10/100/1000/2500 Mbps ports - None
Accessories included -
Application - Home and small office
Category 1 - Netzwerk
Category 2 - Switching Hubs
Chassis type - Desktop
Console port - No
Description - FS1018PS1 16-Port 10/100M PoE+ Switch with 1 Combo SFP Port 200W PoE power, up to 30W per port 2 10/100/1000M uplink ports + 1 SFP port 16 10/100M PoE+ ports CCTV mode supports remote PoE power up to 250m VLAN mode isolates each PoE port for security IEEE 802.3at / IEEE 802.3af compliant Plug&Play
dimension depth - 86 mm
dimension height - 377 mm
Dimensions - 280 x 180 x 44 mm
dimension weight - 2251 g
dimension width - 292 mm
ean - 6971690790271
EAN - 6971690790271
Environment requirements - Working temperature: 0~40°C Storage temperature: -40~70°C Non-condensing humidity: 0 ~ 85%
Fan - No
guarantee - 24
guarantee_type - normal
L2 features -
L3 features -
MAC address table size - 4000
Management, monitoring, configuration -
Manufacturer - Cudy
MPN - FS1018PS1
Name - 16+1P Cudy FS1018PS1 RM PoE+ SFP
name - Switch FS1018PS1 16xFE PoE+ 200W 1xSFP
Network architecture - GigabitEthernet
Number of 10/100 Mbps ports - 16
Number of 10/100/1000 Mbps ports - 2
Number of 10Gb ports - None
Number of COMBO ports - 1
Number of PoE+ ports - 16
Number of PoE ports (PoE & PoE+) - None
Number of QSFP+ ports - None
Number of SFP+ ports - None
Number of SFP56 ports - None
Number of SFP ports - 1
Other features - Transmission speed: 14880pps for 10Mbps 148800pps for 100Mbps 1488000pps for 1000Mbps
Other functions -
Power consumption - 190 W
Power supply - Internal power supply: AC 100 - 240V
Power supply - Internal
producer - Cudy
QoS -
Security -
Stackability - No
Supported protocols and standards - IEEE802.3 IEEE802.3i IEEE802.3u IEEE802.3z IEEE802.3ab IEEE802.3af IEEE802.3at
Support for Jumbo frames - No
Switch class - Unmanaged
Throughput - 7.2 Gb/s
vendpn - FS1018PS1
VLAN -
Weight - 2.2
