10/100/1000M LAN Ports - 3
Antenna - Antenna design - External
Antenna - Antenna gain level (max) - 5 dBi
Antenna - Antennas quantity - 4
Antenna - Antenna type - 2x2
Available bandwidth - 1800 Mbps
Brand - Dahua Technology
BrandPartCode - DH-AX18
Category - Wireless Routers
Category Code - WRO
CnCode CnCode - 85176200
Colour - Black
Description - "AX1800 Wireless Router > 6th Gen Wireless Technology. > 1.8 Gbps Wireless speed (574 Mbps@2.4 GHz, 1201Mbps@5 GHz). > Backward compatible (IEEE 802.11 b/g/n/ac/ax standard). > Beamforming for better Coverage. > OFDMA and 1024-QAM. > Bi-directional MU-MIMO. > WiFi protected Access(WPA/WPA2/WPA3). > Guest Wi-Fi. > Parental Control."
Design - Indication light - Yes
Design - Product colour - Black
Design - Product type - Tabletop router
Dimensions - 252 × 155 × 178 mm
Features - Firmware upgradeable - Yes
Features - Flash memory - 256 MB
Features - Internal memory - 128 MB
Features - Number of simultaneously connected devices (max) - 32
Full Description Line - AX18|Wireless Router|Available bandwidth 1800 Mbps|Wi-Fi 6|IEEE 802.11 b/g|IEEE 802.11n|IEEE 802.11ac|IEEE 802.11ax|3x10/100/1000M|WPA - Wi-Fi Protected Access|WPA2 - Wi-Fi Protected Access|Wireless Frequency Range 2.4/5 GHz|Included Accessories 1 × Power adapter,1 × Ethernet cable,1 × Quick Start Guide,1 × Legal and Regulatory Information|Power supply requirements 12 VDC,1 A|Colour Black|Dimensions 252 × 155 × 178 mm
GTIN - 6923172562463
IEEE 802.11 b/g Network standard - Yes
IEEE 802.11ac Network standard - Yes
IEEE 802.11ax Network standard - Yes
IEEE 802.11n Network standard - Yes
Included Accessories - 1 × Power adapter,
1 × Ethernet cable,
1 × Quick Start Guide,
1 × Legal and Regulatory Information
LAN \ WAN ports - 1
LongDesc - DH-AX18 Gigabit Wireless Router provides wireless access to a large number of users, and has a wide signal coverage and fast wireless speed. It complies with the IEEE 802.11ax standard, and its wireless speed reaches up to 1,775 Mbps, allowing smooth internet access. Using MU-MIMO technology, it supports concurrent connections, greatly reducing network latency. It also uses WPA3 Encryption to protect the device against network attacks. The router is energy efficient, using TWT technology to reduce power consumption. It can be managed through the WiLynk app and provides wireless networks, making it a great choice to use with the latest wireless technology.
LongProductName - 1.8 Gbps, IEEE 802.11b/g/n/ac/ax, 2.4-5 Ghz, 4x RJ-45, 128 MB RAM, 256 MB Flash, 12 VDC, 1 A, 0.43 kg
LongSummaryDescription - Dahua Technology AX18 AX1800 Wireless Router. WAN connection type: RJ-45. Wi-Fi band: Dual-band (2.4 GHz / 5 GHz), Top Wi-Fi standard: Wi-Fi 6 (802.11ax), WLAN data transfer rate (max): 1800 Mbit/s. Ethernet LAN interface type: Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s, Cabling technology: 10/100/1000Base-T(X). Number of data streams: 2x2. Security algorithms: WPA, WPA-PSK, WPA2-PSK, WPA3-SAE
Management features - MIMO - Yes
Management features - MU-MIMO technology - Yes
Management features - Number of data streams - 2x2
Management features - Quality of Service (QoS) support - Yes
Management features - Reset button - Yes
Management features - Web-based management - Yes
Management features - WPS push button - Yes
Model name - AX18
Network - Automatic channel selection - Yes
Network - Cabling technology - 10/100/1000Base-T(X)
Network - Dynamic DNS (DDNS) - Yes
Network - Ethernet LAN - Yes
Network - Ethernet LAN data rates - 10,100,1000 Mbit/s
Network - Ethernet LAN interface type - Gigabit Ethernet
