Be Quiet Pure Power 11, 700W, 80PLUS Gold

Accessories included -
ARTIKEL1 - PURE POWER 11 700W
ARTIKEL2 - 80PLUS GOLD POWER SUPPLY
Brand - be quiet!
BrandPartCode - BN295
category - PC Components|Power Supplies|PSUs up to 800 Watts
Category - Power Supply Units
Category - Root/Electronics/PC parts/PC power supply units
Category 1 - Netzteile
Category_1 - Power
Category_2 - Computer Power Supplies
Certificates 80+ - 80 PLUS Gold
code - BN295
Description - Pure Power 11 700W offers unmatched reliability and the best features in its class. Regardless of whether you are creating a very silent system, building a multi-GPU set for gaming or upgrading an existing computer, you will gain the power supply due to its features and affordable price.
Design - Fan diameter - 12 cm
Design - Number of fans - 1 fan(s)
Design - Product colour - Black
dimensionalWeight - 1086
dimension depth - 100 mm
dimension height - 200 mm
Dimensions - 150 x 86 x 150 mm
dimension weight - 2457 g
dimension width - 260 mm
ean - 4260052186367
EAN - 4260052186367
EANCode - 4260052186367
Eans - 4260052186367
EAN_code - 4260052186367
Fan - 12 cm
Fan speed (max) - 1000 rpm
Floppy power connectors - 1
GRUPPE1 - Computer Systems
GRUPPE2 - Power Supplies
GTIN - 4260052186367
guarantee - 60
guarantee_type - normal
HERSTELLER - BE QUIET
HSTNUMMER - BN295
Logistics data - Harmonized System (HS) code - 84733020
Logistics data - Master (outer) case gross weight - 15.4 kg
Logistics data - Master (outer) case height - 241 mm
Logistics data - Master (outer) case length - 514 mm
Logistics data - Master (outer) case width - 326 mm
Logistics data - Products per master (outer) case - 6 pc(s)
LongDesc - Exceptionally Quiet, Superior Reliability, Great ValuePure Power 11 700W offers peerless dependability and best-in-class features. Whether you’re assembling a very quiet system, building a multi-GPU gaming system, or upgrading an existing PC, your build will benefit from this PSU that simply has the best combination of features at a very popular price.80 PLUS® GOLD CERTIFICATIONVery high operating efficiencyPure Power 11 700W is certified 80 PLUS Gold with an efficiency rating of up to 92% – a truly outstanding level for this class of PSU. The most compelling benefit: lower power consumption and consequently lower costs, and cooler, quieter operation.POWER AND COMPATIBILITY FOR YOUR SYSTEMThe best combination of features and performance at a very popular pricePure Power 11 offers 700W of continuous power with 2 independent 12V rails for signal stability and 4 PCI express connectors for multi-GPU systems. It is suited to very quiet systems, for upgrading or building multimedia or multi-GPU gaming systems.INNOVATIVE TECHNOLOGIESDC-to-DC, Active Clamp and Synchronous RectifierThe use of Active Clamp and Synchronous Rectifier technologies provides very stable operation. The PSU is equipped with DC-to-DC conversion for even tighter voltage regulation under heavy cross-loading conditions. This ensures secure operation for next generation processors and graphics cards.EXCEPTIONALLY SILENT OPERATIONAchieved by a silence-optimized 120mm be quiet! fanThe silence-optimized 120mm be quiet! fan is thermally governed to strike the best balance between effective cooling and quietness. Airflow-optimized fan blades reduce turbulence, enabling best-in-class quiet functionality and the almost inaudible operation that be quiet! is famous for.HIGH-QUALITY SLEEVED CABLESKeeping your system tidy and good-lookingPure Power 700W is equipped with high-quality sleeved cables that simplify component installation, increase airflow and improve cooling. The All-in-one cable has a convenient easy-plug HDD connector.
LongProductName - 700 W, ATX 2.4, 1x ATX 20+4-pin, 6x SATA, 3x PATA, FDD, 4x PCI-E 6+2-pin, 1x P4+4, 120mm fan, 25.9dB max.
LongSummaryDescription - be quiet! Pure Power 11 700W. Total power: 700 W, AC input voltage: 100 - 240 V, Peak power: 750 W. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 55 cm, SATA power cable length: 500,650,800 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Fan diameter: 12 cm, Number of fans: 1 fan(s). Width: 150 mm, Depth: 150 mm, Height: 86 mm
Manufacturer - Be quiet
Manufacturer - Be Quiet!
