpn - SRT6KRMXLI
Voltage - 230 V
Warranty - 3 years
WarrantyInfo - 3 years
WaveformType - Sine wave
Weight - 54.5 kg
Weight - 60.000 Kg
Weight - 67.000000
Weight & dimensions - Depth - 719 mm
Weight & dimensions - Height - 174 mm
Weight & dimensions - Package depth - 960 mm
Weight & dimensions - Package height - 370 mm
Weight & dimensions - Package weight - 67 kg
Weight & dimensions - Package width - 610 mm
Weight & dimensions - Weight - 60 kg
Weight & dimensions - Width - 432 mm
Weight, kg - 60
Width - 432 mm
Width - 960.000000
Width, mm - 432
