TP-LINK TL-SF1016D 16-Port 10/100Mbps Desktop Switch

10Base-T / 100Base-TX Ports - 16
ARTIKEL1 - TL-SF1016D UNMANAGED 10/100M
ARTIKEL2 - SWITCH 16PORT
Brand - TP-Link
BrandPartCode - TL-SF1016D V7
Breite - 0.23
Category - Network Switches
Category - Tīkla produkti, Gudrā māja :: Komutatori (Switch)
Category Code - SWI
Certificates - Compliance certificates - CE, Federal Communications Commission (FCC), RoHS
Code - TL-SF1016D
Data transmission - MAC address table - 2000 entries
Data transmission - Store-and-forward - Yes
Data transmission - Switching capacity - 3.2 Gbit/s
Desc - Portu skaits: 16, Portu ātrums: 10/100 Mb/s, Garantija: 2 gadi
Description - The TL-SF1016D Fast Ethernet Switch is designed for SOHO (Small Office/Home Office) or workgroup users. All 16 ports support auto MDI/MDIX, no need to worry about the cable type, simply plug and play.
Description - TP-LINK TL-SF1016D The TL-SF1016D Fast Ethernet Switch is designed for SOHO (Small Office/Home Office) or workgroup users.. All 16 ports support auto MDI/MDIX, no need to worry about the cable type, simply plug and play. Moreover, with the innovative energy-efficient technology, the TL-SF1016D can save up to 70%* of the power consumption and 80% of the packaging material can be recycled, making it an eco-friendly solution for your business network.
Design - LED indicators - Yes
Design - Product colour - Black
Design - Rack mounting - Yes
Design - Stackable - No
Design - Wall mountable - Yes
Design > Case design - Plastic case
Design > Form factor - Desktop
dimension depth - 70 mm
dimension height - 230 mm
dimension weight - 737 g
dimension width - 290 mm
EAN - 6935364020293
ean - 6935364020293
EANCode - 6935364020293
Full Description Line - 16x10Base-T / 100Base-TX|Switching method Store-and-forward|Included Accessories Power Adapter; User Guide|Unit Net Weight 0.42 kg
Gewicht - 0.62
Gross weight - 0.612 kg
GRUPPE1 - Network
GRUPPE2 - Lan Switch Unmanaged
GTIN - 0845973020293
GTIN - 845973020293
GTIN - 6935364020293
guarantee - 36
guarantee_type - normal
HERSTELLER - TP-LINK
Hoehe - 0.07
HSTNUMMER - TL-SF1016D
ImageUrl - https://www.balticdata.lv/Gfx/ProductImages/Info/Product_1009_1.jpg
Included Accessories - Power Adapter; User Guide
Laenge - 0.29
LargeDescHTML - 16 10/100Mbps Auto-Negotiation RJ45 ports, Supports Auto MDI / MDIXGreen Ethernet technology saves the power up to 80%IEEE 802.3x flow control provides reliable data transferPlastic case, desktop or wall-mounting designPlug and play, no configuration requiredWhat This Product DoesThe TL-SF1016D Fast Ethernet Switch is designed for SOHO (Small Office/Home Office) or workgroup users. All 16 ports support auto MDI/MDIX, no need to worry about the cable type, simply plug and play. Moreover, with the innovative energy-efficient technology, the TL-SF1016D can save up to 80%* of the power consumption and 70% of the packaging material can be recycled, making it an eco-friendly solution for your business network. High PerformanceTL-SF1016D Fast Ethernet Switch provides 16 10/100Mbps Auto-Negotiation RJ45 ports. All ports support Auto MDI/MDIX function, eliminating the need for crossover cables or Uplink ports. Featuring non-blocking switching architecture, TL-SF1016D forwards and filters packets at full wire-speed for maximum throughput. And IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode alleviate the traffic congestion and make TL-SF1016D work reliably.TP-LINK Green TechnologyThis new generation TL-SF1016D Fast Ethernet Switch features the latest innovative energy-efficient technologies that can greatly expand your network capacity with much less power. It automatically adjusts power consumption according to the link status and cable length to limit the carbon footprint of your network.It also complies with the EU’S