300 mm x 300 mm VESA mounting interface - Yes
Accessories included - Remote control (2pcs battery included) Power cord QSG Instruction Connector for RS232C USB-C cable
Aspect ratio - 16:9
Audio - Built-in speaker(s) - Yes
Audio-Out Input/Output connectors - 1/1
Audio > Built-in speaker(s) - Yes
Auto Pivot - No
Bluetooth - No
Brand - LG
BrandPartCode - 49UH5N-E.AEU
Brightness - 500
Brightness - 700 nits
Category - Signage Displays
Category Code - LCD
Certificates - CB
Certificates - CE
Certificates - EMC
Certificates - ErP
Certificates - FCC Class A
Certificates - KC
Code - 49UH5N-E.AEU
Color - Black
Colour - Black/Black
Computer system - Computer system - Yes
Computer system - Computer system type - System on Chip (SoC)
Computer system - Internal memory - 16 GB
Computer system - Operating system installed - WebOS
Computer system - Operating system version - 6.0
Contrast - 1000000:1/1000000:1
Curved - 0 R
Data Sheet (Link) - https://eprel.ec.europa.eu/api/product/1583554/fiches?language=EN
Depth - 39.9 mm
Depth Unit Dimensions - 29.7 mm
Depth with stand - 290 mm
Description - 49UH5N-E Key Feature - Resolution : 3,840 x 2,160 (UHD) - Brightness (Typ.) : 500 nit - Surface Treatement (Haze) : 28 % - Bezel : 8.9 mm (T/R/L), 12.9 mm (B) - Interface : HDMI(3) / DP / USB 2.0 / RS232C / RJ45 / Audio / IR - webOS Smart Platform
Description - New UHD screen with a high degree of matte Standard Signage screen Appropriate screen brightness The UH5J-H series screen with a recommended brightness of 500 cd/m for indoor screens provides a clear image that attracts attention. It is the perfect choice for presenting marketing content in conference rooms, airports, stores, shopping malls, etc. High performance and webOS The LG webOS platform with an intuitive user interface and easy-to-use developer tools enables convenient work. Cover The UH5J-H series screens are intended for use in places where it is impossible to avoid exposure to dust, moisture, etc. factors that may cause the device's parameters to deteriorate over time. The conformal coating covering the power board of the UH5J-H screen reduces the risk of it being damaged by salt, dust, iron powder, moisture, etc. Mobile content management Using the Promota application, you can create a store profile and download recommended templates. The user can adapt the template to his needs and create and manage content not only on a computer but also on a mobile device. IP5x certified The IP5x tightness certificate guarantees that the product is protected against dust that may impair its performance. Compatibility with AV control system. The UH5J-H series devices support Crestron Connected technology, thanks to which they are highly compatible with professional audio-video devices, which allows for perfect integration and control automation and improves management.
Design - Bezel width (bottom) - 1.29 cm
Design - Bezel width (side) - 8.9 mm
Design - Bezel width (top) - 8.9 mm
Design - Orientation - Horizontal/Vertical
Design - Panel mounting interface - 300 x 300 mm
Design - Placement supported - Indoor
Design - Product colour - Black
Design - Product design - Digital signage flat panel
Design - VESA mounting - Yes
Design > Colour of product - Black
Design > VESA mounting - Yes
Design > VESA mounting interfaces - 300 × 300 mm
dimension depth - 1210 mm
dimension height - 750 mm
dimension weight - 16200 g
dimension width - 140 mm
Display - Colour depth - 10 bit
Display - Colour gamut - 95%
Display - Contrast ratio (dynamic) - 1000000:1
Display - Contrast ratio (typical) - 1100:1
Display - Display brightness - 500 cd/m²
Display - Display diagonal - 124.5 cm (49")
Display - Display number of colours - 1.07 billion colours
Display - Display resolution - 3840 x 2160 pixels
Display - Display technology - LCD
Display - Haze rate - 28%
Display - HD type - 4K Ultra HD
Display - LED backlight - Yes
Display - LED backlighting type - Edge-LED
Display - Native aspect ratio - 16:9
Display - Native refresh rate - 60 Hz
Display - Panel life - 50000 h
Display - Panel type - IPS
Display - Response time - 6 ms
Display - Touchscreen - No
