ARTIKEL1 - HMQ-6501 65IN 4K 400CD/QM
ARTIKEL2 - 1200:1 5MS VGA DVI HDMI SDI
Brand - AG Neovo
BrandPartCode - HM651011M0000
Breite - 1.01
Category - Surveillance Monitors
Design - Mounting type - Wall-mounted
Design - Product colour - Black
Design - Product type - CCTV monitor
Display - Anti-glare screen - Yes
Display - Contrast ratio (typical) - 1200:1
Display - Digital horizontal frequency - 15 - 135 kHz
Display - Digital vertical frequency - 24 - 86 Hz
Display - Display brightness - 400 cd/m²
Display - Display diagonal - 163.8 cm (64.5")
Display - Display number of colours - 1.07 billion colours
Display - Display resolution - 3840 x 2160 pixels
Display - Display type - LED
Display - Haze rate - 1%
Display - NTSC coverage (typical) - 72%
Display - Panel type - IPS
Display - Pixel pitch - 0.372 x 0.372 mm
Display - Response time - 5 ms
Display - RGB colour space - NTSC
Display - Surface hardness - 3H
Display - Viewing angle, horizontal - 178°
Display - Viewing angle, vertical - 178°
EANCode - 4710739597516
Gewicht - 35.11
GRUPPE1 - Displays
GRUPPE2 - Lcd Large Format
GTIN - 4710739597516
HERSTELLER - AG NEOVO TECHNOLOGY
Hoehe - 0
HSTNUMMER - HM651011M0000
Laenge - 1.67
LongDesc - The HMQ-6501 is a 65-inch 4K surveillance display with SDI that supports live video streaming over long distances in surveillance and monitoring applications. The display technology is future-proof and compatible with analogue and digital surveillance systems. The HMQ-6501 supports up to 8MP image quality through an HDMI connection to present crisp video footage. With SDI loop-through design, the display can receive real-time 1080p images from HD-SDI or 3G-SDI cameras and transmit the uncompressed videos to multiple SDI displays with ultra-low latency. It fulfils the need for high-quality image details to live video monitoring in broadcasting and video surveillance solutions.See Intricate Details in 4KThe HMQ-6501 features 3840 x 2160 pixels, offering finer video footage. The high resolution enables zoom-in with clear detail as CCTV evidence. As a result, the operator can zoom in on a license plate number or the lines on a face. Furthermore, the panel enables the operator to view smooth 4K video and graphics with a new level of detail and clarity.Support 3G-SDI 1080p High-definition Video StreamingSupport for 3G-SDI and HD-SDI at 1080p resolution enables the HMQ-6501 to display live video signals from SDI cameras. The SDI loop-through output terminal allows displaying the same image to a local SDI monitor or other SDI device.Uncompressed and Ultra-low Latency Transmission via Long DistanceThe HMQ-6501 supports multiple SDI video standards, including SD, HD and 3G-SDI formats. These standards support ultra-low latency and uncompressed transmission of HDTV signals up to 300 meters for live video monitoring.The maximum distances for 3G-SDI, HD-SDI and SD-SDI signal transmission via RG6 coaxial cables:3G-SDI: 100MHD-SDI: 150MSD-SDI: 300MFine-tune CCTV IMAGES for Maximum Clarity and DetailA special pre-configured CCTV Mode maximizes image clarity in low-light footage. You can make granular adjustments and quickly fine-tune your video footage with sharpness, saturation, contrast, brightness, and more. As a result, you don’t need to waste time constantly testing and re-adjusting because the HMQ-6501 already has it all figured out!Enhanced Gamma SelectionOffering an enhanced gamma selection makes for excellent visual optimization. As a result, you can easily improve the light, shadow, and colour balance quality of your videos.Visible Details in Dark ScenesThe technology lets you make black-level adjustments, which facilitate the display of more details in video surveillance images captured in the nighttime or low-light environments.Tailor-Made for ReliabilityThe HMQ-6501 security display adopts a commercial-grade panel and incorporates high-quality components to ensure 24/7 continuous operations. Furthermore, the patented Anti-burn-in™ Technology adds another protection level in mission-critical environments.Metal Casing Ensures Reliable MonitoringThe outer metal case provides enhanced heat dissipation, offering a high level of strength and durability. In turn, this improves the cooling performance to ensure 24/7 proper operation.Easy Control and IntegrationThe built-in RS232 / LAN connections and AG Neovo PID command & Ctrl software allow you to easily control, configure and maintain multiple-display installations in a simple and intuitive way. The software provides intuitive web and mobile interfaces for remote management and OSD-related settings.Versatile Connectivity and Video Loop ThroughThe HMQ-6501 can easily connect to various surveillance equipment with HDMI, DVI, VGA, SDI and Composite (BNC) ports. Its BNC inputs and outputs enable security camera footage to be directly displayed on the screen and loop through to the second device for instant monitoring.
