Accessories included -
Amplification - 20 dBm
Antenna - External
Antenna - Fixed external
Antenna - Antenna features - Detachable antenna
Antenna - Antenna gain level (max) - 4 dBi
Antenna - Antennas quantity - 2
Available bandwidth - 1167 Mbps
Box Weight Brutto (kg) - 7.41 kg
brand - Ubiquiti
category - Mājas un biroju tīkli > Piekļuves punkti > Āra piekļuves punkti
Category - Root/Electronics/Networks and communication/Access points
Category 1 - Netzwerk
Category 2 - Accesspoints
Category Code - WOD
Category_1 - Network and Servers
Category_2 - Network - Switches and Hubs
Certifications - CE, FCC, IC
Channels Quantity - 2
Code - UAP-AC-M
Color - White
Data Bit Rate - 867 Mbps
Data Link Protocol Supports - Gigabit Ethernet/Fast Ethernet/Ethernet IEEE 802.11a/b/g/n/ac
Data transmission speed - 867 Mbps
Depth (mm) - 34.4 mm
Description - Powerful, external, 2x2 MIMO, dual band 802.11ac UAP-AC-M access point Expand your Wi-Fi network outdoors with the UniFi AC Mesh access point, which is part of the Ubiquiti Networks UniFi Enterprise Wi-Fi system. UAP-AC-M is a high-performance dual-band 2x2 MIMO access point, 802.11ac outdoors, with speeds up to 1167 Mb / s. It has two RP-SMA connectors that can be used with attached dual-band omnidirectional antennas or with the optional dual-band antenna for individual pattern shaping.
Description - UniFi is the revolutionary Wi-Fi system that combines enterprise performance, unlimited scalability, and a central management controller. The UniFi AC Mesh APs have a refined industrial design and can be easily installed using the included mounting hardware. Easily accessible through any standard web browser, the UniFi Controller software is a powerful software engineideal for high-density client deployments requiring low latency and high uptime performance. Use the UniFi Controller software to quickly configure and administer an enterprise Wi-Fi network – no special training required. RF map and performance features, real-time status, automatic UAP device detection, and advanced security options are all seamlessly integrated.
Design - Certification - CE, FCC, IC
Design - Internal - No
Design - Placement - Wall
Design - Product colour - White
Design - Reset button - Yes
Device Location - External
dimensionalWeight - 440
dimension depth - 80 mm
dimension height - 245 mm
Dimensions - 353 x 46 x 34.4 mm
Dimensions - 353 x 46 x 34.4 mm
dimension weight - 640 g
dimension width - 115 mm
EAN - 810354025792
ean - 810354025792
EAN - 0810354025792
EAN Code - 810354025792
Eans - 0810354025792
EAN_code - 0810354025792
Encryption Algorithm - TKIP WEP WPA-PSK WPA WPA2 AES
External Color - White
Features - 2.4 GHz - Yes
Features - 5 GHz - Yes
Features - Maximum data transfer rate - 1167 Mbit/s
Features - MIMO - Yes
Features - Networking standards - IEEE 802.3af
Features - Number of users - 250 user(s)
Features - Quality of Service (QoS) support - Yes
Features - VLAN support - Yes
Features - Wi-Fi Multimedia (WMM)/(WME) - Yes
Features > MU-MiMO - Yes
Full Description Line - Network Device Type Wireless Access Point|Data transmission speed 867 Mbps|Dimensions 353 x 46 x 34.4 mm
Gross Weight Kg - 0,8
guarantee - 12
guarantee_type - normal
height - 0.11 m
Height (mm) - 353 mm
I/O ports - 1 x 10/100/1000 Mbit/s
Image - https://content.it4profit.com/pimg/s/resize/900x900x900x900/200210150011375492.jpg
Image - https://content.it4profit.com/pimg/s/resize/900x900x900x900/200210150011393753.jpg
Image - https://content.it4profit.com/pimg/s/resize/900x900x900x900/200210150011402356.jpg
Included Accessories - Mount kit PoE Adapter
Interface - Ethernet/Wi-Fi
LAN - 1 (RJ-45)
length - 0.25 m
Link - https://store.ubnt.com/products/unifi-ac-mesh-ap
Local Area Network Architecture - 10Base-T/100Base-TX/1000Base-T Wi-Fi
Logistics data - Harmonized System (HS) code - 85176990
Management, monitoring, configuration -
Manufacturer - Ubiquiti
Manufacturer Code - UAP-AC-M
Manufacturer Name - Ubiquiti Networks
Manufacturer_code - UAP-AC-M
Maximum Operating Ambient Temperature - 70 °C
Maximum Operating Humidity - 95 %
Minimum Operating Ambient Temperature - -30 °C
Minimum Operating Humidity - 5 %
mpn - UAP-AC-M
MPN - UAP-AC-M
name - Access Point MESH UAP-AC-M
Name - Ubiquiti UAP-AC-M
Name - Ubiquiti UAP-AC-M 1GE/AC1200/AP - AC Mesh Outdoor Accesspoint
Name - Ubiquiti | UniFi | UAP-AC-M Mesh Access Point | 802.11ac | 2.4/5 | 867 Mbit/s | 10/100/1000 Mbit/s | Ethernet LAN (RJ-45) ports 1 | MU-MiMO Yes | PoE in
