100 mm x 100 mm VESA mounting interface - Yes
ARTIKEL1 - B-WARE XCB3494WQSN-B5 34IN
ARTIKEL1 - XCB3494WQSN-B5 86.4CM 34IN IPS
ARTIKEL2 - 3440X1440 300CD HDMI DP
ARTIKEL2 - B-WARE
Audio - Yes
AudioFeatures - 2 x 2W
Brand - iiyama
BrandPartCode - XCB3494WQSN-B5
Breite - 0.48
Brightness - 300
Brightness - 300 cd/m2
Camera - No
Category - Computer Monitors
Category - Root/Electronics/PC peripherals/Monitors
Category 1 - Displays
Category 2 - Monitore
Category Code - LC3
Category_1 - Monitors and TV
Category_2 - LED Monitors 31 inches and up
Colour - Black
Contrast - 3000:1
ContrastRatio - 3000:1
ContrastRatioDynamic - 80,000,000:1
Data Sheet (Link) - https://eprel.ec.europa.eu/api/product/1396054/fiches?language=EN
Depth - 242.5 mm
Description - ProLite XCB3494WQSN-B5 34’’ UWQHD curved with USB-C dock, KVM switch and 150mm height adjustable stand Inspired by the curve of the human eye, the 1500R curved VA screen offers superb images along with a comfortable and immersive viewing experience. Equipped with the KVM switch, the XCB3494WQSN enables you to connect multiple computers which can be operated over one console (monitor, keyboard, mouse). The USB-C dock connector allows you to simplify your workspace by using a single cable to both send the signal from your notebook to your monitor while charging the notebook from the monitor. Additionally, if your monitor is connected to the Internet via a LAN cable, your notebook will automatically be connected to the network. The 150mm height-adjustable stand ensures you can adjust the screen position to your preferences, and the flicker-free panel with blue light reducer function reduces eye fatigue.
Design - Product colour - Black
Display - Contrast ratio (dynamic) - 8000000:1
Display - Contrast ratio (typical) - 3000:1
Display - Display brightness (typical) - 300 cd/m²
Display - Display diagonal - 86.4 cm (34")
Display - Display diagonal (metric) - 86.4 cm
Display - Display number of colours - 16.78 million colours
Display - Display resolution - 3440 x 1440 pixels
Display - Display surface - Matt
Display - HD type - UltraWide Quad HD
Display - Horizontal scan range - 30 - 185 kHz
Display - Maximum refresh rate - 120 Hz
Display - Native aspect ratio - 21:9
Display - NTSC coverage (typical) - 93%
Display - Panel type - VA
Display - Pixel pitch - 0.232 x 0.232 mm
Display - Response time - 0.4 ms
Display - Screen curvature rating - 1500R
Display - Screen shape - Curved
Display - sRGB coverage (typical) - 99%
Display - Touchscreen - No
Display - Viewing angle, horizontal - 178°
Display - Viewing angle, vertical - 178°
Displayable colours - 16.7 million
DisplayCaseColour - Black
DisplayFeatures -
Curvature: 1500RColor support: 16.7M (sRGB: 99%; NTSC: 93%)Blue light reducerFlicker freeFreeSync support HDMI: 100Hz, DP / USB-C: 120Hzi-Style Color
DisplayFormat - 21:9
DisplayNativeResolution - 3440 x 1440
DisplayPort - Yes
DisplayPort Input/Output connectors - 1
DisplaySizecm - 86.4 cm
Display surface - Matte
DisplayType - LED VA
DisplayViewingArea - 797.2 x 333.7 mm
EAN - 4948570121410
EANCode - 4948570121410
Eans - 4948570121410
EAN_code - 4948570121410
EmissionStandard - Energy class: G
Energy efficiency class - G
EPEAT - -
EPREL Registration Number - 1.39605e+006
EPREL Version Number - 1
Ergonomics - Cable lock slot - Yes
Ergonomics - Cable lock slot type - Kensington
Ergonomics - Height adjustment - 15 cm
Ergonomics - Height adjustment - Yes
Ergonomics - On Screen Display (OSD) - Yes
Ergonomics - On Screen Display (OSD) languages - Czech, German, Dutch, English, Spanish, French, Italian, Japanese, Polish, Portuguese, Russian
Ergonomics - Panel mounting interface - 100 x 100 mm
Ergonomics - Tilt adjustment - Yes
