APC Smart-UPS SRT5KRMXLI 5000VA, 4500W, IEC, 3U

Accessories included - - Dokumentacja na CD
- Instrukcja użytkownika
- Klamry do montażu w szafach przemysłowch
- Sprzęt do montażu urządzeń w szafie
- Wsporniki montażowe do szaf przemysłowych
- Czujnik temperatury
- Karta gwarancyjna
Active power - 4500 W
Apparent power - 5 kVA
ARTIKEL1 - SMART-UPS SRT 5000VA 230V RACK
ARTIKEL1 - SMART UPS SRT 5000VA
ARTIKEL2 - .
ARTIKEL2 - RACK MOUNT WITH 6Y WARRANTY PACK
Battery - Automatic battery test - Yes
Battery - Battery capacity - 845 VAh
Battery - Battery life (max) - 5 year(s)
Battery - Battery recharge time - 1.5 h
Battery - Battery technology - Sealed Lead Acid (VRLA)
Battery - Cold start - Yes
Battery - Hot-swap battery - Yes
Battery - Replacement battery cartridge - APCRBC140
Battery - Typical backup time at full load - 4 min
Battery - Typical backup time at half load - 11.8 min
Battery recharge time, h - 3
Brand - APC
BrandPartCode - SRT5KRMXLI
BrandPartCode - SRT5KRMXLI-6W
Category - Root/Accessories | Exploitation/Power supply/UPSs and power strips/UPSs
Category - Uninterruptible Power Supplies (UPSs)
Category 1 - Energie & USV
Category 2 - USV & Stromversorgung
Certification - CE, CE Mark
Charging time - 3 h
Chassis type - Rack
Color - Black
Connections - Contact Closure
Connections - RJ-45 Serial
Connections - SmartSlot
Connections - USB
Connectors - 1 x USB (Typ B)
Connectors - RJ-45
Connectors - SmartSlot
Depth, mm - 719
Description - APC SMART-UPS SRT 5000VA RM 230V
Description - Zasilacz awaryjny o mocy wyjściowej 5000VA/4500W wyposażony w 6 gniazd IEC 320 C13 IEC 320 C13, 4 gniazda IEC 320 C19 IEC 320 C19 oraz 2 IEC Jumpers. Posiada bezobsługowy szczelny akumulator kwasowo-ołowiowy z elektrolitem w postaci żelu oraz ochronę przeciwprzepięciową.
Design - Certification - REACH, CE, CE Mark, EAC, EN/IEC 62040-1, EN/IEC 62040-2, IRAM, NOM, VDE
Design - Certification - REACH, CE, CE Mark, EAC, EN/IEC 62040-1, EN/IEC 62040-2, IRAM, RCM, VDE
Design - Display type - LCD
Design - Form factor - Rackmount
Design - International Protection (IP) code - IP20
Design - Product colour - Black
Design - Rack capacity - 3U
dimension depth - 620 mm
dimension height - 340 mm
Dimensions - 43.2 x 13 x 71.9 cm.
dimension weight - 67000 g
dimension width - 960 mm
ean - 731304301196
EAN - 0731304301196
EANCode - 0731304301196
EANCode - 3606481338990
Eans - 0731304301196
Environment requirements - - Środowisko operacyjne: 0 - 40 °C
- Wilgotność względna podczas pracy: 0 - 95% no%
- Wysokość n.p.m. podczas pracy: 0-900 metry
- Temperatura (przechowywanie): -15 - 45 °C
- Wilgotność względna (przechowywanie): 0 - 95% no%
- Wysokość n.p.m. (przechowywanie): 0-4500 metry
- Poziom hałasu w odległości 1 m od powierzchni urządzenia: 55.00 dBA
- Odprowadzanie ciepła: 931.00 BTU/godz.
