Qnap TS-932PX-4G, 5-Bay + 4-Bay 2.5" Only

ARTIKEL1 - TS-932PX-4G 5+4 BAY 1.7 GHZ QC
ARTIKEL2 - 2 X 10GBE SFP+ LAN + 2 X 2.5GBE
Brand - QNAP
BrandPartCode - TS-932PX-4G
Breite - 0.35
Category - NAS & Storage Servers
Category Code - STS
Category_1 - Network and Servers
Category_2 - NAS
Code - TS-932PX-4G
CPU - AnnapurnaLabs Alpine AL324 ARM Cortex-A57 quad-core 1.7GHz processor
Description - QNAP TS-932PX The quad-core 1.7GHz TS-932PX fits nine drive bays into the size of a 5-bay NAS. With five 3.5-inch SATA 6Gb/s drive bays and four 2.5-inch SATA 6Gb/s bays, the TS-932PX provides the ability to create an HDD/SSD hybrid infrastructure to boost application performance. With two 10GbE SFP+ and two 2.5GbE LAN ports, the TS-932PX supports next-generation networks for empowering bandwidth-demanding applications and providing smoother file access and sharing. 1 Two 10GbE SFP+ and two 2.5GbE RJ45 network ports empower bandwidth-demanding tasks and accelerate file sharing. 2 HBS provides comprehensive backup and data recovery; QuDedup deduplicates the data at the source to optimize storage and bandwidth usage, while reducing backup times. 3 Snapshots record your system status, allowing you to protect files and data from accidental deletion and malware attacks. 4 Cloud storage gateways realize hybrid cloud applications by working with the cache space reserved on NAS to ensure low-latency data access to the cloud. 5 Qtier auto-tiering technology and SSD caching enable constant storage optimization. 6 Increase the storage capacity of the TS-932PX with QNAP TR RAID expansion enclosures or TL JBOD.
Design - Cable lock slot - Yes
Design - Cable lock slot type - Kensington
Design - Chassis type - Tower
Design - Cooling type - Active
Design - Fan diameter - 14 cm
Design - LED indicators - HDD, LAN, SSD, Status, USB
Design - Number of fans - 1 fan(s)
Design - Product colour - Black
Design > Chassis type - Tower
Design > Number of 2.5" bays - 4
Design > Number of 3.5" bays - 5
Desktop/pedestal Mounting Type - Yes
Dimensions - 182.7 × 224.6 × 224.1 mm
EAN - 4713213517963
EANCode - 4713213517963
EAN_code - 4713213517963
Flash memory (ROM) - 512 MB
Full Description Line - CPU AnnapurnaLabs Alpine AL324 ARM Cortex-A57 quad-core 1.7GHz processor|Drives/bays 9|Desktop/pedestal|3xUSB 3.2|2xSFP+|Memory 4 GB|DDR4|Power supply requirements External, 120 W, AC 100 to 240 V
Gewicht - 4.92
Gross Weight Kg - 4,99
GRUPPE1 - Storage
GRUPPE2 - Raid System
GTIN - 4713213517963
HDD Tray - 5x 3.5-inch+ 4 x 2.5-inch SATA 6Gb/s
HERSTELLER - QNAP
Hoehe - 0.26
HSTNUMMER - TS-932PX-4G
Laenge - 0.39
Link - https://www.qnap.com/en/product/ts-932px
Logistics data - Harmonized System (HS) code - 84714100
LongDesc - Energy-efficient Quad-core ProcessorPowered by 64-bit quad-core 1.7GHz ARM Cortex-A57 processor and 4 GB DDR4 RAM (expandable to 16 GB), the TS-932PX features is highly energy efficient without impacting system or application performance.High-speed 10GbE and 2.5GbE connectivityThe TS-932PX includes two 10GbE SFP+ and two 2.5GbE LAN RJ45 ports, providing out-of-the-box support for high-speed networking and supporting Port Trunking and Failover to reinforce your network infrastructure. QNAP also provide many other high-speed networking solutions, including 10GbE/2.5GbE managed/unmanaged switches and network adapters, allowing you to build a budget-friendly high-speed network environment.Boost NAS performance with 2.5-inch SATA SSDsSSDs can greatly improve NAS performance without requiring a heavy investment. The TS-932PX supports SSD cache technology, Qtier™ auto-tiering, and SSD over-provisioning, helping you to balance storage performance, storage allocation, and IT expenses.Protect Important Data with SnapshotsSnapshots fully record the NAS system state and metadata and can be used to quickly restore files to previously-recorded states if they are accidentally deleted/modified or if the system is compromised by ransomware. QNAP snapshots are block-based and only record modified data. Not only does this save storage space, but also reduces the time required to back up and restore