Ergonomics - Tilt angle range - -5 - 23°
Ergonomics - VESA mounting - Yes
Ethernet - Yes
Frequency - 30-185 kHz
FrequencyV - 48-120 Hz
Full Description Line - Model XCB3494WQSN-B5|34"|Curved/21 : 9|Panel VA|Resolution 3440x1440|Form factor 21:9|Brightness 300|Contrast 3000:1|Display Matte|Response time 0.4 ms|Horizontal 178 degrees|Vertical 178 degrees|Displayable colours 16.7 million|1xHDMI|1xDisplayPort|3xUSB 3.2|1xUSB-C|1xHeadphones jack|1xRJ45|Speakers|Swivel|Height adjustable|Tilt|PSU Inbuilt|100 mm x 100 mm|Kensington lock|Included Accessories Cables power, USB, HDMI, DP, USB-COther quick start guide, safety guide|Colour Black
Gewicht - 12.34
Gewicht - 12.36
GrossWeight - 12.400 kg
GRUPPE1 - Displays
GRUPPE2 - Lcd Monitor
GTIN - 4948570121410
HDMI - 1
HDMI Input/Output connectors - 1
Headphones jack Input/Output connectors - 1
Height - 431 mm
Height adjustable Stand - Yes
HeightAdjustment - Yes
HERSTELLER - IIYAMA
HERSTELLER - IIYAMA CONSIGNMENT
Hoehe - 0.24
HSTNUMMER - XCB3494WQSN-B5
HSTNUMMER - XCB3494WQSN-B5-STD
Included Accessories - Cables power, USB, HDMI, DP, USB-C
Other quick start guide, safety guide
InputSignal - HDMIDisplayPort2x USB Type-C3x USB 3.0Audio inRJ-45
KensingtonLock - Yes
Kensington lock support - Yes
Laenge - 0.9
LongDesc -
LongDesc - 34" (86.4 cm) curved monitor with UWQHD resolution, a KVM switch, USB-C dock and a height-adjustable standThe 34" (86.4 cm) XCB3494WQSN curved monitor guarantees a comfortable and immersive viewing experience thanks to the 1500R curvature of the screen. The integrated VA panel with UWQHD resolution (3440x1440) offers excellent image quality and high contrast values. Equipped with a KVM Switch, XCB3494WQSN allows connection to multiple computers to be operated from one console (monitor, keyboard, mouse) The USB-C dock provides a clean and convenient workspace by using only a single cable, to allow the simultaneous transmission of data, video and audio signals, all without quality loss.In addition, the connected device is charged directly by the monitor.When the monitor is connected to the Internet via a LAN cable,your notebook is also automatically connected to the network. The 150mm height-adjustable stand ensures you can adjust the position of the screen to your liking, and the flicker-free panel with blue light reduction function reduces eye fatigue.The height-adjustable base allows you to position the screen perfectly, ensuring optimal viewing comfort. Is good for your health and also increases productivity.
LongProductName - 34" 3440 x 1440, 86.4cm, 300 cd/m², 16.7min, 1500r, 240V, 50/60Hz
LongSummaryDescription - iiyama ProLite XCB3494WQSN-B5. Display diagonal: 86.4 cm (34"), Display resolution: 3440 x 1440 pixels, HD type: UltraWide Quad HD, Display surface: Matt, Response time: 0.4 ms, Native aspect ratio: 21:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. Built-in speaker(s). Built-in USB hub. VESA mounting, Height adjustment. Product colour: Black
Manufacturer - Iiyama
Manufacturer - iiyama
Manufacturer_code - XCB3494WQSN-B5
MANUFDATASHEET - https://iiyama.com/gl_en/products/prolite-xcb3494wqsn-b5/
Model name - XCB3494WQSN-B5
MonitorControls - Push (Menu)UpDownLeft (Eco)Right (Blue Light Reducer)InputVolume +Volume -Power
Monitor features - 21 : 9/Curved
MonitorSize - 34"
MonitorType - Curved
MPN - XCB3494WQSN-B5
Multimedia - Built-in camera - No
Multimedia - Built-in speaker(s) - Yes
Multimedia - Number of speakers - 2
Multimedia - RMS rated power - 2 W
Name - 34''/86,4cm (3440x1440) iiyama XCB3494WQSN 0,4ms HDMI DisplayPort USB 3.0 Height Adj. Stand Speaker Black
Name - iiyama ProLite XCB3494WQSN-B5 - 34 - LED, UWQHD, USB-C, VA panel, 120Hz panel, black
Name - iiyama ProLite XCB3494WQSN-B5 - 34'' | VA | UWQHD | 0,4ms | 120Hz