LongProductName - 64.5", IPS, 3840 x 2160px, UHD, 400 cd/m², 1200:1, NTSC 72%, 5 ms, HDMI, DVI, VGA, BNC, RS-232, RJ-45, USB, 26.2 kg
LongSummaryDescription - AG Neovo HMQ-6501. Product type: CCTV monitor, Mounting type: Wall-mounted, Product colour: Black. Display diagonal: 163.8 cm (64.5"), Display resolution: 3840 x 2160 pixels, Display type: LED. Speaker power: 10 W, Panel mounting interface: 600 x 400 mm. Power source type: AC, Power supply type: Internal, Power consumption (typical): 123 W. Weight: 26.2 kg, Height: 851.7 mm, Depth: 79.8 mm
Operational conditions - Operating relative humidity (H-H) - 20 - 85%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 10 - 95%
Operational conditions - Storage temperature (T-T) - 10 - 60 °C
Packaging content - Cables included - AC, HDMI
Packaging content - Quick start guide - Yes
Packaging content - Remote control included - Yes
Performance - Built-in speaker(s) - Yes
Performance - Number of built-in speakers - 2
Performance - Panel mounting interface - 600 x 400 mm
Performance - Speaker power - 10 W
Performance - VESA mounting - Yes
Ports & interfaces - 3.5 mm (1/8-inch) in - Yes
Ports & interfaces - 3.5 mm (1/8-inch) out - Yes
Ports & interfaces - Composite video in - 1
Ports & interfaces - Composite video out - 1
Ports & interfaces - Digital audio optical out - 1
Ports & interfaces - DVI-D ports quantity - 1
Ports & interfaces - Ethernet LAN - Yes
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 2.0
Ports & interfaces - RJ-45 ports quantity - 1
Ports & interfaces - RS-232 ports - 1
Ports & interfaces - SDI inputs - 1
Ports & interfaces - SDI outputs - 1
Ports & interfaces - USB 2.0 ports quantity - 1
Ports & interfaces - USB port - Yes
Ports & interfaces - VGA (D-Sub) ports quantity - 1
Power - AC input frequency - 50 - 60 Hz
Power - AC input voltage - 100 - 240 V
Power - Energy consumption (SDR) per 1000 hours - 123 kWh
Power - Energy efficiency class (SDR) - G
Power - Energy efficiency scale - A to G
Power - Power consumption (off) - 0.3 W
Power - Power consumption (standby) - 0.5 W
Power - Power consumption (typical) - 123 W
Power - Power source type - AC
Power - Power supply type - Internal
ProductName - HMQ-6501
ShortSummaryDescription - AG Neovo HMQ-6501, CCTV monitor, Wall-mounted, Black, 163.8 cm (64.5"), 3840 x 2160 pixels, LED
Stck_Kart - 1
Stck_Pal - 0
Storno - Y
Technical details - Compliance certificates - CE, Low Voltage Directive (LVD), REACH, RoHS, UKCA, WEEE
Technical details - Sustainability compliance - Yes
Title - AG Neovo HMQ-6501 CCTV monitor 163.8 cm (64.5") 3840 x 2160 pixels
URL - https://www.agneovo.com/uk/monitors/security-surveillance/hmq-series/hmq-6501
WarrantyInfo -
Weight & dimensions - Depth - 79.8 mm
Weight & dimensions - Height - 851.7 mm
Weight & dimensions - Package depth - 220 mm
Weight & dimensions - Package height - 1045 mm
Weight & dimensions - Package weight - 36.7 kg
Weight & dimensions - Package width - 1660 mm
Weight & dimensions - Weight - 26.2 kg
Weight & dimensions - Width - 1476.7 mm
