Accessories included - User manual
Active power - 480 W
Apparent power - 800 VA
ARTIKEL1 - LIEBERT ITON 800VA E 230V
ARTIKEL2 - LIEBERT ITON USV DESKTOP 800VA
Backup time (100% load) - 1.5 min
Battery - Battery capacity - 9 Ah
Battery - Battery recharge time - 4 h
Battery - Battery technology - Sealed Lead Acid (VRLA)
Battery - Battery voltage - 12 V
Battery - Number of batteries supported - 1
Battery - Typical backup time at half load - 3 min
Battery capacity - 9 Ah
Brand - Vertiv
BrandPartCode - LI32121CT00
Breite - 0.23
Category - Root/Accessories | Exploitation/Power supply/UPSs and power strips/UPSs
Category - Uninterruptible Power Supplies (UPSs)
Charging time - 4 h
Chassis type - Tower
Color - Black
Color - Gray
Connectors - None
Design - Certification - CE
Design - Form factor - Tower
Design - International Protection (IP) code - IP20
Design - LED indicators - Yes
Design - Product colour - Black
Design - Safety - IEC/EN/AS 62040-1-1
dimension depth - 140 mm
dimension height - 220 mm
Dimensions - - Width: 100 mm
- Height: 142 mm
- Depth: 287 mm
dimension weight - 5340 g
dimension width - 330 mm
ean - 813829015847
EANCode - 0813829015847
Eans - 813829015847
Environment requirements - - Working temperature: 0 to 40 degrees Celsius
- Storage temperature: -20 to 50 degrees C
- Operating / storage humidity: 0 - 90% (non-condensing)
Features - Audible alarm(s) - Yes
Features - Input frequency - 50/60 Hz
Features - Input operation voltage (max) - 280 V
Features - Input operation voltage (min) - 170 V
Features - Number of input phases - 1
Features - Number of output phases - 1
Features - Output frequency - 50/60 Hz
Features - Output power - 480 W
Features - Output power capacity - 0.8 kVA
Features - Output power factor - 0.6
Features - Power factor - 0.6
Features - Response time - 6 ms
Features - UPS topology - Line-Interactive
Features - Waveform - Stepwise
Filters / protection - Overdischarge
Filters / protection - Overload
GRUPPE1 - Power Protection
GRUPPE2 - UPS (Uninterruptable Power Supply)
GTIN - 0213889015847
GTIN - 213889015847
GTIN - 813829015847
GTIN - 0813829015847
guarantee - 24
guarantee_type - external
HERSTELLER - VERTIV
Hoehe - 0.15
HSTNUMMER - LI32121CT00
Input power ports - Type F Schuko
Laenge - 0.33
Logistics data - Harmonized System (HS) code - 85078000
LongDesc - The Vertiv Liebert itON uninterruptible power supply (UPS) is designed to offer power protection and extend the life of your desktop workstations and standalone IT devices. This 800VA UPS comes with Automatic Voltage Regulator (AVR), which allows flexibility and reliability for PCs and other sensitive electronic equipment. This single-phase line interactive UPS ensures availability of critical IT applications such as desktop computers and professional workstations. It is also suited for point-of-sale terminals, small routers, bridges and hubs, PBXs, and other sensitive electronics. This battery backup provides sufficient back up time, allowing work in progress to be saved safely before proceeding with the system shutdown. The Liebert itON UPS also comes complete with automatic restart and cold start functions for increased continuity and availability. It has compact design, light weight and easy to use controls.
LongProductName - Vertiv Liebert itON UPS 800VA/480W 230V Line Interactive Tower AVR, Lead Acid VRLA Battery, (2) Schuko (LI32121CT00)
LongSummaryDescription - Vertiv Liebert ItON 800VA. UPS topology: Line-Interactive, Output power capacity: 0.8 kVA, Output power: 480 W. AC outlet types: Type F, AC outlets quantity: 2 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery capacity: 9 Ah, Battery voltage: 12 V. Form factor: Tower, Product colour: Black, International Protection (IP) code: IP20. Width: 101 mm, Depth: 279 mm, Height: 142 mm
name - LIEBERT iTON 800VA E 230 iTON 800VA E 230
Name - Vertiv Liebert itON 800VA
No. of batteries - 1
Number of phases input - 1 (230V)
Operational conditions - Operating altitude - 0 - 1500 m
Operational conditions - Operating relative humidity (H-H) - 0 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 90%
Operational conditions - Storage temperature (T-T) - -20 - 50 °C
Other features - - Real power: 480W
- Input connector: Schuko plug (10A)
- Backup time at 50% load: 3 minutes
- Input voltage range in basic mode: 162-290V
- Variable input voltage range: 220-240V
Other features - Battery type - VRLA
Other features - Dimensions (WxDxH) - 101 x 279 x 142 mm
Other features - Input connection type - Schuko cord
Other features - Nominal input voltage - 230 V
Other features - Nominal output voltage - 230 V
Other features - Non-operating relative humidity (non-condensing) - 0 - 90%
Other features - Output connections - 2 x Schuko
Other features - Overload protection - Yes
Other features - Package dimensions (WxDxH) - 143 x 327 x 22 mm
Output power ports - 2 x C/F type (Schuko)
Ports & interfaces - AC outlets quantity - 2 AC outlet(s)
Ports & interfaces - AC outlet types - Type F
Ports & interfaces - Emergency Power Off (EPO) connector - No
Ports & interfaces - USB port - No
producer - Vertiv
Producer - Vertiv
ProducerCode - LI32121CT00
ProductName - Liebert ItON 800VA
ShortDescription -
ShortSummaryDescription - Vertiv Liebert ItON 800VA, Line-Interactive, 0.8 kVA, 480 W, Stepwise, 170 V, 280 V
Special functions - - Cold start
- Automatic Voltage Regulation (AVR)
- Sinus while working on battery
Diodes informing about:
- Charge the battery
- UPS overload
- Weak battery
- Overload
- Need to replace the battery
- Battery failure
Stck_Kart - 4
Stck_Pal - 0
Storno - N
Technical details - Compliance certificates - RoHS
Title - Vertiv Liebert ItON 800VA uninterruptible power supply (UPS) Line-Interactive 0.8 kVA 480 W 2 AC outlet(s)
UPS Architecture - line-interactive
URL - https://www.vertivco.com
vendpn - LI32121CT00
Voltage - 12 V
WarrantyInfo - 2-year
Weight - 4.9 kg
Weight & dimensions - Depth - 279 mm
Weight & dimensions - Height - 142 mm
Weight & dimensions - Package depth - 327 mm
Weight & dimensions - Package height - 220 mm
Weight & dimensions - Package weight - 5.4 kg
Weight & dimensions - Package width - 143 mm
Weight & dimensions - Weight - 4.9 kg
Weight & dimensions - Width - 101 mm
