100 mm x 100 mm VESA mounting interface - Yes
200 mm x 100 mm VESA mounting interface - Yes
200 mm x 200 mm VESA mounting interface - Yes
300 mm x 200 mm VESA mounting interface - Yes
300 mm x 300 mm VESA mounting interface - Yes
400 mm x 200 mm VESA mounting interface - Yes
400 mm x 300 mm VESA mounting interface - Yes
400 mm x 400 mm VESA mounting interface - Yes
Accessories included -
Brand - Neomounts
BrandPartCode - WL40-550BL14
Category - TV Mounts & Stands
Category Code - MAS
Color - Black
Colour - Black
Corner mount - No
Description - NEOMOUNTS BY NEWSTAR SCREEN WALL MOUNT (FULL MOTION, 3 PIVOTS, VESA 400X400)
Description - Neomounts by Newstar tv wall mount Neomounts by Newstar WL40-550BL14 full motion wall mount for 32-55" screens - Black The Neomounts by Newstar WL40-550BL14 is a full motion wall mount for flat screens up to 55" with a maximum weight capacity of 35 kg. The versatile tilt (14°) and swivel (40°) technology allows you to create the optimum viewing angle. The mount can be levelled for the perfect installation. The WL40-550BL14 has a depth of 4,5-42 cm and is suitable for screens that meet VESA hole pattern 100x100 to 400x400 mm. The mount features a nifty Easy-release system, that allows you to attach the TV in a wink of an eye. The mount is equipped with cable management, to secure any loose cables on the back of the screen.
Description - Neomounts by Newstar WL40-550BL14 is a Full Motion wall mount for flat panel monitors up to 55 with a maximum load capacity of 35kg. The versatile tilt (14°) and swivel (40°) technology allows for an optimal viewing angle. The bracket can be levelled for perfect installation. The WL40-550BL14 has a depth of 4.5-42 cm and is suitable for screens meeting VESA 100x100 to 400x400 mm requirements.
Design - Housing material - Steel
Design - Product colour - Black
dimension depth - 60 mm
dimension height - 330 mm
Dimensions -
dimension weight - 4535 g
dimension width - 315 mm
Distance to wall - 42 cm
ean - 8717371448714
Ergonomics - Angle of rotation - 6°
Ergonomics - Cable management - Yes
Ergonomics - Distance to the wall (max) - 42 cm
Ergonomics - Distance to the wall (min) - 4.5 cm
Ergonomics - Height adjustment - No
Ergonomics - Pivot angle - -3 - 3°
Ergonomics - Rotating - Yes
Ergonomics - Swivel angle - 40°
Ergonomics - Swivel angle range - 0 - 40°
Ergonomics - Swivelling - Yes
Ergonomics - Tilt adjustment - Yes
Ergonomics - Tilt angle range - -2 - 12°
Ergonomics - Type - Full motion
Fits screens sized - 32-55"
Full Description Line - Max. weight 35 kg|Fits screens sized 32-55"|Distance to wall 42 cm|100 mm x 100 mm|200 mm x 100 mm|200 mm x 200 mm|300 mm x 200 mm|300 mm x 300 mm|400 mm x 200 mm|400 mm x 300 mm|400 mm x 400 mm|Colour Black
GTIN - 8717371448714
guarantee - 60
guarantee_type - normal
Height - 313.000000
Horizontal adjustment - 40 °
Length - 56.000000
Load (max) - 35 kg
Logistics data - Harmonized System (HS) code - 7326909890
Logistics data - Master (outer) case gross weight - 22.7 kg
Logistics data - Master (outer) case height - 330 mm
Logistics data - Master (outer) case length - 295 mm
Logistics data - Master (outer) case net weight - 21 kg
Logistics data - Master (outer) case width - 349 mm
Logistics data - Products per master (outer) case - 5 pc(s)
Logistics data - Products per pallet (EU) - 160 pc(s)
LongDesc - The Neomounts WL40-550BL14 LEVEL is a full motion wall mount for flat screens up to 55" with a maximum weight capacity of 35 kg. The versatile tilt (14°) and swivel (40°) technology allows you to create the optimum viewing angle. The mount can be levelled for the perfect installation. The LEVEL-550 wall mount has a depth of 4,5-42 cm and is suitable for screens that meet VESA hole pattern 100x100 to 400x400 mm. The WL40-550BL14 features a nifty Easy-release system, that allows you to attach the TV in a wink of an eye. The mount is equipped with cable management, to secure any loose cables on the back of the screen.
