FSP SFX PRO, 450W, 80PLUS Bronze

Brand - FSP
BrandPartCode - PPA450AA00
Category - Power Supply Units
Category 1 - Netzteile
Certificates > Certification - Bronze
Code - SFX PRO 450
Design - Cooling type - Active
Design - Fan diameter - 8 cm
Design - Fan location - Top
Design - Number of fans - 1 fan(s)
Design - On/off switch - Yes
Design - Product colour - Black
EAN - 4713224522123
GTIN - 4713224522123
Logistics data - Harmonized System (HS) code - 84733020
LongDesc - The SFX PRO series is a dream PSU that’s designed to deliver the best power, performance and efficiency to every mini PC enthusiast. Featuring the 80 Plus bronze certified efficiency, IEC62368 certified safety regulation, DC-DC Module, and black ribbon cables, the SFX PRO series came to the world with a mission “Never Let You Down” to provide users a stylish mini PC look as well as the best PC gaming experience!Intelligent Fan Speed ControlSFX Pro’s sleeve fan will automatically adjust its fan speed according to the PSU’s temperature. This helps to provide excellent airflow and low noise operation.80 Plus® Bronze CertificationSFX Pro series features 80 PLUS Bronze certification, saving energy through its high efficiency rating up to 85%.DC-to-DC Module DesignWith DC to DC structure, SFX Pro Series ensure you the outstanding conversion efficiency and offers reliability and stability.Compliant with IEC/EN 62368FSP complies with the latest green power technology, and provides a full array of additional safety approvals to keep designs ahead of the changing regulations. FSP has upgraded the majority of their power supplies to comply with the new IEC/EN 62368 standard for your gaming rig.All Black Ribbon CablesThe matte black coating and all black ribbon cables give your system a sophisticated look.SFX to ATX Adapter BracketAdapts to your individual requirements, not only does it fit into cases with the SFX form factor, but also it can be installed simply into regular ATX, Micro-ATX or Mini-ITX cases.Universal Use, Wide Input Range Power SupplyWide input voltage 100-240V, can ensure the stability of the system when the input voltage is not stable.
LongProductName - 450W, 80 PLUS Bronze, SFX12V, 80mm
LongSummaryDescription - FSP SFX PRO 450W. Total power: 450 W, AC input voltage: 100 - 240 V, AC input frequency: 50 - 60 Hz. Motherboard power connector: 24-pin ATX, Cabling type: Non-Modular. Purpose: PC, Power supply unit (PSU) form factor: SFX, 80 PLUS certification: 80 PLUS Bronze. Product colour: Black, Cooling type: Active, Fan diameter: 8 cm. Width: 100 mm, Depth: 125 mm, Height: 63 mm
Manufacturer - FSP
MPN - PPA450AA00
Name - Fortron | PSU | SFX PRO 450 | 450 W
Name - SFX 450W FSP SFX PRO 450
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 125.00 mm
Package features > Gross depth master carton - 565 mm
Package features > Gross height (mm) - 63.00 mm
Package features > Gross height master carton - 215 mm
Package features > Gross width (mm) - 100.00 mm
Package features > Gross width master carton - 365 mm
Package features > Net weight master carton - 11.892 kg
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 549 pc(s)
Package features > Paper/Pasteboard - 480.00 g
Package features > Plastic (No PET) - 120.00 g
Package features > Tare weight (kg) - 0.60 kg
Package features > Tare weight master carton - 0.754 kg
Package features > Volume (m3) - 0.00 m³
Package features > WEE classification - CL109:5:2017-04-01
Package features > WEEE tax - Yes
Performance - 80 PLUS certification - 80 PLUS Bronze
Performance - Bearing technology - Rifle
Performance - Mean time between failures (MTBF) - 100000 h
Performance - Noise level - 43 dB
Performance - Power supply unit (PSU) form factor - SFX
Performance - Purpose - PC
Ports & interfaces - Cabling type - Non-Modular
Ports & interfaces - CPU power connector (4+4 pin) - Yes
Ports & interfaces - Floppy disk drive connector - Yes
Ports & interfaces - Floppy drive power connector - 1
Ports & interfaces - Motherboard power connector - 24-pin ATX
Ports & interfaces - Number of SATA power connectors - 3
Ports & interfaces - PCI Express power connectors (6+2 pin) - 2
Ports & interfaces - Peripheral (Molex) power connectors (4-pin) - 3
Power - AC input frequency - 50 - 60 Hz
Power - AC input voltage - 100 - 240 V
Power - Combined power (+3.3V) - 85 W
Power - Combined power (+5V) - 85 W
Power - Combined power (+5Vsb) - 12.5 W
Power - Combined power (+12V) - 450 W
Power - Combined power (-12V) - 3.6 W
Power - Efficiency - 85%
Power - Maximum input current (@110V) - 6 A
Power - Maximum input current (@220V) - 2.5 A
Power - Max output current (+3.3V) - 16 A
Power - Max output current (+5V) - 16 A
Power - Max output current (+5Vsb) - 2.5 A
Power - Max output current (+12V) - 37.5 A
Power - Max output current (-12V) - 0.3 A
Power - Power Factor Correction (PFC) type - Active
Power - Power protection features - Over current, Over power, Over voltage, Overheating, Short circuit
Power - Total power - 450 W
Power > Nominal power - 450 W
Producer product family - PSU
Producer product name - SFX PRO 450
ProductName - SFX PRO 450W
ShortSummaryDescription - FSP SFX PRO 450W, 450 W, 100 - 240 V, 50 - 60 Hz, 6 A, 2.5 A, Active
Technical details > Gross weight - 1.82 kg
Technical details > Net weight - 1.22 kg
Technical details > Other features - Fan Type: Rifle, 80mm; Protection OCP/OVP/SCP/ OPP/ OTP
Technical details > Producer - Fortron
Title - FSP SFX PRO 450W power supply unit 24-pin ATX Black
URL - https://www.fsplifestyle.com/PROP195003557/
Warranty - 24
Warranty - 24 month(s)
WarrantyInfo -
Weight - 1.3
Weight & dimensions - Depth - 125 mm
Weight & dimensions - Height - 63 mm
Weight & dimensions - Weight - 1.22 kg
Weight & dimensions - Width - 100 mm
