APC Smart-UPS SMC1000I-2UC 1000VA, 600W, IEC, 2U

Accessories included - Software CD CD with documentation Installation Guide USB cable
Active power - 600 W
Alarm - Alarm when on battery : distinctive low battery alarm : configurable delays
Apparent power - 1000 VA
ARTIKEL1 - APC SMART-UPS C 1000VA LCD
ARTIKEL2 - RM 2U 230V WITH SMARTCONNECT IN
Backup time (100% load) - 9.2 min
Battery - Battery life (max) - 6 year(s)
Battery - Battery recharge time - 3 h
Battery - Battery technology - Sealed Lead Acid (VRLA)
Battery - Number of batteries supported - 1
Battery - Replacement battery cartridge - APCRBC124
Battery recharge time, h - 3
BatteryType - Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Brand - APC
BrandPartCode - SMC1000I-2UC
Breite - 0.5
Category - Root/Accessories | Exploitation/Power supply/UPSs and power strips/UPSs
Category - Uninterruptible Power Supplies (UPSs)
Category 1 - Energie & USV
Category 2 - USV & Stromversorgung
Category_1 - Network and Servers
Category_2 - Network - Network Accessories
Certification - C-tick, CE, GOST, UL 1778, VDE
Charging time - 3 h
Chassis type - Rack
Color - Black
Color - Gray
Connections - USB
ControlPanel - Multi-function LCD status and control console
Depth - 406 mm
Depth, mm - 406
Description - APC SMART-UPS C 1000VA LCD RM 2U 230V WITH SMARTCONNECT
Description - APC Smart-UPS C 1000VA LCD RM 2U 230V with SmartConnect
Intelligent and efficient power protection in networks, from the basic level to the possibility of scaling back-up time. The perfect solution for servers, POS terminals, routers, switches, hubs and other network devices.
APC SmartConnect - a function that allows you to view the UPS status via a secure internet portal. Thanks to the innovative remote monitoring interface you will receive automatic notifications, firmware updates and advanced support. The easy-to-use APC SmartConnect network communication provides additional value - and even more important - peace of mind.
Design - Cable length - 2.44 m
Design - Certification - CSA, CSA C22.2 No. 107.1, FCC Part 15 Class B, ICES-003, UL 1778, REACH
Design - Display type - LCD
Design - Form factor - Rackmount
Design - Product colour - Black
Design - Rack capacity - 2U
dimension depth - 540 mm
dimension height - 575 mm
Dimensions - 8.6 x 43.2 x 40.6 cm
dimension weight - 20700 g
dimension width - 230 mm
ean - 731304332930
EAN - 0731304332930
EANCode - 0731304332930
Eans - 731304332930
EAN_code - 0731304332930
Environment requirements - Operating temperature 0 - 40 ° C Relative humidity during operation 0 - 95% Height m.p. during operation 0-3000 meters Temperature (storage) -15 - 45 ° C Relative humidity (storage) 0 - 95% Height m.p. (storage) 0-15000 meters The noise is heard at a distance of 1 m from the surface of the device 42.0dBA Heat dissipation online 46.0BTU / hour.
Features - Audible alarm(s) - Yes
Features - Audible alarm modes - Alarm when on battery, Low battery alarm, Overload alarm
Features - Automatic Voltage Regulation (AVR) - Yes
Features - Input frequency - 50/60 Hz
Features - Input operation voltage (max) - 300 V
Features - Input operation voltage (min) - 170 V
Features - Noise level - 41 dB
Features - Output frequency - 50/60 Hz
Features - Output operation voltage (max) - 240 V
Features - Output operation voltage (min) - 220 V
Features - Output power - 600 W
Features - Output power capacity - 1 kVA
Features - Output voltage Total Harmonic Distortion (THD) - 5%
Features - Surge energy rating - 680 J
Features - Surge protection - Yes
Features - UPS topology - Line-Interactive
Features - Waveform - Sine
FormFactor - Rack
Form factor - Rack
Frequency range, Hz - 57 - 63 Hz for 60 Hz nominal
Gewicht - 21.65
GrossWeight - 20.650 kg
Gross Weight Kg - 22,33
GRUPPE1 - Power Protection
GRUPPE2 - UPS (Uninterruptable Power Supply)
GTIN - 731304332930
GTIN - 0731304332930
guarantee - 24
guarantee_type - external
Height - 86 mm
Height - 540.000000
Height, mm - 89
HERSTELLER - APC
Hoehe - 0.25
HSTNUMMER - SMC1000I-2UC
I/O connectors - 1 x RJ-45 (iLO Remote Management Network)
I/O connectors - 1 x USB (Type B)
Input connection - IEC-320 C14
InputConnections - IEC-320 C14
InputFrequency - 50/60 Hz +/- 3 Hz (auto sensing)
Input frequency, Hz - 50/60 +/- 3
Input power ports - IEC-C14
InputVoltage - 230V
Input voltage, V - 180 - 287 (170 - 300)
InterfacePorts - USB
Laenge - 0.6
Length - 250.000000
Logistics data - Harmonized System (HS) code - 85078000
Logistics data - Products per pallet - 16 pc(s)
LongDesc -