Network - Receiver sensitivity - 2.4 GHz
11n HT20_MCS0: -95 dbm
11n HT20_MCS7: -75 dbm
11n HT40_MCS0: -92 dbm
11n HT40_MCS7: -72 dbm
11ax HE20_MCS0: -95 dbm
11ax HE20_MCS11: -65 dbm
11ax HE40_MCS0: -92 dbm
11ax HE40_MCS11: -62 dbm
5 GHz
11ac VHT80_MCS0: -89 dbm
11ac VHT80_MCS9:-62 dbm
11ax HE80_MCS0: -89 dbm
11ax HE80_MCS11:-59 dbm
Network - VPN support - L2TP
PPTP
Network Device Type - Wireless Router
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage temperature (T-T) - -20 - 70 °C
Other features - Bandwidth (first) - 2.484 GHz
Other features - Bandwidth (second) - 5.85 GHz
Packaging content - AC adapter included - Yes
Packaging content - Cables included - LAN (RJ-45)
Packaging content - Quick installation guide - Yes
Packaging data - Number of products included - 1 pc(s)
Packaging data - Package depth - 309 mm
Packaging data - Package height - 61 mm
Packaging data - Package weight - 730 g
Packaging data - Package width - 298 mm
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 4
Ports & interfaces - USB port - No
Power - External power adapter - Yes
Power - Output current - 1 A
Power - Output voltage - 12 V
Power - Power consumption (typical) - 12 W
Power - Power source type - DC
Power supply requirements - 12 VDC,1 A
ProductName - AX18 AX1800 Wireless Router
Product Net Weight - 0.43 kg
Protocols - DHCP client - Yes
Protocols - DHCP server - Yes
Security - Network address translation (NAT) - Yes
Security - Parental control - Yes
Security - Security algorithms - WPA, WPA-PSK, WPA2-PSK, WPA3-SAE
Security - System event log - Yes
Shipping Box Depth Shipping/Package Box Dimensions - 31.5 cm
Shipping Box Height Shipping/Package Box Dimensions - 30.5 cm
Shipping Box Weight Shipping/Package Box Dimensions - 0.73 kg
Shipping Box Width Shipping/Package Box Dimensions - 6.5 cm
ShortSummaryDescription - Dahua Technology AX18 AX1800 Wireless Router, Wi-Fi 6 (802.11ax), Dual-band (2.4 GHz / 5 GHz), Ethernet LAN, Black, Tabletop router
Title - Dahua Technology AX18 AX1800 Wireless Router
Unit Box Height - 0.305
Unit Box Length - 0.315
Unit Box Width - 0.065
Unit Calculated Volume - 0.006245 cubm
Unit Calculated Weight - 0.73 kg
Units per Shipping Box - 1
URL - https://www.dahuasecurity.com/products/All-Products/Transmission/IT-Channel-Products/Wireless-Router/AX18
Vendor Homepage - www.dahuasecurity.com/ceen/products/All-Products/Transmission/Wireless-Devices/Wireless-Router/AX18
WAN connection - 3G/4G USB modem compatibility - No
WAN connection - DSL WAN - No
WAN connection - Ethernet WAN - Yes
WAN connection - SIM card slot - No
WAN connection - WAN connection type - RJ-45
Warranty - 36 months
WarrantyInfo -
Weight & dimensions - Depth - 252 mm
Weight & dimensions - Height - 178 mm
Weight & dimensions - Weight - 430 g
Weight & dimensions - Width - 155 mm
Wi-Fi 6 Network standard - Yes
Wireless Frequency Range - 2.4/5 GHz
Wireless LAN features - Channel bandwidth - 80 MHz
Wireless LAN features - Channels quantity - 165 channels
Wireless LAN features - Maximum indoor range - 63 m
Wireless LAN features - Top Wi-Fi standard - Wi-Fi 6 (802.11ax)
Wireless LAN features - Wi-Fi band - Dual-band (2.4 GHz / 5 GHz)
Wireless LAN features - Wi-Fi standards - 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Wireless LAN features - WLAN data transfer rate (first band) - 574 Mbit/s
Wireless LAN features - WLAN data transfer rate (max) - 1800 Mbit/s
Wireless LAN features - WLAN data transfer rate (second band) - 1201 Mbit/s
WPA - Wi-Fi Protected Access Security - Yes
WPA2 - Wi-Fi Protected Access Security - Yes