Network architecture - GigabitEthernet
Network Device Type - Wireless Access Point
Networking > Wi-Fi - Yes
Networking > Wi-Fi standards - 802.11a/b/g/n/ac
Networking Compliant Standards - IEEE 802.1Q(VLAN)
Networking Features - PoE
Nominal Weight - 0.152 kg
Number of antennas - 2
Operating temperature range - -30 to 70° C
Operational conditions - Operating relative humidity (H-H) - 5 - 95%
Operational conditions - Operating temperature (T-T) - -30 - 70 °C
Other features -
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 452 mm
Package features > Gross height (mm) - 286 mm
Package features > Gross width (mm) - 243 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 28 pc(s)
Package features > Paper/Pasteboard - 30.06 g
Package features > Plastic (No PET) - 3.34 g
Package features > Tare weight (kg) - 0.334 kg
Package features > Volume (m3) - 0.031413096 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - Yes
Package Type - Box
Packs in Box - 10
Pack Weight Brutto (kg) - 0.741 kg
Pack Weight Netto (kg) - 0.411 kg
PDF - http://www.blobs.lt/products/3/8/0/9/9/1/cc8bae262b8d64b69cf61c5b4614b34a/original.pdf
Performance > Ethernet LAN data rates - 10/100/1000 Mbit/s
Performance > Frequency band - 2.4/5
Performance > Wi-Fi data rate (max) - 867 Mbit/s
Pieces in pack - 1
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces > Ethernet LAN (RJ-45) ports - 1
Ports & interfaces > POE - PoE in
Power - Power consumption (typical) - 8.5 W
Power - Power over Ethernet (PoE) - Yes
Power - Power supply - 24 W
Power consumption - 8.5 Watts
Power supply - Adapter 24 V, 0,5 A Gigabit PoE
Power supply requirements - 24V, 0.5A Gigabit PoE Adapter
producer - UBIQUITI
Producer - Ubiquiti
producerCode - UAP-AC-M
ProducerCode - UAP-AC-M
Producer product family - UniFi
Producer product name - UAP-AC-M Mesh Access Point
ProductCard - https://content.it4profit.com/itshop/itemcard_cs.jsp?ITEM=181227114954565433&THEME=asbis&LANG=lv
ProductCategory - Tīkla produkti
ProductCode - UAP-AC-M-EU
ProductDescription - Ubiquiti UniFi Indoor/Outdoor AP, AC Mesh,2x2 MIMO,300 Mbps(2.4GHz),867 Mbps(5GHz),Passive PoE,24V,2 External Dual-Band Omni Antennas,Wall/Pole/Fast-Mount Kit Included,250+ Concurrent Clients,EU
productName - Ubiquiti Unifi AC Mesh 1167 Mbit/s White Power over Ethernet (PoE)
productSize - Normal
ProductType - Networking - Wireless Access Point
Radio Output Power - 4 dBi
Security -
Security - Number of SSID supported - 4
Security - Service Set Identifier (SSID) features - Hidden SSID
Shipping Box Depth Shipping/Package Box Dimensions - 25 cm
Shipping Box Height Shipping/Package Box Dimensions - 11.1 cm
Shipping box quantity - 1
Shipping Box Weight Shipping/Package Box Dimensions - 0.67 kg
Shipping Box Width Shipping/Package Box Dimensions - 8.5 cm
ShortDescription -
Short description - Ubiquiti Access-Point UniFi Mesh UAP-AC-M 802.11ac incl. PoE adapter
sizeX - 250
sizeY - 110
sizeZ - 80
Software -
Special functions -
Standards - 802.1Q
Standards - 802.11ac
System Requirements -
Technical details > Gross weight - 1.06 kg
Technical details > Net weight - 0.726 kg
Technical details > Producer - Ubiquiti
Technical details > Warranty - 12 month(s)
Technical_details - LAN: 1x 1000Base-T (PoE-PD) Wireless: WLAN 802.11a/b/g/n/ac, simultaneous Transfer rate: 300Mbps (2.4GHz), 867Mbps (5GHz) Security: WEP, WPA, WPA2 Antennas: 2x external (detachable) Connectors: not available Power consumption: 8.5W (operation) Dimensions: 353x46x34mm Special features: VLAN, Outdoor
title - Ubiquiti UniFi AC Mesh
Unit Box Height - 0.25
Unit Box Length - 0.09
Unit Box Width - 0.11
Unit Brutto Volume - 0.002359 cubm
Unit Gross Weight - 0.67 kg
Unit Net Weight - 0.152 kg
Vendor - UBIQUITI
Vendor Homepage - dl.ubnt.com/datasheets/unifi/UniFi_AC_Mesh_DS.pdf
vendpn - UAP-AC-M-EU
Warranty - 12
Warranty - 12 months
Warranty - 12 months warranty from the date of sale
warrantyLength - 24
Warranty Products Returnable - Yes
Warranty Term (month) - 24
Warranty Term Notes - 24 months - for EU
warrantyType - G
Warranty Validation Criteria - Serial Number
Weight - 0,67
Weight - 0.68
weight - 0.74 kg
Weight - 152 g
weight - 675
Weight & dimensions - Depth - 34 mm
Weight & dimensions - Height - 353 mm
Weight & dimensions - Weight - 152 g
Weight & dimensions - Width - 46 mm
Wi-Fi Band Frequency - 2.4 GHz/5 GHz
width - 0.12 m
Width (mm) - 46 mm
Wireless LAN features > Wi-Fi band - 802.11ac