LongDesc - Certainty in your connected worldProtect your entry-level servers, small switches, networking devices, and point-of-sale (POS) equipment with the Smart-UPS SMC1000-2UC with APC SmartConnect – the first cloud enabled UPS for distributed IT. The SMC1000-2UC UPS provides backup battery power in the event of a power outage, while safeguarding your equipment from harmful power conditions, spikes and surges. The included service-free cloud monitoring feature is accessible from any internet connected device, and maximizes the life and performance of your UPS by providing proactive advice and life cycle recommendations so you can remotely monitor your power infrastructure from anywhere in the world. Automatic green mode ensures you are operating at the highest level of efficiency, and intelligent battery management maximizes performance. With a 600-watt output power capacity and six battery and surge protected outlets, this Smart-UPS is ideal for home users and small- to medium-sized businesses.The first cloud enabled UPS for distributed ITThe SMC1000-2UC comes with our innovative remote cloud monitoring solution, APC SmartConnect, a feature which allows you to view the status of your UPS on a secure web portal via any internet connected device. APC SmartConnect maximizes the life and performance of your UPS through automatic notifications, firmware updates, and advanced support.Intuitive LCD interface for status updates and configurationThe bright, easy-to-read LCD interface provides real-time status updates of your APC UPS with multiple language options, and intuitive navigation keys.Intelligent battery managementFor easy maintenance, the Smart-UPS SMC1000-2UC provides a predictive month and year when battery replacement is recommended. It also prolongs battery life by regulating the charge voltage in relation to battery temperature. Detect faulty batteries with the periodic battery self-test and disconnected battery notificationAutomatic Voltage Regulation (AVR)AVR adjusts high and low voltages to a safe level, ensuring your equipment had reliable power and preserving the life of the battery.Pure sine wave outputPure sine wave output while on battery provides the highest degree of compatibility for active PFC (power factor corrected) servers and sensitive electronics.Green mode for reduced power consumptionOperate efficiently with the Smart-UPS green mode, which allows you to conserve energy without sacrificing any protection when power quality is within optimal levels and power conditioning is not necessary.PowerChute software for safe system shutdownDesigned for exceptional usability, PowerChute Business Edition software provides safe system shutdown in the event of an extended power outage while preventing potential data corruption. Find cost savings by using PowerChute to monitor your equipment’s energy consumption.ENERGY STAR QualifiedAcknowledged for meeting standardized energy efficiency requirements and passing the program's testing, the Smart-UPS SMC1000-2UC has been recognized for its ability to save you money while protecting the environment. Any UPS that is ENERGY STAR Qualified must achieve operational efficiency in the top 25 percent of the market, thus demonstrating the ability to allow you to realize lower electrical operating costs, and a reduced carbon footprint.
LongProductName - 1 kVA, 600W, 85-136V, 50/60Hz, 680J, 432x406x86mm, 20.52kg, Black
LongSummaryDescription - APC SMC1000I-2UC. UPS topology: Line-Interactive, Output power capacity: 1 kVA, Output power: 600 W. AC outlet types: C13 coupler, Power plug: C14 coupler, AC outlets quantity: 4 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery life (max): 6 year(s), Battery recharge time: 3 h. Form factor: Rackmount, Product colour: Black, Rack capacity: 2U. Width: 432 mm, Depth: 406 mm, Height: 86 mm
Manufacturer - APC
Manufacturer Code - SMC1000I-2UC
Manufacturer Name - APC by Schneider Electric
ManufacturerPartNumber - SMC1000I-2UC
Manufacturer_code - SMC1000I-2UC
MANUFDATASHEET - http://www.apc.com/shop/hr/en/products/APC-Smart-UPS-C-1000VA-LCD-RM-2U-230V-with-SmartConnect/P-SMC1000I-2UC?isCurrentSite=true
Maximum power, W - 600
MPN - SMC1000I-2UC
Name - APC Smart-UPS 1000VA SMC1000I-2UC
Name - APC Smart-UPS Rack SMC1000I-2UC 1000VA 600W 2HE mit SmartConnect
Name - APC Smart SMC1000I-2UC
name - Uninterruptible Power Supply SMC1000I-2UC C 1kVA/600W 2U SmartConne
Noise level, dB - 42
Nominal input voltage, V - 230
Nominal output voltage, V - 230
Number of phases input - 1 (230V)
Operating relative humidity range, % - 0 - 95
Operating temperature range (T-T), °C - 0 - 40
Operational conditions - Non-operating altitude - 0 - 15000 m
Operational conditions - Operating altitude - 0 - 3000 m
Operational conditions - Operating relative humidity (H-H) - 0 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 95%
Operational conditions - Storage temperature (T-T) - -15 - 45 °C
Other features -
OutputConnections -