Display - Viewing angle, horizontal - 178°
Display - Viewing angle, vertical - 178°
Display > Contrast ratio (typical) - 1100:1
Display > Display - 3840 x 2160 pixels
Display > Placement (L/P) - Landscape/Portrait
Display > Response time - 6 ms
Display > Viewing angle, horizontal - 178 °
Display > Viewing angle, vertical - 178 °
Displayable colours - 1070 million
Display surface - Matt
Dynamic contrast - 1 000 000:1
EAN - 8806084296412
ean - 8806084296412
Energy class - G
Energy consumption, standard - 87 kWh/1000h
Energy efficiency class - G
Energy label - Pobierz
EPREL Registration Number - 1.58355e+006
EPREL Version Number - 2
Full Description Line - 49"|Panel IPS|Resolution 3840x2160|Form factor 16:9|Refresh rate 60 Hz|Brightness 500|Contrast 1000000:1|Response time 6 ms|Horizontal 178 degrees|Vertical 178 degrees|Displayable colours 1070 million|3xHDMI|1xAudio-Out|1xRS232|1xUSB 2.0|1xRJ45|Tilt|PSU Inbuilt|300 mm x 300 mm|Operation time hours/day 24/7|Included Accessories Remote Controller(include battery 2ea), Power Cord, QSG, Regulation Book, Phone to RS232C Gender, Cable Holder(2EA), AC Cord Holder (1EA)|Colour Black
GTIN - 0195174062340
GTIN - 195174062340
GTIN - 8806084296412
guarantee - 24
guarantee_type - external
HDMI Input/Output connectors - 3/3
Height - 644.5 mm
Height adjustment - No
Height Unit Dimensions - 630.8 mm
Height with stand - 694.3 mm
I/O connectors - 1 x DVI-D
I/O connectors - 1 x RJ-45 LAN
I/O connectors - 1 x USB 2.0
I/O connectors - 2 x 3,5 mm minijack
I/O connectors - 2 x HDMI
I/O connectors - 2 x RS-232C (IR)
Included Accessories - Remote Controller(include battery 2ea), Power Cord, QSG, Regulation Book, Phone to RS232C Gender, Cable Holder(2EA), AC Cord Holder (1EA)/ Remote Controller(include battery 2ea), Power Cord, QSG, Regulation Book, Phone to RS232C Gender, Cable Holder(2EA), AC Cord Holder (1EA)
LongDesc - UHD Signage Display with LG webOS Platform and Advanced SecurityHigh Resolution DisplayIt offers a resolution that is four times higher than FHD, satisfying customers visually. Additionally, the anti-glare coating on the screen reduces screen reflection in bright lighting environments, increasing visibility and legibility, providing customers with a comfortable screen.Convenient webOS PlatformThe UH5N-E is equipped with a high-performance SoC that allows for multiple tasks to be performed without a separate media player. The webOS platform provides app development tools with an intuitive UI that enhances user convenience, enabling easy connection with external sensors and webOS partner apps to create an SI-friendly environment.Durability that Provides ReliabilityOptimized for business environments, the UH5N-E is protected against salt, dust, iron powder and humidity thanks to conformal coating on power board, allowing for stable operation. Also, its customer-centric features, such as IP5x, 30-degree tilting and Shock Monitoring, provide both reliability and satisfaction.Design for Space UtilizationDesigned with thin bezels and simple cable management, the UH5N-E saves space. With specialized hidden power inlets, it can be installed close to the wall, leaving only about 13 mm of space with the slim bracket. Bezels accessories can also be used to convert it into an art frame, making it a stylish interior element that matches customers' interior spaces.Enhanced Security FeaturesThe UH5N-E provides security features, including LG's Enhanced Kernel Protection (EKP) technology, protecting important data from external access or attacks. LG UHD Signage also holds reliable certification in the field of information security, maintaining customers' data and businesses securely. For example, this model is ISO/IEC 15408 Common Criteria EAL2 Certified.SustainabilityWith a commitment to innovation and sustainability, LG is continuously striving to create a better future for manufacturers, consumers, and future generations. With a focus on minimizing waste, maximizing recycling, and efficient power management, LG actively strives for sustainability, obtaining various certifications such as FCC EMC Class B.
