Noctua NH-U14S TR4-SP3

category - Aircooling|Coolers|CPU Coolers|AMD|Socket Threadripper
Category - Root/Electronics/PC parts/Cooling/Processor fans
Category_1 - Computer Cases and Cooling
Category_2 - Coolers for CPU
code - NH-U14S TR4-SP3
Design - Fan connector - 4-pin
Design - Fins material - Aluminium
Design - Material - Copper
Design - Number of fan blades - 7
Design - Number of fans - 1 fan(s)
Design - Product colour - Aluminium
Design - Product colour - Beige
dimensionalWeight - 1113
ean - 9010018000108
Eans - 9010018000108
EAN_code - 9010018000108
Logistics data - Master (outer) case gross weight - 13 kg
Logistics data - Products per master (outer) case - 8 pc(s)
Manufacturer - Noctua
Manufacturer_code - NH-U14S TR4-SP3
Name - Noctua NH-U14S TR4-SP3
name - Noctua NH-U14S TR4-SP3 CPU-Kühler - 140mm
Other features - Heatsink dimensions (W x D x H) - 150 x 52 x 165 mm
Other features - Mean time to failure (MTTF) - 150000 h
Packaging content - Low-noise adaptor (LNA) - Yes
Performance - Airflow - 140.2 m³/h
Performance - Airflow with LNA (max) - 115.5 m³/h
Performance - Bearing type - Self-Stabilising Oil-pressure Bearing (SSO)
Performance - Compatible processor series - AMD Ryzen
Performance - Fan diameter - 14 cm
Performance - Noise level (high speed) - 19.2 dB
Performance - Noise level with LNA (max) - 24.6 dB
Performance - Rotational speed (max) - 1500 RPM
Performance - Rotational speed (min) - 300 RPM
Performance - Rotational speed with LNA (max) - 1200 RPM
Performance - Suitable for - Processor
Performance - Supported processor sockets - Socket SP3
Performance - Supported processor sockets - Socket TR4
Performance - Type - Cooler
Power - Power supply - 1.56 W
Power - Voltage - 12 V
Producer - Noctua
producerCode - NH-U14S TR4-SP3
ProducerCode - NH-U14S TR4-SP3
productName - Noctua NH-U14S TR4-SP3 computer cooling component Processor Cooler 14 cm Aluminium, Beige (sTRX4, sWRX8, TR4, SP3)
productSize - Normal
ShortDescription - Chłodzenie CPU|150 PWM|
sizeX - 230
sizeY - 220
sizeZ - 110
Technical_details - Design: Tower cooler Dimensions (WxHxD): 150x165x78mm Fan(s): 140x140x25mm, 300-1500rpm, 140.2m3/?h, 24.6dB(A) Weight: 1.03kg Connector: 4-Pin PWM Socket: TR4, SP3 Special features: 6 heatpipes, nickel-plated Warranty: six years
warrantyLength - 72
warrantyType - F
Weight - 1,48
weight - 1490
Weight & dimensions - Depth - 78 mm
Weight & dimensions - Fan dimensions (W x D x H) - 140 x 150 x 25 mm
Weight & dimensions - Heatsink weight - 865 g
Weight & dimensions - Height - 165 mm
Weight & dimensions - Package depth - 113 mm
Weight & dimensions - Package height - 217 mm
Weight & dimensions - Package weight - 1.5 kg
Weight & dimensions - Package width - 226 mm
Weight & dimensions - Weight - 1.03 kg
Weight & dimensions - Width - 150 mm