- Klasa ochrony: IP 20
Features - Audible alarm(s) - Yes
Features - Auto-restart - Yes
Features - Crest factor - 3:1
Features - Efficiency - 94.1%
Features - Emergency Power Off (EPO) - Yes
Features - Input frequency - 40 - 70 Hz
Features - Input operation voltage (max) - 275 V
Features - Input operation voltage (min) - 100 V
Features - Input operation voltage (min) - 160 V
Features - Noise level - 55 dB
Features - Output frequency regulation - 50/60 Hz
Features - Output operation voltage (max) - 240 V
Features - Output operation voltage (min) - 220 V
Features - Output power - 4500 W
Features - Output power capacity - 5 kVA
Features - Output voltage Total Harmonic Distortion (THD) - 3%
Features - Surge energy rating - 480 J
Features - Surge protection - Yes
Features - UPS topology - Double-conversion (Online)
Features - Waveform - Sine
Filters / protection - Surge
Form factor - Rack
Frequency range, Hz - 50/60 +/- 3
Gewicht - 62
Gewicht - 67
Gross Weight Kg - 63,6
GRUPPE1 - Power Protection
GRUPPE2 - UPS (Uninterruptable Power Supply)
GTIN - 0064813389905
GTIN - 064813389905
GTIN - 731304301196
GTIN - 0731304301196
GTIN - 3606481338990
GTIN - 5054444033341
GTIN - 5415247178897
GTIN - 8592978040864
guarantee - 36
guarantee_type - external
Height - 620.000000
Height, mm - 130
HERSTELLER - APC
HSTNUMMER - SRT5KRMXLI
HSTNUMMER - SRT5KRMXLI-6W
Input connection - Hard Wire 3 wire (1PH+N+G)
Input frequency, Hz - 45 - 65
Laenge - 1
Length - 325.000000
Logistics data - Harmonized System (HS) code - 85078000
Logistics data - Products per pallet - 6 pc(s)
LongDesc - Always stay online and prevent data lossAn APC Smart-UPS On-Line always supplies perfectly clean power to all connected equipment thanks to its double conversion technology. Even power outages have no influence on this. The APC Smart-UPS On-Line then automatically supplies emergency power without having to switch. This way you prevent unwanted failure of, for example, a PC, server, storage or switch. With the included Powershute Network Shutdown software you can even have critical IT hardware shut down in an automated and controlled manner. This prevents data loss, downtime and physical damage to hardware.Extend the runtimeYou can easily increase the number of minutes that the APC SRT5KRMXLI can independently supply emergency power by connecting external battery packs (SRT192RMBP). A runtime of several hours is even possible.AvailabilityThe Smart-UPS On-Line has an internal bypass and uses double conversion, maximizing the availability and lifespan of connected hardware. It also makes the UPS compatible with an emergency power generator. The Un-Line double conversion technology ensures clean, uninterrupted power to protected equipment even when generator power is used.SafetyIn addition, a Smart-UPS On-Line protects connected devices against peak voltage caused by lightning, among other things. This APC emergency power supply is ideally suited for business use.Rack mountThe APC Smart-UPS SRT is easy to operate in the rack thanks to a tiltable graphic LCD screen. Thanks to the included 4-post rail kit, you can easily mount the UPS in a rack.Manage your Smart-UPSThanks to the integrated network card, you can easily connect the APC UPS to the network. This way you can monitor and manage the UPS remotely (SNMP) and the UPS can send a shutdown signal to multiple physical and/or virtual servers using PowerChute Network Shutdown software.PowerChute Network ShutdownPowerChute Network Shutdown is UPS management software that works with the UPS Network Management Card to protect Windows, Linux and Host ESXi, as well as hyperconverged and virtual infrastructure*. In the event of a power outage, PowerChute can properly shut down your virtual machines and the preconfigured boot sequence ensures they are turned back on.*An additional license is required for HCI and virtual machine support:1 year: SWPCNS1Y-DIGI3 years: SWPCNS3Y-DIGI5 years: SWPCNS5Y-DIGIRemote management and monitoring of your networkThe network card can be managed remotely via the easy-to-use web browser interface, remote management software EcoStruxure™ IT (SFTWES1-DIGI) or other SNMP-compatible system. Tip EcoStruxure™ IT also includes the functionalities of the support contract below.Support contractThe optional network card support contract license* ensures you are always up to date and secure and includes additional benefits such as frequent updates with:• New and improved features• Security updates• Advanced support*The above license is available in the variants:1 year: SWNMC3SU-1Y-DIGI3 years: SWNMC3SU-3Y-DIGI5 years: SWNMC3SU-5Y-DIGIExtend the lifespanThe internal battery cartridge (APCRBC140) can be replaced easily, safely and independently by the user. This without having to switch off the APC SRT5KRMXLI or connected equipment. This way you can easily and cheaply extend the lifespan of the APC Smart-UPS and your equipment always remains online.Warranty extensionThe manufacturer's warranty of the SRT5KRMXLI is 3 years, with the exception of the battery cartridge, which has a 2-year manufacturer's warranty. Both are extended by 