LongProductName - Neomounts WL40-550BL14 full motion wall mount for 32-55" screens - Black
LongSummaryDescription - Neomounts tv wall mount. Maximum weight capacity: 35 kg, Minimum screen size: 81.3 cm (32"), Maximum screen size: 139.7 cm (55"), Minimum VESA mount: 100 x 100 mm, Maximum VESA mount: 400 x 400 mm. Tilt angle range: -2 - 12°, Swivel angle range: 0 - 40°, Angle of rotation: 6°, Distance to the wall (min): 4.5 cm, Distance to the wall (max): 42 cm. Product colour: Black
Manufacturer - NEOMOUNTS
ManufacturerPartNumber - WL40-550BL14
Max. weight - 35 kg
Mounting - Maximum screen size - 139.7 cm (55")
Mounting - Maximum VESA mount - 400 x 400 mm
Mounting - Maximum weight capacity - 35 kg
Mounting - Minimum screen size - 81.3 cm (32")
Mounting - Minimum VESA mount - 100 x 100 mm
Mounting - Mounting type - Wall
Mounting - Number of displays supported - 1
Mounting - Panel mounting interface - 100 x 100,200 x 100,200 x 200,200 x 300,200 x 400,300 x 200,300 x 300,400 x 200,400 x 300,400 x 400
name - Wall bracket WL40-550BL14 32-55 inch
Number of screens - 1
Other features -
Packaging content - Mounting kit - Yes
Packaging data - Package depth - 310 mm
Packaging data - Package height - 55 mm
Packaging data - Package width - 329 mm
PeriodofWarranty - 5 Y
producer - Neomounts
ProductName - Neomounts tv wall mount
Range (max) - 42 cm
Range (min) - 4.5 cm
Range adjustment - Yes
Screen size (max) - 55 ''
Screen size (min) - 32 ''
Shipping Box Depth Shipping/Package Box Dimensions - 34 cm
Shipping Box Height Shipping/Package Box Dimensions - 31 cm
Shipping box quantity - 1
Shipping Box Weight Shipping/Package Box Dimensions - 4.526 kg
Shipping Box Width Shipping/Package Box Dimensions - 6 cm
Short summary - Neomounts by Newstar WL40-550BL14 full motion wall mount for 32-55" screens - Black
ShortSummaryDescription - Neomounts tv wall mount, 100 x 100 mm, 400 x 400 mm, -2 - 12°, 0 - 40°, Steel, Black
Stand/mount type - Wall
Stuff - Metal
Technical details - Country of origin - China
Technical details - Lockable - Not lockable
Technical details - Package net weight - 4.5 kg
Technical details - Quantity per pack - 1 pc(s)
Title - Neomounts tv wall mount
Type - Wall
Unit Box Height - 0.31
Unit Box Length - 0.34
Unit Box Width - 0.06
Unit Brutto Volume - 0.006324 cubm
Unit Gross Weight - 4.53 kg
Unit Net Weight - 3.9 kg
URL - https://www.neomounts.com/default.asp?pageid=44&artdetail=WL40-550BL14
Usage - Monitors
Usage - TV
Vendor Homepage - www.neomounts.com/tv-lfd/wall-mounts/wl40-550bl14-neomounts-by-newstar-tv-wall-mount/
vendpn - WL40-550BL14
Vertical adjustment - 12 °
VESA - 100 x 100
VESA - 200 x 100
VESA - 200 x 200
VESA - 200 x 300
VESA - 200 x 400
VESA - 300 x 200
VESA - 300 x 300
VESA - 400 x 200
VESA - 400 x 300
VESA - 400 x 400
Warranty - 60 months
WarrantyInfo - 5 year
Weight - 4.520000
Weight & dimensions - Depth - 45 mm
Weight & dimensions - Height - 433 mm
Weight & dimensions - Width - 433 mm
Wheels - No
Width - 330.000000