Manufacturer_code - BN295
MB power connector - 20 + 4 pin
MOLEX power connectors - 3
MPN - BN295
Name - 700W be quiet! PURE POWER 11 | 80+Gold
name - be quiet! Pure Power 11 80 PLUS Gold Netzteil - 700 Watt
Name - be quiet! Pure Power 11 700W
Name - be quiet! Pure Power 11 700W - 80Plus Gold
name - PSU Pure Power 11 700W 80+ GOLD N.MODU BN295
Number of power supply connector 4+4-pin 12V - 1
Number of power supply connectors PCI-E 6 +2 pin - 4
Other features -
Other features - Cable ties included - Yes
Other features - Noise level (full-load mode, 100%) - 25.9 dB
Other features - Noise level (quiet mode, 50%) - 12.2 dB
Other features - Noise level (silent mode, Other features - Screws included - Yes
Packaging data - Manual - Yes
Packaging data - Package depth - 240 mm
Packaging data - Package height - 96 mm
Packaging data - Package type - Box
Packaging data - Package weight - 2.39 kg
Packaging data - Package width - 210 mm
Performance - 80 PLUS certification - 80 PLUS Gold
Performance - ATX version - 2.4
Performance - Bearing technology - Rifle
Performance - Certification - ErP, WEEE
Performance - EPS version - 2.92
Performance - Power supply unit (PSU) form factor - ATX
Performance - Purpose - PC
Performance - Safety - CE, CB, TÜV, FCC, cTUVus, RCM, BSMI, CU, CCC
PFC - Active
Ports & interfaces - Cabling type - Non-Modular
Ports & interfaces - CPU power cable length - 60 cm
Ports & interfaces - CPU power connector (4+4 pin) - Yes
Ports & interfaces - Floppy disk drive connector - Yes
Ports & interfaces - Motherboard power cable length - 55 cm
Ports & interfaces - Motherboard power connector - 20+4 pin ATX
Ports & interfaces - Number of PATA power connectors - 3
Ports & interfaces - Number of SATA power connectors - 6
Ports & interfaces - PCI Express power cable length - 50 cm
Ports & interfaces - PCI Express power connectors (6+2 pin) - 4
Ports & interfaces - SATA power cable length - 500 mm
Ports & interfaces - SATA power cable length - 500,650,800 mm
Ports & interfaces - SATA power cable length - 650
Ports & interfaces - SATA power cable length - 800 mm
Power - AC input frequency - 50 - 60 Hz
Power - AC input voltage - 100 - 240 V
Power - Combined power (+3.3V) - 150 W
Power - Combined power (+5V) - 150 W
Power - Combined power (+5Vsb) - 15 W
Power - Combined power (+12V) - 672 W
Power - Combined power (-12V) - 3.6 W
Power - Efficiency - 92%
Power - Hold time - 25 ms
Power - Input current - 10 A
Power - Max output current (+3.3V) - 25 A
Power - Max output current (+5V) - 20 A
Power - Max output current (+5Vsb) - 3 A
Power - Max output current (+12V1) - 36 A
Power - Max output current (+12V2) - 30 A
Power - Max output current (-12V) - 0.3 A
Power - Peak power - 750 W
Power - Power factor - 0.99
Power - Power Factor Correction (PFC) type - Active
Power - Power protection features - Over current
Power - Power protection features - Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Power - Power protection features - Overheating
Power - Power protection features - Over power
Power - Power protection features - Over voltage
Power - Power protection features - Short circuit
Power - Power protection features - Under voltage
Power - Total power - 700 W
Power supply - 700 W
producer - Be quiet!
Producer - be quiet!
producerCode - BN295
ProducerCode - BN295
productName - be quiet! Pure Power 11 700W power supply unit 20+4 pin ATX ATX Black
ProductName - Pure Power 11 700W
productSize - Normal
SATA power connectors - 6
ShortDescription - 700 | ATX | 120 mm | 20 + 4 pin | 150mm x 86mm x 150mm | 80 PLUS Gold
ShortSummaryDescription - be quiet! Pure Power 11 700W, 700 W, 100 - 240 V, 750 W, 50 - 60 Hz, 10 A, Active
sizeX - 265
sizeY - 205
sizeZ - 100
Stck_Kart - 6
Stck_Pal - 12
Storno - Y
Technical details - Compliance certificates - RoHS
Technical details - Sustainability certificates - ENERGY STAR
Title - be quiet! Pure Power 11 700W power supply unit 20+4 pin ATX ATX Black
URL - https://www.bequiet.com/en/download/powersupply/1540?utm_source=newsletter
vendpn - BN295
WarrantyInfo - 5-year manufacturer’s warranty
warrantyLength - 36
warrantyType - G
Weight - 2,44
Weight - 2.46
weight - 2482
Weight & dimensions - Depth - 150 mm
Weight & dimensions - Height - 86 mm
Weight & dimensions - Weight - 2.11 kg
Weight & dimensions - Width - 150 mm