RoHS, prohibiting the use of certain hazardous materials. Besides, 70% of the packaging material can be recycled. Easy to UseThe auto features of this switch make installation plug and play and hassle-free. No configuring is required. Auto MDI/MDIX eliminates the need for crossover cables. Auto-negotiation on each port senses the link speed of a network device (10, 100 Mbps) and intelligently adjusts for compatibility and optimal performance. The information provided on this page is a property of the manufacturer or the brand.To find out more, please visit: http://www.tp-link.com
Link - https://www.tp-link.com/us/home-networking/16-port-switch/tl-sf1016d/
LongDesc - What This Product DoesThe TL-SF1016D Fast Ethernet Switch is designed for SOHO (Small Office/Home Office) or workgroup users. All 16 ports support auto MDI/MDIX, no need to worry about the cable type, simply plug and play. Moreover, with the innovative energy-efficient technology, the TL-SF1016D can save the power consumption and 70% of the packaging material can be recycled, making it an eco-friendly solution for your business network.High PerformanceTL-SF1016D Fast Ethernet Switch provides 16 10/100Mbps Auto-Negotiation RJ45 ports. All ports support Auto MDI/MDIX function, eliminating the need for crossover cables or Uplink ports. Featuring non-blocking switching architecture, TL-SF1016D forwards and filters packets at full wire-speed for maximum throughput. And IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode alleviate the traffic congestion and make TL-SF1016D work reliably.TP-LINK Green TechnologyThis new generation TL-SF1016D Fast Ethernet Switch features the latest innovative energy-efficient technologies that can greatly expand your network capacity with much less power. It automatically adjusts power consumption according to the link status and cable length to limit the carbon footprint of your network.It also complies with the EU’S RoHS, prohibiting the use of certain hazardous materials. Besides, 70% of the packaging material can be recycled.Easy to UseThe auto features of this switch make installation plug and play and hassle-free. No configuring is required. Auto MDI/MDIX eliminates the need for crossover cables. Auto-negotiation on each port senses the link speed of a network device (10, 100 Mbps) and intelligently adjusts for compatibility and optimal performance.
LongProductName - 16× 10/100 Mbps RJ45 Ports, AUTO Negotiation/AUTO MDI/MDIX, 220V/50Hz, 200 x 142 x 40 mm
LongSummaryDescription - TP-Link 16-Port 10/100Mbps Desktop Switch. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100), Basic switching RJ-45 Ethernet ports quantity: 16. Full duplex. MAC address table: 2000 entries, Switching capacity: 3.2 Gbit/s. Networking standards: IEEE 802.3u, IEEE 802.3x. DC input voltage: 9 V. Power connector: DC-in jack. Wall mountable, Rack mounting
Management features - Switch type - Unmanaged
name - SF1016D Desktop Switch 16-Port 10/100Mbps
Name - TP-LINK TL-SF1016D
Name - TP-LINK | Switch | TL-SF1016D | Desktop | 10/100 Mbps (RJ-45) ports quantity 16 | Power supply type External
Network - 10G support - No
Network - Auto-negotiation - Yes
Network - Auto MDI/MDI-X - Yes
Network - Copper ethernet cabling technology - 100BASE-TX, 10BASE-T
Network - Ethernet LAN data rates - 10,100 Mbit/s
Network - Flow control support - Yes
Network - Full duplex - Yes
Network - Half duplex - Yes
Network - MAC address auto-learning supported - Yes
Network - Networking standards - IEEE 802.3u, IEEE 802.3x
Operational conditions - Heat dissipation - 11.01 BTU/h
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Other features > Power supply type - External
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 283 mm
Package features > Gross depth master carton - 590 mm
