TP-LINK Omada SG2428LP

10/100/1000/2500 Mbps ports - None
10Base-T / 100Base-TX / 1000Base-T Ports - 24
Accessories included -
Application - Medium and large companies
ARTIKEL1 - OMADA 28-PORT 1G SMART SWITCH
ARTIKEL2 - WITH 16-PORT POE+
Brand - TP-Link
BrandPartCode - SG2428LP
Breite - 0
Category - Network Switches
Category 1 - Netzwerk
Category 2 - Switching Hubs
Category Code - SWI
Certificates - CE, FCC
Chassis type - Rack
CnCode CnCode - 85176200
Console port - No
Data transmission - Forwarding rate - 41.66 Mpps
Data transmission - Jumbo frames - 9000
Data transmission - Jumbo frames support - Yes
Data transmission - MAC address table - 8000 entries
Data transmission - Packet buffer memory - 4.1 MB
Data transmission - Switching capacity - 56 Gbit/s
Description - 16× portów Gigabit 802.3af/at PoE+ 8× portów Gigabit RJ45 bez PoE i 4× gniazd SFP Gigabit Łączny budżet PoE wynosi 150 W, z możliwością dostarczenia do 30 W PoE na port Scentralizowane zarządzanie w chmurze za pośrednictwem strony internetowej lub aplikacji Omada Zarządzanie samodzielnym urządzeniem za pomocą strony internetowej, interfejsu wiersza poleceń (CLI), SNMP i RMON Statyczne trasowanie pomaga kierować ruchem wewnętrznym dla większej efektywności VLAN, ACL, QoS oraz przeszukiwanie IGMP Projekt bezwentylatorowy dla cichej pracy Wytrzymała metalowa obudowa i projekt do montażu w szafie rackowej
Description - Omada 28-Port Gigabit Smart Switch with 16-Port PoE+ 16× Gigabit 802.3af/at PoE+ ports 8× Gigabit non-PoE RJ45 ports and 4× Gigabit SFP slots 150 W total PoE budget with up to 30 W PoE output per port* Centralized cloud management via the web or the Omada app† Standalone management via web, CLI, SNMP, and RMON Static Routing helps route internal traffic for higher efficiency VLAN, ACL, QoS, and IGMP Snooping Fanless design for quiet operation Durable metal casing and rackmountable design
Design - LED indicators - Yes
Design - Product colour - Grey
Design - Rack mounting - Yes
Desktop/pedestal Mounting Type - Yes
dimension depth - 100 mm
dimension height - 530 mm
Dimensions - 440 × 220 × 44 mm
Dimensions - 440×220×44 mm
dimension weight - 4010 g
dimension width - 335 mm
ean - 8885020620832
EAN - 8885020620832
EANCode - 8885020620832
Environment requirements - Temperatura pracy: 040 stopni Celsjusza Temperatura przechowywania: -4070 stopni Celsjusza Wilgotność robocza: 1090% RH, bez kondensacji Wilgotność przechowywania: 590% RH, bez kondensacji
Fan - No
Forwarding rate - 41.66 Mpps
Forwarding rate - 41.66 Mpps
Full Description Line - Series Omada|Desktop/pedestal|Rack|24x10Base-T / 100Base-TX / 1000Base-T|4xSFP|PoE ports 8|PoE+ ports 16|PoE power budget 150 Watts|Switching capacity 56 Gbps|Forwarding rate 41.66 Mpps|Dimensions 440×220×44 mm|Unit Net Weight 3.7 kg
Gewicht - 4.02
Gross Weight Kg - 4
GRUPPE1 - Network
GRUPPE2 - Lan Switch Unmanaged
GTIN - 8885020620832
GTIN - 8885020620849
guarantee - 60
guarantee_type - normal
HERSTELLER - TP-LINK
Hoehe - 0
HSTNUMMER - SG2428LP
Jumbo frame size - 9 KB
L2 features - 511 IPv4, IPv6 shared multicast groups IGMP Snooping Multicast VLAN Registration (MVR) Multicast Filtering Limited IP Multicast (256 profiles and 16 entries per profile)
L3 features -
Laenge - 0
LongDesc - - 24× Gigabit Ports (16× PoE+), 4× Gigabit SFP Slots- 150 W Total PoE Budget- Fanless Design for Silent Operation- Zero-Touch Provisioning- Centralized Management- Omada App- Static Routing- Traffic SeparationSoftware Defined Networking (SDN) with Cloud AccessRemotely manage your access points, switches, and gateways across multiple sites all from a single interface.Multiple Application ScenariosSurveillanceWorks with IP Cameras Conference CallWorks with IP Phones Wi-Fi CoverageWorks with Access Points Wired ConnectionsWorks with Non-PoE Devices such as PCs and Printers
LongProductName - 16× 10/100/1000 Mbps PoE+ RJ45, 8× 10/100/1000 Mbps RJ45, 4× Gigabit SFP Slots, 56 Gbps, 41.66 Mpps, 440 x 220 x 44 mm
LongSummaryDescription - TP-Link Omada 28-Port Gigabit Smart Switch with 16-Port PoE+. Switch type: Managed, Switch layer: L2/L2+. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24. MAC address table: 8000 entries, Switching capacity: 56 Gbit/s. Networking standards: IEEE 802.3af, IEEE 802.3at. Power over Ethernet (PoE). Rack mounting
MAC address table size - 8000
Management, monitoring, configuration -
Management features - ARP inspection - Yes