3 years to 6 and 5 years respectively with the APC service pack (WBEXTWAR3YR-SP-05).Maximize availabilityOr instead of extending the warranty, opt for the even more complete 5-year Monitoring & Dispatch Service (WMD5YOSNBD-SP-05) to maximize the availability of your APC UPS. In addition to a 5-year warranty, it also includes 24/7 remote monitoring through the Schneider Electric Connected Services Hub and SE's on-site repair service (replacement parts, labor, installation and call-out charges).Switched Outlet Groups: Remote reboot and phased start-upThanks to the Switched Outlet Groups, it is possible to configure a phased/delayed power-on per UPS outlet group. This reduces the peak load on the UPS and brings it closer to the constant load, which limits oversizing of the UPS.It is also possible to reset a group of multiple UPS outputs and the equipment connected to them. If a network card (ap9640) is used in combination with Ecostruxure IT Expert (SFTWES1-DIGI), this can even be done remotely.You can also eliminate non-critical loads; Like this extend the runtime for critical equipment.Green PremiumThis label represents Schneider Electric's commitment to delivering products with best-in-class environmental performance. Green Premium promises to comply with the latest regulations, transparency on environmental effects and circular and low CO2 emission products.Green Premium:- Stands for an energy-efficient product that helps our customers achieve their CO2 reduction goals and save energy costs at the same time. The energy efficiency of this product is at least 10% higher than the market average.- Provides insight into the environmental effects of the product, this data is available 24/7 via the digital product environmental profile, see https://checkaproduct.se.com/- Commits to minimal use of hazardous substances within and beyond regulatory compliance (RoHS/REACh)Included in the box1x SRT5KRMXLI1x C13 to C14 power cord 1.2 meters1x C13 to C14 power cord 2 meters1x PowerChute Network Shutdown (CD)1x Installation manual1x Rack mounting brackets1x temperature sensor (AP9335T)1x USB cable1x 2.5MM to DB9 cable
LongDesc - LCD graphics displayText and mimic diagrams that display modes of operation, system parameters and alarms.10/100 BaseT ConnectionConnect the device to a network using a 10 or 100 BaseT connectionGreen modePatent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.Battery failure notificationProvides early-warning fault analysis on batteries enabling timely preventive maintenanceAutomatic internal bypassSupplies utility power to the connected loads in the event of a UPS power overload or fault.Scalable runtimeAllows additional run time to be quickly added as needed.Intelligent battery managementMaximizes battery performance, life, and reliability through intelligent, precision charging.Hot-swappable batteriesEnsures clean, uninterrupted power to protected equipment while batteries are being replacedAutomatic restart of loads after UPS shutdownAutomatically starts up the connected equipment upon the return of utility power.Temperature-compensated battery chargingProlongs battery life by regulating the charge voltage according to battery temperature.Network manageableProvides remote power management of the UPS over the network.InfraStruXure Manager CompatibleEnables centralized management via the APC InfraStruXure Manager.SmartSlotCustomize UPS capabilities with management cards.LED status indicatorsQuickly understand unit and power status with visual indicators.Serial connectivityProvides management of the UPS via a serial port.Plug-and-Play external batteriesEnsures clean, uninterrupted power to the loads when adding extra runtime to the UPS.Rack/Tower convertibleProtects the initial investment in the UPS when migrating from tower to rack-mount environment.Flash upgradeable firmwareInstall maintenance releases of firmware remotely using FTP.User-replaceable batteriesIncreases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR)Automatic self-testPeriodic battery self-test ensures early detection of a battery that needs to be replaced.Predicitive failure notificationProvides early-warning fault analysis ensuring proactive component replacement.Disconnected battery notificationWarns when a battery is not available to provide backup power.Audible alarmsProvides notification of changing utility power and UPS power conditionsFrequency and voltage regulationGives higher application availability by correcting poor frequency and voltage conditions without using the battery.Power conditioningProtects connected loads from surges, spikes, lightning, and other power disturbances.Input power factor correctionMinimizes installation costs by enabling the use of smaller generators and cabling.Generator compatibleEnsures clean, uninterrupted power to protected equipment when generator power is used.Cold-start capableProvides temporary battery power when the utility power is out.Resettable circuit breakerEasy recovery from overloads; no need to replace a fuse.Safety-agency approvedEnsures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.
