Accessories included - Zestaw śrub 1 x 120mm PWM wentylator już zainstalowany
Brand - Chieftec
BrandPartCode - BX-10B-M-OP
Category - Computer Cases
Category_1 - Computer Cases and Cooling
Category_2 - Computer Cases
Chassis type - Mini Tower
Color - Black
Computer case backlight - No
Cooling - Bottom fans diameters supported - 120,140 mm
Cooling - Number of bottom fans supported (max) - 3
Cooling - Number of rear fans supported (max) - 1
Cooling - Number of top fans supported (max) - 2
Cooling - Rear fans diameters supported - 120 mm
Cooling - Rear fans installed - 1x 120 mm
Cooling - Top fans diameters supported - 120,140 mm
Cooling - Top radiator sizes supported - 240 mm
Description - Obudowa BX-10B-M-OP Mini Tower CHIEFTEC BX-MESH to nowoczesna, kompaktowa obudowa, która łączy elegancki design z wysoką funkcjonalnością i łatwością montażu. Wyposażone w standardową kompatybilność z zasilaczem ATX, płyty m-ATX i karty graficzne o maksymalnej długości 380 mm, a także łącznie 6 możliwych wentylatorów, nowoczesne konfiguracje nie powinny mieć problemów z instalacją w BX-10B-M-OP z wystarczającą ilością miejsca i dobre chłodzenie.
Design - Cable management - Yes
Design - Form factor - Mini Tower
Design - Illumination - No
Design - Material - Metal
Design - Maximum CPU cooler height - 16.5 cm
Design - Maximum graphics card length - 38 cm
Design - Maximum PSU length - 18 cm
Design - Number of 2.5" bays - 3
Design - Number of 3.5" bays - 1
Design - Number of expansion slots - 4
Design - Number of internal 3.5" bays - 1
Design - On/off button - Yes
Design - Product colour - Black
Design - Side window - No
Design - Supported motherboard form factors - micro ATX, Mini-ITX
Design - Type - PC
dimension depth - mm
dimension height - mm
Dimensions - 325 (+ 15 nóżki) x 204 x 415 mm
dimension weight - g
dimension width - mm
Drive bays 2.5'' extern. - 0
Drive bays 2.5'' intern. - 4
Drive bays 3.5'' extern. - 0
Drive bays 3.5'' intern. - 1
Drive bays 5.25'' extern. - 0
Drive bays 5.25'' intern. - 0
ean -
Fans installed - 1 x 120 mm (back)
Form-factor - Micro ATX
Form-factor - Mini ITX
Front panel connectors - 1 x mic/headphone (combo)
Front panel connectors - 1 x USB 3.2 Gen1
Front panel connectors - 1 x USB 3.2 Gen 1 Type-C
guarantee - 24
guarantee_type - normal
LongDesc - The CHIEFTEC BX-MESH is a modern, compact mini tower that combines elegant and subtle design with high functionality and easyinstallation for a capable system. Featuring standard ATX PSU compatibility, m-ATX boards and graphics cards up to a maximum length of 380mm, as well as a total of 6 possible installed fans, modern configurations should have no trouble being installed into the BX-10B-M-OP from a space or cooling perspective.
LongProductName - Chieftec BX Mesh BX-10B-M-OP
LongSummaryDescription - Chieftec BX-10B-M-OP. Form factor: Mini Tower, Type: PC, Product colour: Black. Power supply location: Rear. Rear fans installed: 1x 120 mm, Rear fans diameters supported: 120 mm, Top fans diameters supported: 120,140 mm. Supported HDD sizes: 2.5,3.5", SSD form factor: 2.5". Width: 204 mm, Depth: 415 mm, Height: 325 mm
Manufacturer - Chieftec
Manufacturer_code - BX-10B-M-OP
Maximum CPU cooling height - 165 mm
Maximum length of the graphics card - 380 mm
Maximum length of the power supply - 180 mm
Maximum number of fans - 6
Name - Chieftec BX-MESH, tower housing (black, tempered glass)
name - PC case BX-10B-M-OP Mini Tower black
No. of drive bays - 4
Number of fans installed - 1
Number of slots for expansion cards - 4
Ooptional water cooling - 1 x 240 mm (góra)
Optional fans - 1 x 120 mm (back)
Optional fans - 2 x 120/140 mm (top)
Optional fans - 3 x 120 mm lub 2 x 140 mm (front)
Other features - Sloty wewnętrzne: 1 x 3,5 oraz 3 x 2,5 Lub 4 x 2,5 Zasilacz: ATX (zalecane 180 mm, jeśli GPU jest większa, niż 300 mm) Długość kart VGA: 380 mm (300 mm, jeśli zasilacz jest wyższy, niż 180 mm)
Ports & interfaces - Audio input - Yes
Ports & interfaces - Audio output - Yes
Ports & interfaces - Combo headphone/mic port - Yes
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity - 1
Ports & interfaces - USB Type-C ports quantity - 1
Power supply - Failure
Power supply - Power supply included - No
Power supply - Power supply location - Rear
producer - Chieftec
ProductName - BX-10B-M-OP
ShortSummaryDescription - Chieftec BX-10B-M-OP, Mini Tower, PC, Black, micro ATX, Mini-ITX, Metal, 16.5 cm
Side panel - Metal fence
Storage - SSD form factor - 2.5"
Storage - Supported HDD sizes - 2.5,3.5"
Technical details - Warranty period - 2 year(s)
Title - Chieftec BX-10B-M-OP computer case Mini Tower Black
URL - https://www.chieftec.eu/products-detail/561/BX-10B-M-OP
vendpn - BX-10B-M-OP
Video -
WarrantyInfo - 24 Months
Weight - 4.51 kg
Weight - 5,35
Weight & dimensions - Depth - 415 mm
Weight & dimensions - Height - 325 mm
Weight & dimensions - Material thickness - 0.6 mm
Weight & dimensions - Width - 204 mm