Management features - Cloud-managed - Yes
Management features - Quality of Service (QoS) support - Yes
Management features - Switch layer - L2/L2+
Management features - Switch type - Managed
Management features - Web-based management - Yes
Manufacturer - TP-Link
Manufacturer Code - SG2428LP
Manufacturer Name - TP-LINK
Model name - SG2428LP
MPN - SG2428LP
Multicast features - Multicast support - Yes
Name - 24+4P TP-Link Omada SG2428LP M RM POE+
name - Switch SG2428LP 16xGE PoE+ 8xGE 4xSFP
Network - 10G support - No
Network - Auto-negotiation - Yes
Network - Flow control support - Yes
Network - Link aggregation - Yes
Network - Networking standards - IEEE 802.3af, IEEE 802.3at
Network - Number of VLANs - 4000
Network - Spanning tree protocol - Yes
Network - Virtual LAN features - MAC address-based VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN
Network - VLAN support - Yes
Network architecture - GigabitEthernet
Number of 10/100 Mbps ports - None
Number of 10/100/1000 Mbps ports - 8
Number of 10Gb ports - None
Number of COMBO ports - None
Number of PoE+ ports - 16
Number of QSFP+ ports - None
Number of SFP+ ports - None
Number of SFP56 ports - None
Number of SFP ports - 4
Operational conditions - Heat dissipation - 628 BTU/h
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Other features -
Other functions -
Performance - Fanless - Yes
PoE+ ports - 16
PoE ports - 8
PoE power budget - 150 Watts
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 24
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Gigabit Ethernet (10/100/1000)
Ports & interfaces - SFP module slots quantity - 4
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 100 - 240 V
Power - Power consumption (max) - 184.7 W
Power - Power source - AC/PoE
Power consumption - 184.7 W
Power over Ethernet (PoE) - Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) power per port - 30 W
Power over Ethernet (PoE) - Power over Ethernet plus (PoE+) ports quantity - 16
Power over Ethernet (PoE) - Total Power over Ethernet (PoE) budget - 150 W
Power supply - 100-240V AC, 50/60Hz
Power supply - External
Primary port count - 24
producer - TP-LINK
ProductName - Omada 28-Port Gigabit Smart Switch with 16-Port PoE+
QoS - 802.1p CoS/DSCP priority 8 priority queues Priority Schedule Mode: SP (Strict Priority), WRR (Weighted Round Robin) Queue Weight Config Bandwidth Control: Port/Flow-based Rating Limit Smoother Performance Storm Control: Multiple Control Modes(kbps/ratio), Broadcast/Multicast/Unknown-Unicast Control
Rack Mounting Type - Yes
Security - Secure web management through HTTPS with SSLv3/TLS 1.2 Secure Command Line Interface (CLI) management with SSHv1/SSHv2 IP/Port/MAC-based access control
Security - Access Control List (ACL) - Yes
Security - DHCP features - DHCP relay, DHCP server
Security - IGMP snooping - Yes
Security - MAC address filtering - Yes
Security - Password protection - Yes
Series - Omada
SFP Ports - 4
Shipping Box Depth Shipping/Package Box Dimensions - 55.5 cm
Shipping Box Height Shipping/Package Box Dimensions - 43 cm
Shipping box quantity - 4
Shipping Box Weight Shipping/Package Box Dimensions - 17.4 kg
Shipping Box Width Shipping/Package Box Dimensions - 36.5 cm
Short description - TP-LINK Switch SG2428LP Omada 28-Port Gigabit Smart Switch with 16-Port PoE+
ShortSummaryDescription - TP-Link Omada 28-Port Gigabit Smart Switch with 16-Port PoE+, Managed, L2/L2+, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting
Stackability - Yes
Stck_Kart - 1
Stck_Pal - 7
Storno - Y
Supported protocols and standards -
Support for Jumbo frames - Yes
Switch class - SMART
Switching capacity - 56 Gbps
Switch layer - L2
Switch layer - L2+
Throughput - 56 Gb/s
Title - TP-Link Omada 28-Port Gigabit Smart Switch with 16-Port PoE+
Unit Box Height - 0.1
Unit Box Length - 0.535
Unit Box Width - 0.34
Unit Brutto Volume - 0.02178 cubm
Unit Gross Weight - 4.35 kg
Unit Net Weight - 3.7 kg
URL - https://www.tp-link.com/au/business-networking/omada-switch-smart/sg2428lp/#highlights
Vendor Homepage - www.tp-link.com/au/business-networking/omada-switch-smart/sg2428lp/
vendpn - SG2428LP
VLAN - VLAN Group: Max. 4K VLAN Groups 802.1Q tag VLAN MAC VLAN: 12 Entries Protocol VLAN GVRP Voice VLAN
Warranty - 24 months
WarrantyInfo - 5 Years
Weight - 4
Weight & dimensions - Depth - 220 mm
Weight & dimensions - Height - 44 mm
Weight & dimensions - Width - 440 mm