data. The TS-932PX supports up to 256 snapshots per NAS and up to 64 snapshots per volume or LUN.Multi-Point File Backup, Access, and SyncThe TS-932PX supports common file sharing protocols (including SMB/CIFS, AFP and NFS) for Windows®, Mac®, and Linux®/UNIX® devices. Coupled with Qsync (a utility that transforms a QNAP NAS into a secure, high-capacity data center for file synchronization) any file uploaded to the TS-932PX becomes available for all linked devices (such as computers, laptops, and mobile devices). Hybrid Backup Sync helps you easily backup or synchronize data on the TS-932PX to another QNAP NAS, remote server, or cloud storage (including Microsoft One Drive®, Google Drive™, and Dropbox®) for disaster recovery.Smart AI Photo ManagementQuMagie integrates QuMagie Core AI image recognition technology for facial recognition, subject identification, and geotagging photos. Similar photos are categorized into People, Places, and Things albums. QuMagie also features a built-in timeline scroll, customizable folder covers, iOS® Live Photo display and a powerful search tool, to provide you with the ultimate photo management and image sharing solution.Low-latency Access to Cloud Data with Cloud Storage GatewaysBy deploying cloud storage gateways and enabling local caching on the TS-932PX, you can seamlessly use the cloud for storage, backup, and data recovery with low-latency access, providing an innovative hybrid cloud experience.HybridMount File-Based Cloud GatewayFlexibly expand your storage capacity by connecting to cloud storage. You can leverage QTS apps to manage and edit your cloud files or monitor multimedia files. HybridMount is ideal for file server online collaboration and file-level data analysis.VJBOD Cloud Block-Based Cloud GatewayVJBOD Cloud supports backing up NAS data to block-based cloud storage. Block-based data transmission uploads random data and large files to the cloud in blocks, and only block-based volume or LUN changes are transmitted. This is ideal for backing up LUN, databases, and confidential files.Easily find and automatically organize filesThe TS-932PX provides greater convenience for managing files. You can quickly find files using Qsirch and auto-archive them with Qfiling.File searchQsirch quickly finds images, music, videos, documents, emails, and other files by using keywords, colors and different filters.Auto archivingQfiling automates file organization or recycling based on self-configured rules, greatly improving work efficiency.Secure remote access to your QNAP NASUse myQNAPcloud Link to access, share, download, and manage files stored on an HQ-based NAS via the Internet. QNAP NAS also supports VPN services for remote workers to access the NAS and resources on a private network from the Internet. You can also use QVPN Device Client powered by QNAP's proprietary QBelt protocol to easily connect to your TS-932PX and use measurement tools to know the speed of your VPN connections and connection history.Flexible and economical storage expansionQNAP provides several ways to expand the storage capacity of the TS-932PX to accommodate data growth:Upgrade RAID CapacityHot-swap lower-capacity drives with larger-capacity drives to expand the TS-932PX.Attach Expansion EnclosuresConnect two expansion enclosures (4-bay TR-004, 2-bay TR-002) or one 8-bay TL-D800C JBOD and use the Storage & Snapshots Manager to handle NAS capacity expansion.Migrate to a New NASInstall your NAS hard drives into a larger QNAP NAS and retain all your existing data and configurations.Multiply Your ProductivityQVR ProBuild a secure surveillance environment without any extra software needed. Provides free embedded channels and you can also purchase QVR Pro licenses to deploy a large-scale surveillance network.Notification CenterConsolidates all QTS system events, alerts, and notifications for easy NAS management, keeping you always informed of your NAS status.Security CounselorA security portal for checking weaknesses and providing recommendations for enhancing NAS security. It also integrates anti-virus and anti-malware scanning software.
