Chieftec A-80 Series, 550W

Brand - Chieftec
BrandPartCode - CTG-550C
Category - Power Supply Units
Design - Cooling type - Active
Design - Fan diameter - 12 cm
Design - Fan location - Top
Design - Number of fans - 1 fan(s)
Design - Product colour - Black
dimensionalWeight - 926
GTIN - 4710713239364
Logistics data - Harmonized System (HS) code - 84733020
LongDesc - this popular PSU series is now extended by new models featuring cable management. With many awards granted, these PSUs are perfectly suited for cost aware users, who pay attention to both good price and high efficiency.
LongProductName - 550W, 230V/6A, ATX 12V 2.3, PS II, >85%, 120mm fan
LongSummaryDescription - Chieftec CTG-550C. Total power: 550 W, AC input voltage: 230 V, AC input frequency: 50 Hz. Motherboard power connector: 20+4 pin ATX, Cabling type: Semi-Modular. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Width: 150 mm, Depth: 140 mm, Height: 87 mm
Other features - Parallel processing technology support - 2-Way CrossFireX, 2-Way SLI
Packaging data - Package type - Box
Performance - 80 PLUS certification - 80 PLUS
Performance - ATX version - 2.3
Performance - Certification - CE, CB, FCC
Performance - Mean time between failures (MTBF) - 100000 h
Performance - Parallel processing technology support - 2-Way CrossFireX
Performance - Parallel processing technology support - 2-Way SLI
Performance - Power supply unit (PSU) form factor - ATX
Performance - Purpose - PC
Performance - RoHS compliance - Y
Ports & interfaces - Cabling type - Modular
Ports & interfaces - Cabling type - Semi-Modular
Ports & interfaces - CPU P4 connector (4-pin) - 1
Ports & interfaces - EPS power connector (8-pin) - Yes
Ports & interfaces - Floppy drive power connector - 2
Ports & interfaces - Motherboard power connector - 20+4 pin ATX
Ports & interfaces - Number of SATA power connectors - 6
Ports & interfaces - PCI Express power connectors (6+2 pin) - 2
Ports & interfaces - Peripheral (Molex) power connectors (4-pin) - 4
Power - AC input frequency - 50 Hz
Power - AC input voltage - 230 V
Power - Combined power (+3.3V) - 130 W
Power - Combined power (+5V) - 130 W
Power - Combined power (+5Vsb) - 15 W
Power - Combined power (+12V) - 456 W
Power - Combined power (-12V) - 3.6 W
Power - Efficiency - 85%
Power - Input current - 6 A
Power - Maximum input current (@110V) - +12V1,+12V2,+3.3V,+5V,+5Vsb,-12V
Power - Max output current (+3.3V) - 25 A
Power - Max output current (+5V) - 22 A
Power - Max output current (+5Vsb) - 3 A
Power - Max output current (+12V1) - 25 A
Power - Max output current (+12V2) - 25 A
Power - Max output current (-12V) - 0.3 A
Power - Power factor - 0.9
Power - Power Factor Correction (PFC) type - Active
Power - Power protection features - Over current
Power - Power protection features - Over current, Over voltage, Overheating, Overload, Short circuit, Under voltage
Power - Power protection features - Overheating
Power - Power protection features - Overload
Power - Power protection features - Over voltage
Power - Power protection features - Short circuit
Power - Power protection features - Under voltage
Power - Total power - 550 W
producerCode - CTG-550C
productName - Chieftec CTG-550C power supply unit 550 W ATX Black
ProductName - CTG-550C
productSize - Normal
ShortSummaryDescription - Chieftec CTG-550C, 550 W, 230 V, 50 Hz, 6 A, +12V1,+12V2,+3.3V,+5V,+5Vsb,-12V, Active
sizeX - 180
sizeY - 105
sizeZ - 245
Technical details - Compliance certificates - RoHS
Title - Chieftec CTG-550C power supply unit 550 W 20+4 pin ATX ATX Black
URL - https://www.chieftec.eu/en/psus/a-80-series/ctg-550c.html
WarrantyInfo - 2 year
warrantyLength - 24
warrantyType - R
weight - 2348
Weight & dimensions - Depth - 140 mm
Weight & dimensions - Height - 87 mm
Weight & dimensions - Width - 150 mm
