MikroTik mAP

Name: MikroTik mAP
Brand: MikroTik
SKU: 270568
Price: 43.3 EUR
Availability: InStock

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.

ID: 270568 Product code: RBmAP2nD

In stock 19 units

Warranty: 2 years (Warranty for business entities 1 year)

Compare

Delivery options More about shipping

Delivery to Smartpost free of charge: on Wednesday, 27.11.2024
Delivery to Omniva parcel machine free of charge: on Wednesday, 27.11.2024
Piegāde uz DPD Pickup Paku Skapi free of charge: on Wednesday, 27.11.2024
Delivery to Latvian post office, parcel locker or Circle K free of charge: on Wednesday, 27.11.2024
Delivery to address in Riga 3.99 €: on Wednesday, 27.11.2024
Delivery to address in Latvia 6.99 €: on Wednesday, 27.11.2024
Delivery to Dateks.lv parcel drop-off point at 9 Zemitāna Street: on Monday, 25.11.2024 after 15:00

Main product parameters All parameters

Speed index: N/A
Type of device: Access Point

Basic information

Speed index : N/A

Type of device Access Point

Access Point - bezvadu piekļuves punkts, kas nodrošina kabeļu tīkla paplašināšanas pārraidi bezvadu tīklā izmantojot vienu LAN pieslēgvietu. Access point nav rūteris, un nespēj sadalīt vienu interneta pieslēguma adresi vairākiem datoriem, tamdēļ šo iekārtu slēdziet tikai aiz esoša kabeļu rūtera.

Router, jeb maršrutētājs - bezvadu piekļuves punkts, kas nodrošina viena interneta pieslēguma sadalīšanu vairākiem datoriem, gan caur tīkla vadiem, gan bezvadu tīklā. Parasti bezvadu maršrutētājam ir viena kabeļu interneta pieslēgvieta, četras datoru pieslēgvietas (kuras var papildināt, izmantojot switch komutatoru) un antenas, kas nodrošina apraidi datoriem un citām WiFi iekārtām.

Range Extender - bezvadu tīkla apraides attāluma pastiprinātājs. Paredzēts esoša signāla pastiprināšanai, lai palielinātu uzveršanas un pārraides attālumu.

Wifi adapter - Bezvadu tīkla karte, paredzēta datora pieslēgšanai pie bezvadu WiFi rūtera vai piekļuves punkta. PCI, PCI-E ir paredzēti galddatoriem, savukārt PCMCIA un USB - portatīvajiem datoriem. Jāpiebilst, ka lielākā daļa portatīvo datoru jau rūpnīcā tiek komplektēti ar bezvadu tīkla kartēm.

USB tīkla karte ir pēdējā izvēle, jo USB2.0 caurlaidības ātrums ir samērā zems ~22MB/s, kas nozīmē to, ka netiks izmantots bezvadu tīkla maksimālais iespējamais ātrums. Ja ir iespēja, labāk izvēlēties kādu citu pieslēguma veidu.

Functionality

3G/4G support Nav

A possibility to put the SIM card of mobile operators or the USB Dongle adapter in the router providing access to the 3G mobile Internet.

Prior to buying a router with the 3G support you should verify whether the device supports the 3G USB Dongle receiver of the particular mobile communications operator at the manufacturer's website.

Band mode N/A

SingleBand is a standard wireless technology characteristic of all the modern wireless devices.

DualBand is 2.4GHz with an additional 5.0GHz channel providing better receiving of the signal and more stable high-speed operation. For using this function both devices, i.e. the router and the wireless network card, have to support the DualBand mode.

Ethernet 10/100

LAN or ethernet cables connection slots operational mode.

10/100 MB.s is the standard speed characteristic of almost all the routers.

10/100/1000 MB.s, or GigaBit is tens of times faster standard which, in combination of GigaBit LAN network cards, provides great data transmission speed advantages between computers connected within the internal network. This solution is usually required in offices where large data volumes are copied between computers or fast Internet connection is used (no ~30 MB/s) simultaneously in several computers.

Ports and equipment

LAN ports : 0

Wireless

Without
WiFi Adapter USB (+8.76 €)
Gembird Adapter Mini USB WiFi 300 Mbps
Alternatives
WiFi Adapter PCI-E 1x (+13.34 €)
TP-LINK TL-WN781ND, PCI-E x1 WiFi Adapter
Alternatives