LongProductName - 5x 3.5", Alpine AL324 ARM Cortex-A57 1.7GHz, 4 GB SODIMM DDR4 (1 x 4 GB), 512 MB Flash, LAN, 120 W, AC 100 - 240 V, 182.7 x 224.6 x 224.1 mm
LongSummaryDescription - QNAP TS-932PX. Type: NAS. Chassis type: Tower. Device class: Small & Medium Business. Processor family: Annapurna Labs, Processor model: Alpine AL-324, Processor frequency: 1.7 GHz. Internal memory: 4 GB, Internal memory type: DDR4. Total installed storage capacity: 0 TB. Operating system installed: QNAP Turbo System
Manufacturer - Qnap
Manufacturer Code - TS-932PX-4G
Manufacturer Name - QNAP
Manufacturer_code - TS-932PX-4G
Memory - 4 GB
Memory - Flash memory - 512 MB
Memory - Internal memory - 4 GB
Memory - Internal memory type - DDR4
Memory - Maximum RAM supported - 16 GB
Memory - Memory form factor - SO-DIMM
Memory - Memory slots - 1
Memory > Internal memory type - DDR4
Memory > Internal RAM - 4 GB
Memory type - DDR4
Name - QNAP TS-932PX-4G 4x1.7GHz 5x3.5 - SME / Entry NAS
Name - QNAP | 9-Bay QTS NAS | TS-932PX-4G | Up to 9 HDD/SSD Hot-Swap | AnnapurnaLabs Alpine | AL324 ARM Cortex-A57 Quad-Core | Processor frequency 1.7 GHz | 4 GB | DDR4
Network - DHCP client - Yes
Network - DHCP server - Yes
Network - Dynamic DNS (DDNS) - Yes
Network - Ethernet LAN - Yes
Network - Ethernet LAN data rates - 100,1000,2500,10000 Mbit/s
Network - Ethernet LAN data rate supported (max) - 10000 Mbit/s
Network - iSCSI support - Yes
Network - Jumbo frames support - Yes
Network - Link aggregation - Yes
Network - Load balancing system - Yes
Network - Supported network protocols - FTP, SFTP, TFTP, ec, OpenVPN, QBelt
Network - Wake-on-LAN ready - Yes
Network - WLAN adapter supported - Yes
Number of drives/bays - 9
Operational conditions - Operating relative humidity (H-H) - 5 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage temperature (T-T) - -20 - 70 °C
Other features > Drive bays - 9
Other features > Ethernet LAN (RJ-45) ports - 4
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 340 mm
Package features > Gross height (mm) - 380 mm
Package features > Gross width (mm) - 250.00 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 27 pc(s)
Package features > Paper/Pasteboard - 1440.00 g
Package features > Plastic (No PET) - 160.00 g
Package features > Tare weight (kg) - 1.60 kg
Package features > Volume (m3) - 0.03 m³
Package features > WEE classification - CL109:5:2017-04-01
Package features > WEEE tax - Yes
Packaging content - External power adapter - Yes
Performance - Access Control List (ACL) - Yes
Performance - Backup features - Cloud, iSCSI LUN
Performance - Backup function - Yes
Performance - Browser supported - Apple Safari 7+, Google Chrome, Microsoft Internet Explorer 10+, Mozilla Firefox
Performance - Built-in FTP server - Yes
Performance - Buzzer - Yes
Performance - Device class - Small & Medium Business
Performance - Hot spare - Yes
Performance - Multilingual support - Yes
Performance - Noise level - 18.6 dB
Performance - On/off switch - Yes
Performance - Reset button - Yes
Performance - S.M.A.R.T. support - Yes
Performance - Security algorithms - 256-bit AES, FIPS 140-2, HTTPS, SNMPv2, SNMPv3, SSH, SSL/TLS
Performance - Share folder - CIFS/SMB
Performance - Snapshot - Yes
Performance - System log - Yes
Performance - Type - NAS
Performance - USB copy function - Yes
Performance - Web-based management - Yes
Ports & interfaces - Concurrent connections - 700
Ports & interfaces - Ethernet LAN (RJ-45) ports - 2
Ports & interfaces - Fiber optic connector - SFP+
Ports & interfaces - Fiber ports quantity - 2
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity - 3
