75 mm x 75 mm VESA mounting interface - Yes
Audio-Out Input/Output connectors - 1
Brand - Dahua Technology
BrandPartCode - DHI-LM24-E230C
Brightness - 250
Category - Computer Monitors
Category - Root/Electronics/PC peripherals/Monitors
Category Code - LC3
Contrast - 3000:1
Depth Unit Dimensions - 73.96 mm
Description - > Comfortable 1500R exquisite curvature, close to the natural look and feel of the human eye, bringing immersive visual enjoyment; > The 1920*1080 resolution produces clearer and more vivid pictures; > VA panel for wide viewing angles with 3-sided frameless design; > Wide color gamut, 99% sRGB, 83% NTSC, 85% DCI-P3, 80% Adobe RGB. It meets the designer's demand of image texture; > The 165Hz high refresh rate enables you to aim at the target more quickly, eliminates picture lagging, and helps you to aim at the target faster; > Adaptive sync can effectively solve picture lagging and tearing
Design - Detachable stand - Yes
Design - Frameless design - Yes
Design - Market positioning - Gaming
Design - Product colour - Black
Display - Adobe RGB coverage - 80%
Display - Backlight type - Edge LED
Display - Contrast ratio (typical) - 3000:1
Display - Display brightness (typical) - 250 cd/m²
Display - Display diagonal - 59.9 cm (23.6")
Display - Display resolution - 1920 x 1080 pixels
Display - Display technology - LED
Display - HD type - Full HD
Display - Maximum refresh rate - 165 Hz
Display - Native aspect ratio - 16:9
Display - NTSC coverage (typical) - 83%
Display - Panel type - VA
Display - Response time - 1 ms
Display - Screen curvature rating - 1500R
Display - Screen shape - Curved
Display - sRGB coverage (typical) - 99%
Display - Touchscreen - No
Display - Viewing angle, horizontal - 178°
Display - Viewing angle, vertical - 178°
DisplayPort Input/Output connectors - 1
Eans - 6923172547682
Energy consumption, standard - 17 kWh/1000h
Energy efficiency class - E
Ergonomics - Height adjustment - No
Ergonomics - Panel mounting interface - 75 x 75 mm
Ergonomics - Pivot - No
Ergonomics - Swivelling - No
Ergonomics - Tilt adjustment - Yes
Ergonomics - Tilt angle range - -5 - 15°
Ergonomics - VESA mounting - Yes
Ergonomics - Wall mountable - Yes
Full Description Line - Model LM24-E230C|23.6"|Gaming/Curved|Panel VA|Resolution 1920x1080|Form factor 16:9|Refresh rate 165Hz|Brightness 250|Contrast 3000:1|Response time 1 ms|Horizontal 178 degrees|Vertical 178 degrees|2xHDMI|1xDisplayPort|1xAudio-Out|Tilt|PSU External|75 mm x 75 mm
HDMI Input/Output connectors - 2
Height Unit Dimensions - 333.54 mm
LongDesc -
LongProductName - 23.6’’ FHD Monitor 1500R, 1920 x 1080 VA, 165Hz, 250 cd/m2, 3000:1, 1ms, 1 x DP1.2，2 x HDMI 1.4, Audio out
LongSummaryDescription - Dahua Technology DHI-LM24-E230C. Display diagonal: 59.9 cm (23.6"), Display resolution: 1920 x 1080 pixels, HD type: Full HD, Display technology: LED, Response time: 1 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. VESA mounting. Product colour: Black
Model name - LM24-E230C
Monitor features - Curved/Gaming
Multimedia - Built-in camera - No
Multimedia - Built-in speaker(s) - No
Name - Dahua LM24-E230C - 23,6'' | VA | Full HD | 1ms
Native resolution - 1920x1080
Operational conditions - Operating relative humidity (H-H) - 10 - 85%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Packaging content - Cables included - DisplayPort
Packaging content - Power adapter included - Yes
Packaging content - Stand included - Yes
Packaging data - Package depth - 149 mm
Packaging data - Package height - 407 mm
Packaging data - Package weight - 4.9 kg
Packaging data - Package width - 630 mm
Panel type - VA
Ports & interfaces - Built-in USB hub - No
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - DisplayPorts quantity - 1
Ports & interfaces - DisplayPort version - 1.2
Ports & interfaces - HDMI - Yes
Ports & interfaces - HDMI ports quantity - 2
Ports & interfaces - HDMI version - 1.4
Ports & interfaces - Headphone out - Yes
Ports & interfaces - Headphone outputs - 1
Power - AC adapter output voltage - 12 V
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 100 - 240 V
Power - Energy consumption (SDR) per 1000 hours - 17 kWh
Power - Energy efficiency class (SDR) - E
Power - Energy efficiency scale - A to G
Power - European Product Registry for Energy Labelling (EPREL) code - 1536828
Power - Power consumption (max) - 35 W
Power - Power consumption (standby) - 0.5 W
Power - Power consumption (typical) - 24 W
Power - Power supply type - External
Power supply - External
Producer - Dahua Technology
ProducerCode - LM24-E230C
ProductName - DHI-LM24-E230C
Refresh rate - 165Hz
Response time - 1 ms
Screen form factor - 16:9
Screen size - 23.6"
Shipping Box Depth Shipping/Package Box Dimensions - 63 cm
Shipping Box Height Shipping/Package Box Dimensions - 42 cm
Shipping Box Weight Shipping/Package Box Dimensions - 4.7 kg
Shipping Box Width Shipping/Package Box Dimensions - 15 cm
ShortDescription - 23,6'' | VA | Full HD | 1ms
ShortSummaryDescription - Dahua Technology DHI-LM24-E230C, 59.9 cm (23.6"), 1920 x 1080 pixels, Full HD, LED, 1 ms, Black
Tilt Stand - Yes
Title - Dahua Technology DHI-LM24-E230C LED display 59.9 cm (23.6") 1920 x 1080 pixels Full HD Black
Unit Box Height - 0.42
Unit Box Length - 0.63
Unit Box Width - 0.15
Unit Brutto Volume - 0.03969 cubm
Unit Gross Weight - 4.7 kg
Unit Net Weight - 3.2 kg
URL - https://www.dahuasecurity.com/la/products/All-Products/Display--Control/Monitors/Gaming-Series/LM24-E230C
Vendor Homepage - display.dahuasecurity.com/consumer/en/products/productDetail?product_id=109627
Viewing angle horizontal - 178 degrees
Viewing angle vertical - 178 degrees
Warranty - 36 months
WarrantyInfo -
Weight & dimensions - Depth (without stand) - 74 mm
Weight & dimensions - Height (without stand) - 333.5 mm
Weight & dimensions - Weight (with stand) - 3.2 kg
Weight & dimensions - Width (without stand) - 537.9 mm
Width Unit Dimensions - 537.86 mm