IEC Jumpers (Battery Backup)

IEC 320 C13 (Battery Backup)

OutputFrequency - 57 - 63 Hz for 60 Hz nominal
Output interface - 2 x IEC Jumpers (Battery Backup)
4 x IEC 320 C13 (Battery Backup)
Output power, W - 600
Output power capacity (VA) - 1000
Output power ports - 4 x IEC-C13
OutputVoltage - 230V
PackageContents -

CD with software

Documentation CD

Installation guide

Rack Mounting brackets

USB cable

Packaging data - Cables included - RJ-45, RS-232
Packaging data - Rack mount kit - Yes
Packaging data - Resource CD - Yes
Packaging data - Software CD - Yes
PeriodofWarranty - 2 Y
Ports & interfaces - AC outlets quantity - 4 AC outlet(s)
Ports & interfaces - AC outlet types - C13 coupler
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces - Number of outlets (Battery backup & protection) - 4
Ports & interfaces - Power plug - C14 coupler
Ports & interfaces - Serial interface - Yes
Ports & interfaces - Serial interface type - RS-232
Ports & interfaces - SmartSlot - Yes
Ports & interfaces - USB 2.0 ports quantity - 1
Ports & interfaces - USB port - Yes
PowerVAW - 1000 VA
PowerW - 600 W
ProdDesc - APC Smart-UPS C 1000VA LCD RM 2U 230V with SmartConnect
producer - APC
Producer - APC
ProducerCode - SMC1000I-2UC
ProductName - SMC1000I-2UC
ProductPicture - http://www.tdbaltic.ee/images/ds4/SMC1000I-2UC-01.jpg
ProductPicture2 -
ProductPicture3 -
ProductPicture4 -
Rack height (units) - 2
RechargeTime - 3hour(s)
RJ45 - -
Runtime - -
ShortDescription -
Short description - APC Smart-UPS C 1000 VA LCD RM mit SmartConnect
ShortSummaryDescription - APC SMC1000I-2UC, Line-Interactive, 1 kVA, 600 W, Sine, 170 V, 300 V
SmartSlot - -
Software -
Special functions -
Stck_Kart - 1
Stck_Pal - 8
Storage temperature range (T-T), °C - -15 - 45
Storno - Y
Surge energy rating, J - 459
Technical details - Compliance certificates - RoHS
Technical details - Sustainability certificates - ENERGY STAR, Green Premium
Title - APC SMC1000I-2UC uninterruptible power supply (UPS) Line-Interactive 1 kVA 600 W 4 AC outlet(s)
Topology - Line interactive
UPS Architecture - line-interactive
UPS devices and accessories - Yes
URL - https://www.apc.com/shop/us/en/products/APC-Smart-UPS-C-1000VA-LCD-RM-2U-120V-with-SmartConnect/P-SMC1000-2UC
USB - Yes
vendpn - SMC1000I-2UC
Warranty - -
WarrantyInfo - 2 years
WaveformType - Sine wave
Weight - 20.52 kg
Weight - 20.520 Kg
Weight - 21.96
Weight - 22.000000
Weight - 24,60
Weight & dimensions - Depth - 406 mm
Weight & dimensions - Height - 86 mm
Weight & dimensions - Package depth - 570 mm
Weight & dimensions - Package height - 235 mm
Weight & dimensions - Package weight - 20.7 kg
Weight & dimensions - Package width - 535 mm
Weight & dimensions - Weight - 20.5 kg
Weight & dimensions - Width - 432 mm
Weight, kg - 20.52
Width - 432 mm
Width - 580.000000
Width, mm - 432