LongProductName - 49", 4K UHD (3840 x 2160), IPS, 500 nit, 8 ms, IP5X, SoC, Wi-Fi, PIP, PBP, Pro:Idiom, Beacon, Control Manager, SuperSign CMS, webOS 6.0
LongSummaryDescription - LG 49UH5N-E. Product design: Digital signage flat panel. Display diagonal: 124.5 cm (49"), Display technology: LCD, Display resolution: 3840 x 2160 pixels, Display brightness: 500 cd/m², HD type: 4K Ultra HD. Wi-Fi. Operating hours (hours/days): 24/7. Operating system installed: WebOS. Product colour: Black
Matrix type - TFT IPS
Model - 49UH5N-E
Model - 49UH5N-E
name - 49UH5N-E IPS screen 500cd/m2 24/7
Name - LG | 49UH5N-E | 49 " | Landscape/Portrait | 24/7 | WebOS | 500 cd/m² | 6 ms | 178 ° | 178 °
Native resolution - 3840x2160/3840x2160
Number of colors - 1,07 mld
Operating temperature range - 0 °C to 40 °C
Operational conditions - Operating relative humidity (H-H) - 10 - 80%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operation time hours/day - 24/7
Optional accessory - Base (ST-653T) Wall bracket (LSW350B) OPS Set (KT-OPSF)
Other features -
Other features - Audio output - 1
Other features - Plug and Play - Yes
Other features - Power consumption (PowerSave) - 70 W
Other features > Signage product family - Digital Signage
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 1215.00 mm
Package features > Gross height (mm) - 152.00 mm
Package features > Gross width (mm) - 736.00 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 10 pc(s)
Package features > Paper/Pasteboard - 2000.00 g
Package features > Plastic (No PET) - 500.00 g
Package features > Tare weight (kg) - 2.50 kg
Package features > Volume (m3) - 0.14 m³
Package features > WEE classification - CL109:2:2017-04-01
Package features > WEEE tax - Yes
Packaging content - Batteries included - Yes
Packaging content - Cables included - AC, Phone
Packaging content - Remote control included - Yes
Packaging data - Package depth - 152 mm
Packaging data - Package height - 736 mm
Packaging data - Package weight - 16.1 kg
Packaging data - Package width - 1215 mm
Panel type - IPS
Performance - Automatic brightness control - Yes
Performance - HDCP - Yes
Performance - HDCP version - 1.4/2.2/2.3
Performance - International Protection (IP) code - IP5X
Performance - On Screen Display (OSD) - Yes
Performance - Operating hours (hours/days) - 24/7
Performance - Picture-in-Picture - Yes
Performance - Purpose - Universal
Ports & interfaces - DisplayPorts quantity - 1
Ports & interfaces - DVI port - No
Ports & interfaces - Ethernet LAN - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces - HDMI input ports quantity - 3
Ports & interfaces - HDMI output ports quantity - 1
Ports & interfaces - HDMI ports quantity - 4
Ports & interfaces - Remote (IR) input - 1
Ports & interfaces - RS-232C - Yes
Ports & interfaces - USB connector type - USB Type-A
Ports & interfaces - USB port - Yes
Ports & interfaces - USB ports quantity - 1
Ports & interfaces - USB version - 2.0
Ports & interfaces - Wi-Fi - Yes
Ports & interfaces > Device connectivity - Input: HDMI In (3, 3,840 × 2,160 @ 60Hz, HDCP 2.2/1.4), DP In (3,840 × 2,160 @ 60Hz, HDCP 2.2/1.3), RS-232C In (4 Pin Phone-jack), RJ45 (LAN) In, IR In, USB In 2.0 (Type A); Output: HDMI Out (3,840 × 2,160 @ 30Hz, Input (HDMI1/2/3/DP)), Audio Out, RS-232C Out (4 Pin Phone-jack), Daisy Chain (Input HDMI, DP / Output HDMI)