More detailed specification

10Base-T / 100Base-TX Ports - 2
Accessories included -
Activity Status indicators - Yes
Antenna Gain - 1.2 dB
Antenna gain - 1.2 dBi
brand - MikroTik
category - MikroTik > Wi-Fi mājai un ofisam > mAP
Category 1 - Netzwerk
Category 2 - Accesspoints
Category Code - WAP
Code - RBmAP2nD
Color - Black
Color - White
Description - mAP (micro Access Point) jest niewielkich rozmiarów bezprzewodowym punktem dostępowym Dual-Chain 2.4GHz z pełnymi możliwościami RouterOS. Działa również jako PoE injector - drugi port Ethernet dostarcza do 500mA energii do innego urządzenia, np. można do niego podłączyć urządzenie SXT CPE.
Description - The mAP (micro Access Point) is a tiny size wireless Dual-Chain 2.4GHz Access Point with full RouterOS capabilities. It is very portable, since it accepts power from a wide variety of sources - USB, Passive PoE and power jack. It also works as a PoE injector - the second Ethernet port provides up to 500mA of power to another device, for example, you can connect a SXT CPE device to it.
dimension depth - 55 mm
dimension height - 170 mm
Dimensions - 68 x 68 x 19 mm
Dimensions - 68 x 68 x19mm
dimension weight - 200 g
dimension width - 70 mm
EAN - 2000001037492
ean - 4752224004291
EAN - 4752224004291
Features > MU-MiMO - No
Full Description Line - mAP // RBmAP2nD|Type Wireless Access Point|IEEE 802.3af|IEEE 802.3at|IEEE 802.11 b/g|IEEE 802.11n|Antenna Gain 1.2 dB|Activity|Link|Power|Dimensions 68 x 68 x19mm
Gross weight - 0.38 kg
guarantee - 12
guarantee_type - normal
height - 0.067 m
I/O ports - 2 x 10/100 Mbit/s
IEEE 802.3af Network standard - Yes
IEEE 802.3at Network standard - Yes
IEEE 802.11 b/g Network standard - Yes
IEEE 802.11n Network standard - Yes
length - 0.18 m
Link Status indicators - Yes
Management, monitoring, configuration -
Manufacturer - MikroTik
Model name - mAP // RBmAP2nD
mpn - RBmAP2nD
MPN - RBMAP2ND
name - Access point 2.4GHz 2FE RBmAP2nD
Name - MikroTik RBmAP2nD
Name - MikroTik | mAP RBmAP2nD | 802.11n | 10/100 Mbit/s | Ethernet LAN (RJ-45) ports 2 | MU-MiMO No | PoE in/out
Network architecture - FastEthernet
Network Device Type - Wireless Access Point
Operating frequency - 2,4 GHz
Other features - Procesor: QCA9531 Liczba rdzeni procesora: 1 Częstotliwość nominalna procesora: 650 MHz System operacyjny: RouterOS Rozmiar pamięci RAM: 64 MB Rozmiar przechowywania: 16 MB MTBF: Około 100 000 godzin w 25C
Package features > Gross depth (mm) - 176 mm
Package features > Gross height (mm) - 55 mm
Package features > Gross width (mm) - 73 mm
Package features > Packing quantity - 1 pc(s)
Package features > Palette Qty - 1223 pc(s)
Package features > Paper/Pasteboard - 100 g
Package features > Tare weight (kg) - 0.1 kg
Package features > Volume (m3) - 0.00070664 m³
Package features > WEE classification - CL109:6:2017-04-01
Performance > Ethernet LAN data rates - 10/100 Mbit/s
Ports & interfaces > Ethernet LAN (RJ-45) ports - 2
Ports & interfaces > POE - PoE in/out
Power Status indicators - Yes
Power supply - Liczba wejść DC: 3 (gniazdo DC, PoE-IN, MicroUSB) Napięcie wejściowe gniazda DC: 8-57 V Maksymalne zużycie energii: 5 W Napięcie wejściowe PoE: 12-57 V
producer - Mikrotik
Producer product name - mAP RBmAP2nD
Security -
Shipping Box Depth Shipping/Package Box Dimensions - 18 cm
Shipping Box Height Shipping/Package Box Dimensions - 5.8 cm
Shipping box quantity - 1
Shipping Box Weight Shipping/Package Box Dimensions - 0.255 kg
Shipping Box Width Shipping/Package Box Dimensions - 7.5 cm
Software -
Special functions -
Standards - 802.11b
Standards - 802.11g
Standards - 802.11n
System Requirements -
Technical details > Net weight - 0.28 kg
Technical details > Producer - MikroTik
Technical details > Software type - RouterOS (Level 4)
title - MikroTik mAP
Unit Box Height - 0.058
Unit Box Length - 0.18
Unit Box Width - 0.075
Unit Brutto Volume - 0.000783 cubm
Unit Gross Weight - 0.255 kg
Unit Net Weight - 0.15 kg
Vendor Homepage - mikrotik.com/product/RBmAP2nD
vendpn - RBmAP2nD
Warranty - 12
Warranty - 12 month(s)
Warranty - 12 months
Weight - 0.24
weight - 0.265 kg
width - 0.08 m
Wireless LAN features > Wi-Fi band - 802.11n
