Accessories included - TCR100 router 18W power supply 2 x LTE Antenna (rotatable, SMA male) Ethernet cable (1.5 m) SIM adapter kit QSG (Quick Start Guide) RMS leaflet
Aero2 support - No
Antenna - Detachable external
Antenna - Antenna connector type - SMA
Antenna - Antenna design - Internal
Antenna - Antennas quantity - 2
Antenna - Detachable antenna(s) - Yes
Card reader - None
Certificates -
Color - Aluminium
Data transmission - LTE
Data transmission - UMTS
Description - TCR100 router This router was created based on experience gained in the field of industrial IoT to ensure reliable communication at home and in offices. Thanks to 4G LTE-A technology, you can use the TCR100 as a primary or backup connection source. Dual Ethernet and Dual-band Wi-Fi interfaces allow you to easily connect multiple devices. TCR100 features connectivity indicators, Wi-Fi and Wi-Fi Protected buttons for quick and simple setup .Reliable, secure and easy to use - TCR100 is the perfect choice for any home network.
Description - TELTONIKA IOT ROUTER TCR100 4G WI-FI HOME USER
Design - Housing material - Plastic
Design - LED indicators - LAN, Status, WAN, WLAN
Design - Product colour - Black
Design - Product type - Tabletop router
dimensionalWeight - 363
dimension depth - 70 mm
dimension height - 175 mm
Dimensions - 150 x 37 x 105 mm
dimension weight - 635 g
dimension width - 150 mm
ean - 4779027312811
Environment requirements - Operating temperature: -40 C to 75 C Humidity during operation: 10% to 90% non-condensing
Features - Built-in processor - Yes
Features - Flash memory - 16 MB
Features - Internal memory - 128 MB
Features - Operating system installed - RutOS
Features - Processor architecture - MIPS 24Kc
Features - Processor frequency - 650 MHz
Features - Processor manufacturer - Qualcomm
Features - Processor model - Qualcomm Atheros QCA9531
guarantee - 24
guarantee_type - normal
Height - 70.000000
I/O ports - 1 x 10/100 Mbit/s
I/O ports - 1 x 10/100 Mbit/s WAN
I/O ports - 1 x SIM card slot
Length - 150.000000
Logistics data - Harmonized System (HS) code - 85176990
LTE network - 700 MHz
LTE network - 800 MHz
LTE network - 850 MHz
LTE network - 900 MHz
LTE network - 1500 MHz
LTE network - 1800 MHz
LTE network - 2100 MHz
LTE network - 2300 MHz
LTE network - 2500 MHz
LTE network - 2600 MHz
Management, monitoring, configuration - Network: NAT, Static/Dynamic routing, Firewall, OpenVPN, IPsec Unique network features: VLAN, Load balancing, Mobile quota control, WEB Filter, Network Backup, Auto Failover Connection monitoring: Ping Reboot, Periodic Reboot, Wget Reboot, LCP and ICMP for link inspection Authentication: Pre-shared key, digital certificates, X.509 certificates Settings: Update FW without losing current configuration Management and monitoring: WEB UI, SSH, SMS, SNMP, JSON-RPC, FOTA, RMS Supported languages: Busybox shell, Lua, C, C++ Development tools: SDK package with build environment provided
Management features - Reset button - Yes
Management features - Web-based management - Yes
Management features - WPS push button - Yes
Manufacturer - TELTONIKA
ManufacturerPartNumber - TCR100000000
Mobile network - 3G - Yes
Mobile network - 3G standards - DC-HSDPA
Mobile network - 3G standards - HSUPA
Mobile network - 3G standards - WCDMA
Mobile network - 4G - Yes
Mobile network - 4G standard - LTE
Mobile network - 5G - Yes
Mobile network - Mobile network generation - 4G
Model - TCR100
name - Router LTE TCR100 (Cat 6), 3G, Wifi, 1xEthernet
Network - Cabling technology - 10/100Base-T(X)
Network - Ethernet LAN - Yes
Network - Ethernet LAN data rates - 10
Network - Ethernet LAN data rates - 100 Mbit/s
Network - Ethernet LAN interface type - Fast Ethernet
Network - Load balancing system - Yes
Network - Networking standards - IEEE 802.3
Network - Networking standards - IEEE 802.3u
Network - Networking standards - IEEE 802.11r
Network - Networking standards - IEEE 802.11s