Power - AC input frequency - 50-60 Hz
Power - AC input voltage - 100-240 V
Power - Energy efficiency class (SDR) - G
Power - Power consumption (max) - 140 W
Power - Power consumption (standby) - 0.5 W
Power - Power consumption (typical) - 100 W
Power consumption - 87 kW
Power supply - Inbuilt/Inbuilt
producer - LG Electronics
Producer product name - 49UH5N-E
ProductName - 49UH5N-E
Refresh rate - 60 Hz
Refresh rate - 60 Hz
Resolution - 3840 x 2160
Response time - 6/6 ms
Response time - 8 ms
RJ45 Input/Output connectors - 1/1
RS232 Input/Output connectors - 1/1
Screen form factor - 16:9
Screen size - 49"
Screen size (diag.) - 49''
Shipping Box Depth Shipping/Package Box Dimensions - 121/121 cm
Shipping Box Height Shipping/Package Box Dimensions - 74/74 cm
Shipping box quantity - 1
Shipping Box Weight Shipping/Package Box Dimensions - 15.85/15.85 kg
Shipping Box Width Shipping/Package Box Dimensions - 15/15 cm
ShortSummaryDescription - LG 49UH5N-E, Digital signage flat panel, 124.5 cm (49"), LCD, 3840 x 2160 pixels, Wi-Fi, 24/7
Software > Operating system - WebOS
Speakers built-in - Yes
Standby consumption - 0.5 Watts
Static contrast - 1 000:1
Technical details - Real Time Clock (RTC) - Yes
Technical details > Bezel width - 8.9 mm (T/R/L), 12.9 mm (B) mm
Technical details > Brightness - 500 cd/m²
Technical details > Diagonal - 49 "
Technical details > Dimensions (WxDxH) - 1095.6 x 630.8 x 29.7 mm
Technical details > Gross weight - 16.10 kg
Technical details > Net weight - 13.60 kg
Technical details > Operating hours/days - 24/7
Technical details > Producer - LG
Tilt Stand - Yes/Yes
Title - LG 49UH5N-E Digital signage flat panel 124.5 cm (49") LCD Wi-Fi 500 cd/m² 4K Ultra HD Black WebOS 24/7
Touchscreen - No
Touch screen - No
Transreflective technology - LED
TV tuner built-in - No
Unit Box Height - 0.74
Unit Box Length - 1.21
Unit Box Width - 0.15
Unit Brutto Volume - 0.1343/0.1343 cubm
Unit Gross Weight - 15.8/15.8 kg
Unit Net Weight - 13.6/13.6 kg
URL - https://www.lg-informationdisplay.com/product/digital-signage/standard/65UH5N-E
USB 2.0 Input/Output connectors - 1/1
Vendor Homepage - www.lg-informationdisplay.com/product/digital-signage/standard/49UH5N-E
vendpn - 49UH5N-E
VESA - 300 x 300
Viewing angle, horizontal - 178 °
Viewing angle, vertical - 178 °
Viewing angle horizontal - 178/178 degrees
Viewing angle vertical - 178/178 degrees
Warranty -
Warranty - 36
Warranty - 36 month(s)
Warranty - 36 months
WarrantyInfo -
Web camera - None
Weight - 15.4 kg
Weight & dimensions - Display depth - 29.7 mm
Weight & dimensions - Display height - 630.8 mm
Weight & dimensions - Display weight - 13.6 kg
Weight & dimensions - Display width - 1095.6 mm
Weight with stand - 16 kg
Width - 1098.6 mm
Width Unit Dimensions - 1095.6 mm
WiFi - Yes
DVI is a digital standard and ensures high image quality, however, thanks to the big size of the plug and the inability of the standard to develop further due to a few technical restrictions this type of connection is gradually losing its popularity to modern HDMI and DisplayPort standards.