Package features > Gross height (mm) - 225 mm
Package features > Gross height master carton - 365 mm
Package features > Gross width (mm) - 68 mm
Package features > Gross width master carton - 465 mm
Package features > Net weight master carton - 12.24 kg
Package features > Packing quantity - 20 pc(s)
Package features > Palette Qty - 340 pc(s)
Package features > Paper/Pasteboard - 205 g
Package features > PET - 4 g
Package features > Plastic (No PET) - 11 g
Package features > Tare weight (kg) - 0.22 kg
Package features > Tare weight master carton - 1.702 kg
Package features > Volume (m3) - 0.0043299 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - Yes
Packaging content - User guide - Yes
Packaging data - AC adapter included - Yes
Packaging data - Package depth - 285 mm
Packaging data - Package height - 68 mm
Packaging data - Package type - Box
Packaging data - Package weight - 590 g
Packaging data - Package width - 223 mm
Performance - Fanless - Yes
Performance - Minimum system requirements - Microsoft Windows 98SE, NT, 2000, XP, Vista, Windows 7, MAC OS, NetWare, UNIX, Linux
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 16
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Fast Ethernet (10/100)
Ports & interfaces - Fast Ethernet (copper) ports quantity - 16
Ports & interfaces - Power connector - DC-in jack
Ports & interfaces > 10/100 Mbps (RJ-45) ports quantity - 16
Ports & interfaces > POE - No
Ports & interfaces > Predominant port type - 10/100 Mbps (RJ-45)
Power - DC input voltage - 9 V
Power - Input current - 0.6 A
Power - Power consumption (max) - 3.23 W
Power - Power source - DC
Power - Power supply included - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) - No
Primary port count - 16
producer - TP-LINK
Producer product family - Switch
Producer product name - TL-SF1016D
ProductName - 16-Port 10/100Mbps Desktop Switch
Shipping Box Depth Shipping/Package Box Dimensions - 28.7 cm
Shipping Box Height Shipping/Package Box Dimensions - 6.7 cm
Shipping box quantity - 1
Shipping Box Weight Shipping/Package Box Dimensions - 0.6 kg
Shipping Box Width Shipping/Package Box Dimensions - 22.5 cm
ShortSummaryDescription - TP-Link 16-Port 10/100Mbps Desktop Switch, Unmanaged, Fast Ethernet (10/100), Full duplex, Rack mounting, Wall mountable
Stck_Kart - 20
Stck_Pal - 0
Storno - Y
Sustainability - Sustainability compliance - Yes
Switching method - Store-and-forward
Technical details > Net weight - 0.392 kg
Technical details > Other features - Flow control, full duplex capability, auto-negotiation, auto-uplink (auto MDI/MDI-X), store and forward.
Technical details > Producer - TP-LINK
Technical specifications - Interface1610/100Mbps RJ45 Ports AUTO Negotiation/AUTO MDI/MDIX
External Power Supply100~240VAC, 50/60Hz
Dimensions (W X D X H)7.9*5.6*1.6 in. (200*142*40 mm)
CertificationFCC, CE, RoHs
Package Contents
-16-Port 10/10Mbps Desktop Switch TL-SF1016D
-Power Adapter
-User Guide
System RequirementsMicrosoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7, MAC® OS, NetWare®, UNIX® or Linux.
EnvironmentOperating Temperature: 0℃~40℃ (32℉~104℉);
Storage Temperature: -40℃~70℃ (-40℉~158℉);
Operating Humidity: 10%~90% non-condensing;
Storage Humidity: 5%~90% non-condensing
Title - TP-Link 16-Port 10/100Mbps Desktop Switch
Unit Box Height - 0.067
Unit Box Length - 0.287
Unit Box Width - 0.225
Unit Brutto Volume - 0.004327 cubm
Unit Gross Weight - 0.6 kg
Unit Net Weight - 0.42 kg
URL - https://www.tp-link.com/uk/business-networking/unmanaged-switch/tl-sf1016d/
Vendor Homepage - http://www.tp-link.com/en/products/details/?model=TL-SF1016D
vendpn - TL-SF1016D
Warranty - 24
Warranty - 24 month(s)
Warranty - 36 months
WarrantyInfo -
Weight & dimensions - Depth - 142 mm
Weight & dimensions - Height - 40 mm
Weight & dimensions - Width - 200 mm