LongProductName - 3U, 5000VA, 4500W, 230V, 480J, 55dBA, USB, Smart-Slot
LongProductName - APC Smart-UPS On-Line SRT5KRMXLI - 5000VA, 6x C13, 4x C19 output, rack mountable, Embedded NMC
LongSummaryDescription - APC Smart-UPS On-Line. UPS topology: Double-conversion (Online), Output power capacity: 5 kVA, Output power: 4500 W. AC outlet types: C13 coupler, C19 coupler, Power plug: Terminal, AC outlets quantity: 10 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery capacity: 845 VAh, Typical backup time at full load: 4 min. Form factor: Rackmount, Product colour: Black, Rack capacity: 3U. Width: 432 mm, Depth: 719 mm, Height: 130 mm
LongSummaryDescription - APC Smart-UPS On-Line SRT5KRMXLI - 5000VA, 6x C13, 4x C19 output, rack mountable, Embedded NMC. UPS topology: Double-conversion (Online), Output power capacity: 5 kVA, Output power: 4500 W. AC outlet types: C13 coupler, C19 coupler, Power plug: Terminal, AC outlets quantity: 10 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery capacity: 845 VAh, Typical backup time at full load: 4 min. Form factor: Rackmount, Product colour: Black, Rack capacity: 3U. Width: 432 mm, Depth: 719 mm, Height: 130 mm
Manufacturer - APC
Manufacturer Code - SRT5KRMXLI
Manufacturer Name - APC by Schneider Electric
ManufacturerPartNumber - SRT5KRMXLI
Maximum power, W - 4500
MPN - SRT5KRMXLI
Name - APC Smart-UPS SRT 5000 Rack 3HE SRT5KRMXLI 5000VA 4500W inkl. Netzwerkkarte
Name - APC Smart SRT 5000 VA RM
name - SRT5KRMXLI Smart-UPS SRT 5000VA Rack 230V
No. of batteries - 1
Noise level, dB - 55
Nominal input voltage, V - 230 (220, 240)
Nominal output voltage, V - 230 (220, 240)
Number of phases input - 1 (230V)
Operating relative humidity range, % - 0 - 95
Operating temperature range (T-T), °C - 0 - 40
Operational conditions - Non-operating altitude - 0 - 15000 m
Operational conditions - Operating altitude - 0 - 3000 m
Operational conditions - Operating relative humidity (H-H) - 0 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 95%
Operational conditions - Storage temperature (T-T) - -15 - 45 °C
Other features -
Other features - Packaging content - Web/SNMP Management Card
Output interface - 6 x IEC 320 C13, 4 x IEC 320 C19, 2 x IEC Jumpers
Output power, W - 4500
Output power capacity (VA) - 5000
Output power ports - 4 x IEC-C19
Output power ports - 6 x IEC-C13
Packaging data - Bracket - Yes
Packaging data - Quick installation guide - Yes
Packaging data - Rack mount kit - Yes
Packaging data - Temperature sensor - Yes
Packaging data - Warranty card - Yes
PeriodofWarranty - 3 Y
Ports & interfaces - AC outlets quantity - 10 AC outlet(s)
Ports & interfaces - AC outlet types - C13 coupler, C19 coupler
Ports & interfaces - Number of output IEC jumpers - 2
Ports & interfaces - Power plug - Terminal
Ports & interfaces - Serial interface - Yes
Ports & interfaces - Serial interface type - RJ-45
Ports & interfaces - SmartSlot - Yes
Ports & interfaces - USB port - Yes
producer - APC
Producer - APC
ProducerCode - SRT5KRMXLI
ProductName - APC Smart-UPS On-Line SRT5KRMXLI - 5000VA, 6x C13, 4x C19 output, rack mountable, Embedded NMC
ProductName - Smart-UPS On-Line
Runtime - 4 min (full load) / 12 min (half load)
ShortDescription -
Short description - APC Smart-UPS SRT 5000 VA RM SRT5KRMXLI
ShortSummaryDescription - APC Smart-UPS On-Line, Double-conversion (Online), 5 kVA, 4500 W, Sine, 160 V, 275 V
ShortSummaryDescription - APC Smart-UPS On-Line SRT5KRMXLI - 5000VA, 6x C13, 4x C19 output, rack mountable, Embedded NMC, Double-conversion (Online), 5 kVA, 4500 W, Sine, 100 V, 275 V
Software - PowerChute Network Shutdown v3.0.1
Special functions - Zimny start
Stck_Kart - 1
Stck_Pal - 1
Storage temperature range (T-T), °C - -15 - 45
Storno - Y
Surge energy rating, J - 480
Technical details - Sustainability certificates - RoHS, ENERGY STAR
Title - APC Smart-UPS On-Line SRT5KRMXLI - 5000VA, 6x C13, 4x C19 output, rack mountable, Embedded NMC
Title - APC Smart-UPS On-Line uninterruptible power supply (UPS) Double-conversion (Online) 5 kVA 4500 W 10 AC outlet(s)
UPS Architecture - on-line
UPS devices and accessories - Yes
URL - https://www.apc.com/products/resource/include/techspec_index.cfm?base_sku=SRT5KRMXLI&ISOCountryCode=GB
URL - https://www.apc.com/products/resource/include/techspec_index.cfm?base_sku=SRT5KRMXLI-6W
vendpn - SRT5KRMXLI
Voltage - 230 V
WarrantyInfo - 3 year warranty on the UPS (excluding battery) and 2 years on the battery (the warranty consists of replacement or repair)
WarrantyInfo - 6 year
Weight - 54.5 kg
Weight - 54.43
Weight - 67.000000
Weight & dimensions - Depth - 719 mm
Weight & dimensions - Height - 130 mm
Weight & dimensions - Package depth - 960 mm
Weight & dimensions - Package height - 330 mm
Weight & dimensions - Package weight - 66.9 kg
Weight & dimensions - Package width - 610 mm
Weight & dimensions - Weight - 54.4 kg
Weight & dimensions - Width - 432 mm
Weight, kg - 54.55
Width - 950.000000
Width, mm - 432
