ARTIKEL1 - TW1623AS-B1P 15.6IN ANDROID OS
ARTIKEL2 - 1920X1080 30MS 450CD/M2 1000:1 1
Audio - Built-in speaker(s) - Yes
Audio - Number of built-in speakers - 2
Audio - RMS rated power - 4 W
Brand - iiyama
BrandPartCode - TW1623AS-B1P
Breite - 0
Category - Signage Displays
Certificates - Certification - CE, EAC, RoHS support, ErP, WEEE, REACH, UKCA
Computer system - Built-in processor - Yes
Computer system - Computer system - Yes
Computer system - Internal memory - 4 GB
Computer system - Internal storage capacity - 32 GB
Computer system - Operating system installed - Android
Computer system - Operating system version - 13
Computer system - Processor architecture - ARM Cortex-A55
Computer system - Processor cores - 4
Computer system - Processor family - ARM Rockchip
Computer system - Processor frequency - 2 GHz
Computer system - Processor manufacturer - Rockchip
Computer system - Processor model - RK3568
Design - Fingerprint resistant - Yes
Design - Orientation - Horizontal/Vertical
Design - Panel mounting interface - 100 x 100 mm
Design - Placement supported - Indoor
Design - Product colour - Black
Design - Product design - Interactive flat panel
Design - VESA mounting - Yes
Display - Active display area (W x H) - 344.2 x 193.6 mm
Display - Contrast ratio (typical) - 1000:1
Display - Display brightness - 450 cd/m²
Display - Display diagonal - 39.6 cm (15.6")
Display - Display number of colours - 16.7 million colours
Display - Display resolution - 1920 x 1080 pixels
Display - Glass thickness - 1.8 mm
Display - HD type - Double Full HD
Display - Multi-touch - Yes
Display - Native aspect ratio - 16:9
Display - Number of simultaneous touchpoints - 10
Display - Panel type - IPS
Display - Pixel pitch - 0.17925 x 0.17925 mm
Display - Response time - 30 ms
Display - Surface hardness - 6H
Display - Touchscreen - Yes
Display - Touchscreen technology - Projected capacitive system
Display - Viewing angle, horizontal - 170°
Display - Viewing angle, vertical - 170°
EANCode - 4948570124534
Gewicht - 2.47
GRUPPE1 - Displays
GRUPPE2 - Led Small Format
GTIN - 4948570124534
HERSTELLER - IIYAMA CONSIGNMENT
Hoehe - 0
HSTNUMMER - TW1623AS-B1P
Laenge - 0
LongDesc - 15.6” Full HD PCAP 10pt touch screen with Android and POE TechnologyThe ProLite TW1623AS-B1P touch panel PC is a perfect choice for high-use environments such as retail, interactive POS, information desks or hospitality applications. Thanks to the pre-installed Android operating system, it is possible to easily customize the monitor by installing applications directly to it.The Power over Ethernet technology (POE) allows to provide both data connection and power by a single cable, simplifying all installations. This monitor can operate in landscape, portrait and face-up orientation in 24/7 operating time. Together with the built-in microphone and speakers it offers interactive and almost limitless application possibilities.ConnectivityThe RJ45 (LAN) connector supporting Power over Ethernet technology (POE*) allows to provide both data connection and power by a single cable, simplifying all installations. Together with the built-in microphone and speakers it offers interactive and almost limitless application possibilities. *Requires 30WAndroid OSThanks to Android OS, you can easily customize the display to your needs by installing applications directly to it.Touch technology - CapacitiveThis technology uses a sensor-grid of micro-fine wires integrated into the glass that covers the screen. Touch is detected because electrical characteristics of the sensor grid change when human finger is placed on the glass. Thanks to the glass overlay this technology is highly durable, and the touch function remains unaffected even if the glass is scratched. It offers perfect picture performance and will work with human finger (also latex gloved) and stylus-pen.IPS TechnologyIPS displays are best known for wide viewing angles and natural, highly accurate colours. They are especially suited for colour-critical applications.Anti-fingerprint coatingThis special Nano coating ensures a smoother touch and less resistance in the swipe. It makes the screen less static and susceptible to dirt, dust, fingerprints and it improves the clarity of the content displayed on the screen.
LongProductName - 15.6", 39.5cm, IPS, 16:9, 1920 x 1080, 450 cd/m², 30 ms, Touch, Rj-45, HDMI, 2 x 2 W, Android 13, Rockchip RK3568, Black
LongSummaryDescription - iiyama TW1623AS-B1P. Product design: Interactive flat panel. Display diagonal: 39.6 cm (15.6"), Display resolution: 1920 x 1080 pixels, Display brightness: 450 cd/m², HD type: Double Full HD, Touchscreen. Wi-Fi. Operating hours (hours/days): 24/7. Operating system installed: Android. Product colour: Black
Other features - Audio input - Mini Jack
Other features - Bluetooth - Yes
Other features - Bluetooth version - 5.2
Packaging content - Power adapter included - Yes
Packaging data - Package depth - 75 mm
Packaging data - Package height - 295 mm
Packaging data - Package volume - 2400 cm³
Packaging data - Package width - 477 mm
Performance - On Screen Display (OSD) - Yes
Performance - Operating hours (hours/days) - 24/7
Performance - Purpose - Commercial
Ports & interfaces - Card reader integrated - Yes
Ports & interfaces - Compatible memory cards - SD
Ports & interfaces - Ethernet LAN - Yes
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - Microphone in - Yes
Ports & interfaces - USB port - Yes
Ports & interfaces - USB ports quantity - 3
Ports & interfaces - USB version - 2.0
Ports & interfaces - Wi-Fi - Yes
Ports & interfaces - Wi-Fi standards - 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Power - Power consumption (off) - 0.3 W
Power - Power consumption (standby) - 0.5 W
Power - Power consumption (typical) - 24 W
ProductName - TW1623AS-B1P
ShortSummaryDescription - iiyama TW1623AS-B1P, Interactive flat panel, 39.6 cm (15.6"), 1920 x 1080 pixels, Wi-Fi, 24/7
Stck_Kart - 5
Stck_Pal - 5
Storno - Y
Title - iiyama TW1623AS-B1P Signage Display Interactive flat panel 39.6 cm (15.6") Wi-Fi 450 cd/m² Double Full HD Black Touchscreen Built-in processor Android 24/7
URL - https://iiyama.com/gl_en/products/prolite-tw1623as-b1p/
WarrantyInfo -
Weight & dimensions - Display depth - 30.5 mm
Weight & dimensions - Display height - 244 mm
Weight & dimensions - Display weight - 1.5 kg
Weight & dimensions - Display width - 387 mm