Native resolution - 3440x1440
PackageContents - Cables: power, USB, HDMI, DP, USB-CQuick start guideSafety guide
Packaging content - Cables included - AC, DisplayPort, HDMI, USB, USB Type-C
Packaging content - Quick start guide - Yes
Packaging data - Package depth - 236 mm
Packaging data - Package height - 480 mm
Packaging data - Package weight - 12.4 kg
Packaging data - Package width - 900 mm
Panel type - VA
Performance - AMD FreeSync - Yes
Performance - Flicker-free technology - Yes
Performance - Low Blue Light technology - Yes
Pivot - No
Pixelpitch - 0.232 mm
Pixel size - 0.232 mm
Ports & interfaces - Built-in KVM switch - Yes
Ports & interfaces - Built-in USB hub - Yes
Ports & interfaces - DisplayPorts quantity - 1
Ports & interfaces - HDCP - Yes
Ports & interfaces - HDMI - Yes
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - Headphone out - Yes
Ports & interfaces - Number of USB Type-C upstream ports quantity - 1
Ports & interfaces - USB Power Delivery - Yes
Ports & interfaces - USB Power Delivery up to - 65 W
Ports & interfaces - USB Type-A downstream ports quantity - 3
Power - AC input frequency - 50 - 60 Hz
Power - AC input voltage - 100 - 240 V
Power - Energy efficiency class (SDR) - G
Power - European Product Registry for Energy Labelling (EPREL) code - 1396054
Power - Power consumption (off) - 0.5 W
Power - Power consumption (standby) - 0.5 W
Power - Power consumption (typical) - 56 W
Power - Power supply type - Internal
Power supply - Inbuilt
ProdDesc - Iiyama Prolite XCB3494WQSN-B5 - 3440 x 1440 @120Hz (4.9 megapixel UWQHD, DisplayPort & USB-C) - Aspect ratio - 21:9 - Panel brightness, 300 cd/m² - Static contrast, 3000:1
Producer - iiyama
ProducerCode - XCB3494WQSN-B5
ProductName - XCB3494WQSN-B5
ProductPicture - http://www.tdbaltic.ee/images/ds4/XCB3494WQSN-B5-01.jpg
ProductPicture2 - http://www.tdbaltic.ee/images/ds4/XCB3494WQSN-B5-02.jpg
ProductPicture3 - http://www.tdbaltic.ee/images/ds4/XCB3494WQSN-B5-03.jpg
ProductPicture4 -
Response time - 0.4 ms
ResponseTime - 0.4 ms
RJ45 Input/Output connectors - 1
Rotate - No
Screen form factor - 21:9
Screen size - 34"
Shipping Box Depth Shipping/Package Box Dimensions - 89.5 cm
Shipping Box Height Shipping/Package Box Dimensions - 48 cm
Shipping Box Weight Shipping/Package Box Dimensions - 13.6 kg
Shipping Box Width Shipping/Package Box Dimensions - 23 cm
ShortDescription - 34'' | VA | UWQHD | 0,4ms | 120Hz
ShortSummaryDescription - iiyama ProLite XCB3494WQSN-B5, 86.4 cm (34"), 3440 x 1440 pixels, UltraWide Quad HD, 0.4 ms, Black
Speakers - Yes
Standby consumption - 0.5 Watts
Stck_Kart - 1
Stck_Pal - 0
Stck_Pal - 15
Storno - N
Storno - Y
Swivel Stand - Yes
Tilt - Yes
Tilt Stand - Yes
Title - iiyama ProLite XCB3494WQSN-B5 LED display 86.4 cm (34") 3440 x 1440 pixels UltraWide Quad HD Black
Unit Box Height - 0.48
Unit Box Length - 0.895
Unit Box Width - 0.23
Unit Brutto Volume - 0.09881 cubm
Unit Gross Weight - 13.6 kg
Unit Net Weight - 9.4 kg
URL - https://iiyama.com/de_de/produkte/prolite-xcb3494wqsn-b5/
USB - Yes
USB-C Input/Output connectors - 1
USB 3.2 Input/Output connectors - 3
USBTypeC - 65 W
Vendor Homepage - iiyama.com/gl_en/products/prolite-xcb3494wqsn-b5/
VESACompatible - Yes
VESAStandard - 100 x 100
ViewingAngle - 178
Viewing angle horizontal - 178 degrees
ViewingAngleV - 178
Viewing angle vertical - 178 degrees
Warranty - 3 years
Warranty - 36 months
WarrantyInfo -
Weight - 9.400 kg
Weight - 12,40
Weight - 12.36
Weight & dimensions - Depth (with stand) - 245.5 mm
Weight & dimensions - Height (with stand) - 431 mm
Weight & dimensions - Weight (with stand) - 9.4 kg
Weight & dimensions - Width (with stand) - 809.5 mm
Width - 809.5 mm
Wireless - No
WirelessFeatures - -