Ports & interfaces - USB port - Yes
Ports & interfaces > Interface - 2x2.5GbE, 2x10GbE 3xUSB 3.2 Gen 1
Power - AC input frequency - 50 - 60 Hz
Power - AC input voltage - 100 - 240 V
Power - Fan voltage - 12 V
Power - Number of power supply units - 1
Power - Power supply location - External
Power - Power supply unit (PSU) capacity - 120 W
Power supply requirements - External, 120 W, AC 100 to 240 V
Processor - Processor architecture - ARM Cortex-A57
Processor - Processor cores - 4
Processor - Processor family - Annapurna Labs
Processor - Processor frequency - 1.7 GHz
Processor - Processor manufacturer - Annapurna Labs
Processor - Processor model - Alpine AL-324
Processor > Processor family - AnnapurnaLabs Alpine
Processor > Processor frequency - 1.7 GHz
Processor > Processor model - AL324 ARM Cortex-A57 Quad-Core
Producer product family - 9-Bay QTS NAS
Producer product name - TS-932PX-4G
ProductName - TS-932PX
SFP+ Input/Output connectors - 2
Shipping Box Depth Shipping/Package Box Dimensions - 34.5 cm
Shipping Box Height Shipping/Package Box Dimensions - 38 cm
Shipping box quantity - 1
Shipping Box Weight Shipping/Package Box Dimensions - 4.8 kg
Shipping Box Width Shipping/Package Box Dimensions - 25 cm
Short description - QNAP NAS TS-932PX-4G (9 Bay)
ShortSummaryDescription - QNAP TS-932PX, NAS, Tower, Annapurna Labs, Alpine AL-324, 4 GB, DDR4
Software - Linux operating systems supported - Yes
Software - Mac operating systems supported - Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina
Software - Operating system installed - QNAP Turbo System
Software - Operating system version - 5.0.0
Software - Server operating systems supported - Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Software - Windows operating systems supported - Windows 10, Windows 7, Windows 8
Stck_Kart - 2
Stck_Pal - 30
Storage - Bad block scan - Yes
Storage - Disk roaming - Yes
Storage - Hot-swap drive bays - Yes
Storage - Installed storage drive type - No
Storage - Number of storage drives supported - 9
Storage - Online RAID expansion - Yes
Storage - Online RAID migration - Yes
Storage - RAID levels - 0, 1, 5, 6, 10, 50, 60, JBOD
Storage - RAID rebuild - Yes
Storage - RAID support - Yes
Storage - Storage drive capacity - 0 GB
Storage - Storage drives installed - No
Storage - Storage drive sizes supported - 2.5,3.5"
Storage - Supported file systems - FAT32, HFS+, NTFS, ext3, ext4
Storage - Supported storage drive interfaces - Serial ATA, Serial ATA II, Serial ATA III
Storage - Supported storage drive types - HDD & SSD
Storage - Total installed storage capacity - 0 TB
Storage > Number of storage drives supported - Up to 9 HDD/SSD Hot-Swap
Storno - N
Supported drives - 3.5-inch SATA hard disk drives, 2.5-inch SATA hard disk drives, 2.5-inch SATA solid state drives, 2.5-inch solid state drives
Technical details > Gross weight - 4.8 kg
Technical details > Net weight - 3.2 kg
Technical details > Other features - Fan: 1x140mm, 12VDC, Power Supply Unit: External, 120 W, AC 100 to 240 V
Technical details > Producer - QNAP
Title - QNAP TS-932PX NAS Tower Annapurna Labs Alpine AL-324 4 GB DDR4 0 TB QNAP Turbo System Black
Unit Brutto Volume - 0.03277 cubm
Unit Gross Weight - 4.8 kg
Unit Net Weight - 3.39 kg
URL - https://www.qnap.com/en/product/ts-932px
USB 3.2 Input/Output connectors - 3
Vendor Homepage - www.qnap.com/en/product/ts-932px
Warranty - 24
Warranty - 24 month(s)
Warranty - 24 months
WarrantyInfo - 2 year
Weight - 4,94
Weight & dimensions - Depth - 224.1 mm
Weight & dimensions - Height - 182.7 mm
Weight & dimensions - Weight - 3.39 kg
Weight & dimensions - Width - 224.6 mm
