ID: 1150200
Product code: DS-3E0105P-E/M
Can be ordered 3 units Availability: 14 days after order approval
Warranty: 2 years
Hikvision DS-3E0105P-E/M(B)
Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
Delivery options More about shipping
- Delivery to Smartpost free of charge: 04.12.2024
- Delivery to Omniva parcel machine free of charge: 04.12.2024
- Piegāde uz DPD Pickup Paku Skapi free of charge: 04.12.2024
- Delivery to Latvian post office, parcel locker or Circle K free of charge: 04.12.2024
- Delivery to address in Riga 3.99 €: 04.12.2024
- Delivery to address in Latvia 6.99 €: 04.12.2024
- Delivery to Dateks.lv parcel drop-off point at 9 Zemitāna Street: 02.12.2024 after 15:00
Main product parameters All parameters
- Base-T speed: 10/100
- RJ-45 Ports: 4
Ports and equipment
Base-T speed
: 10/100
PoE Ports
: 4
RJ-45 Ports
: 4
Specifikācija
Number of fans
: Fanless
PoE Per-Port Power Budget
: 30 W
PoE Support
: Ir
PoE Total Power Budget
: 35 W
Weight (g)
: 200 g
Network cards
More detailed specification
Data transmission - MAC address table - 2000 entries
Data transmission - Packet buffer memory - 0.768 MB
Data transmission - Switching capacity - 1 Gbit/s
Design - Housing material - Metal
Design - Product colour - Blue
dimensionalWeight - 421
Management features - Switch type - Unmanaged
Network - 10G support - No
Network - Networking standards - IEEE 802.3af
Network - Networking standards - IEEE 802.3at
Operational conditions - Operating relative humidity (H-H) - 5 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 95%
Operational conditions - Storage temperature (T-T) - -40 - 85 °C
Packaging data - Package weight - 480 g
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 5
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Fast Ethernet (10/100)
Power - DC input voltage - 48 V
Power - Input current - 0.8 A
Power - Power consumption (max) - 38 W
Power over Ethernet (PoE) - Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) ports quantity - 4
Power over Ethernet (PoE) - Power over Ethernet (PoE) power per port - 30 W
producerCode - DS-3E0105P-E/M
productName - SWITCH POE HIKVISION DS-3E0105P-E/M(B)
productSize - Normal
sizeX - 195
sizeY - 108
sizeZ - 100
warrantyLength - 24
warrantyType - F
weight - 660
Weight & dimensions - Depth - 83.1 mm
Weight & dimensions - Height - 27.6 mm
Weight & dimensions - Weight - 200 g
Weight & dimensions - Width - 105 mm