Number of antennas - Two connectors
Operating frequency - 2,4 GHz
Operating frequency - 5 GHz
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - -40 - 75 °C
Other features - 4G network (LTE) - Cat 6; DC-HSDPA; HSUPA; WCDMA Processor: Qualcom MIPS 24Kc CPU; 650MHz RAM: 128 MB, DDR2 RAM Internal memory: 16 MB, SPI Flash Buttons: Wi-Fi On/Off, Activate WPS, Reset
Packaging content - AC adapter included - Yes
Packaging content - Antenna included - Yes
Packaging content - Cables included - LAN (RJ-45)
Packaging content - Quick start guide - Yes
Packaging data - Number of products included - 1 pc(s)
Packaging data - Package depth - 148 mm
Packaging data - Package height - 71 mm
Packaging data - Package type - Box
Packaging data - Package width - 173 mm
PeriodofWarranty - 2 Y
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces - USB port - No
Power - AC input voltage - 100 - 240 V
Power - Output current - 1 A
Power - Output voltage - 12 V
Power - Power consumption (typical) - 3.7 W
Power - Power source type - AC
Power - Power supply - 18 W
Power supply - 9 - 30 VDC, 4-pin DC connector
producer - TELTONIKA
producerCode - TCR100
productName - Teltonika TCR100 wireless router Fast Ethernet Dual-band (2.4 GHz / 5 GHz) 4G Black
productSize - SmallPallet
Protocols - Supported network protocols - TCP, UDP, IPv4, IPv6, ICMP, NTP, DHCP, DNS, HTTP, HTTPS, SSL v3, TLS, ARP, PPPoE, UPNP, SSH, Telnet, SNMP
Security - Authetication: Pre-shared key, digital certificates, X.509 certificates Firewall: Pre-configured firewall rules can be enabled via WebUI, unlimited firewall configuration via CLI; DMZ; NAT; NAT-T Attack prevention: DDOS prevention (SYN flood protection, SSH attack prevention, HTTP/HTTPS attack prevention), port scan prevention (SYN-FIN, SYN-RST, X-mas, NULL flags, FIN scan attacks) VLAN: Tag based VLAN separation Mobile quota control: Option to set custom data limit WEB filter: Blacklist for blocking unwanted out websites, Whitelist for specifying allowed sites only Access control: Flexible access control of TCP, UDP, ICMP packets, MAC address filter WiFi security: WPA3-EAP, WPA3-SAE, WPA2-Enterprise-PEAP, WPA2-PSK, WEP; AES-CCMP, TKIP, Auto Cipher modes, client separation
Security - Firewall - Yes
Security - Security algorithms - AES-CCMP
Security - Security algorithms - SNMP
Security - Security algorithms - SSH
Security - Security algorithms - TKIP
Security - Security algorithms - WEP
Security - Security algorithms - WPA2-Enterprise
Security - Security algorithms - WPA2-PSK
Security - Security algorithms - WPA3-Enterprise
Security - Security algorithms - WPA3-SAE
SIM card - Mini
sizeX - 148
sizeY - 71
sizeZ - 173
Software - RutOS (OpenWrt based Linux OS)
Special functions -
Standards - 802.3
Standards - 802.3u
Standards - 802.11a
Standards - 802.11ac
Standards - 802.11b
Standards - 802.11e
Standards - 802.11g
Standards - 802.11n
Standards - 802.11r
Standards - 802.11s
System Requirements -
Type - GSM 3G/4G
UMTS network - 800 MHz
UMTS network - 850 MHz
UMTS network - 1800 MHz
UMTS network - 2100 MHz
vendpn - TCR100 000000
WAN connection - 3G/4G USB modem compatibility - No
WAN connection - DSL WAN - Yes
WAN connection - Ethernet WAN - Yes
WAN connection - SIM card slot - Yes
WAN connection - WAN connection type - RJ-45
warrantyLength - 24
warrantyType - G
Weight - 0.600000
Weight - 376 g
weight - 841170
Weight & dimensions - Depth - 105 mm
Weight & dimensions - Height - 37 mm
Weight & dimensions - Weight - 376 g
Weight & dimensions - Width - 150 mm
Width - 175.000000
Wireless LAN features - Top Wi-Fi standard - Wi-Fi 5 (802.11ac)
Wireless LAN features - Wi-Fi band - Dual-band (2.4 GHz / 5 GHz)
Wireless LAN features - Wi-Fi standards - 802.11a
Wireless LAN features - Wi-Fi standards - 802.11b
Wireless LAN features - Wi-Fi standards - 802.11g
Wireless LAN features - Wi-Fi standards - Wi-Fi 4 (802.11n)
Wireless LAN features - Wi-Fi standards - Wi-Fi 5 (802.11ac)
