Lenovo THINKSYSTEM M.2 5400 PRO 480GB READ INTENSIVE SATA 6GB NHS SSD

Name: Lenovo THINKSYSTEM M.2 5400 PRO 480GB READ INTENSIVE SATA 6GB NHS SSD
Brand: Lenovo
SKU: 954181
Price: 943.87 EUR
Availability: InStock

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.

ID: 954181 Product code: 4XB7A82287

Can be ordered 4 units Availability: 14 days after order approval

Warranty: 2 years (Warranty for business entities 1 year)

Compare

Delivery options More about shipping

Delivery to Smartpost free of charge: 08.01.2025
Delivery to Omniva parcel machine free of charge: 08.01.2025
Piegāde uz DPD Pickup Paku Skapi free of charge: 08.01.2025
Delivery to Latvian post office, parcel locker or Circle K free of charge: 08.01.2025
Delivery to address in Riga 3.99 €: 08.01.2025
Delivery to address in Latvia 6.99 €: 08.01.2025
Delivery to Dateks.lv parcel drop-off point at 9 Zemitāna Street: 06.01.2025 after 15:00

Main product parameters All parameters

Capacity: 480 GB
Type: SATA
Interface: SATA III (6Gb/s)

Basic information

Capacity 480 GB

The HDD capacity in Gigabytes indicates how much information can be stored by the HDD. The capacity of the HDD is fixed and cannot be increased after buying the HDD. Therefore, upon buying the HDD you should verify its compliance with your current volume requirements and provides a reserve for future needs.

Type : SATA

Ports and equipment

Interface : SATA III (6Gb/s)

Interface SATA

SSDs with SATAII and SATAIII connection are compatible with the connections of both types in the motherboard. Still, it has to be taken into account that the motherboard SATAII connection can provide maximum about 300 MB/s transmission capacity which can reduce the actual transmission capacity of the SSDs whose reading and/or writing speed exceeds this level to the capacity limits of the SATAII.

The situation is similar with the PCI-Express and SATAIII connection slots. Although the SATAIII standard can provide up to 600 MB/s data transmission capacity there are SSDs with the speed exceeding this limit, in this case the manufacturer chooses the PCI-Express connection slot with a higher transmission capacity. The PCI-Express discs cannot be connected to the portable computer.

More detailed specification

ARTIKEL1 - THINKSYSTEM M.2 5400 PRO 480GB
ARTIKEL2 - READ INTENSIVE SATA 6GB NHS SSD
Brand - Lenovo
BrandPartCode - 4XB7A82287
Breite - 0.14
Category - Internal Solid State Drives
EANCode - 0889488633784
Features - Certification - Micron Green Standard
Built with sulfur resistant resistors
CE (Europe): EN 55032 Class B, RoHS
UKCA (UK): SI 2016/1091 Class B and SI 2012/3032 RoHS
FCC: CFR Title 47, Part 15 Class B
UL/cUL: approval to UL-60950-1, 2nd Edition, IEC 60950-1:2005 (2nd Edition); EN 60950-1 (2006) + A11:2009+ A1:2010 + A12:2011 + A2:2013
BSMI (Taiwan): approval to CNS 13438 Class B and CNS 15663
RCM (Australia, New Zealand): AS/NZS CISPR32 Class B
KC RRA (Korea): approval to KN32 Class B, KN 35 Class B
W.E.E.E.: compliance with EU WEEE directive 2012/19/EC
TUV (Germany): approval to IEC60950/EN60950
VCCI (Japan): 2015-04 Class B
IC (Canada): ICES-003 Class B
Morocco: approval to EN55032/EN55024 Class B
UkrSEPRO (Ukraine): EN55032 Class B, IEC60950/EN60950, RoHS (Resolution 2017 No. 139)
Features - Component for - Server/workstation
Features - Hot-swap - Yes
Features - Interface - Serial ATA III
Features - Mean time between failures (MTBF) - 3000000 h
Features - Memory type - 3D TLC NAND
Features - Random read (4KB) - 95000 IOPS
Features - Random write (4KB) - 37000 IOPS
Features - Read latency - 170 µs
Features - S.M.A.R.T. support - Yes
Features - SSD capacity - 480 GB
Features - SSD form factor - M.2
Features - Write latency - 42 µs
Gewicht - 0.05
GRUPPE1 - Hard Drive/Optical
GRUPPE2 - Solid State Drive
GTIN - 0889488633784
GTIN - 889488633784
HERSTELLER - LENOVO
Hoehe - 0.02
HSTNUMMER - 4XB7A82287
Laenge - 0.22
LongDesc - The ThinkSystem 5400 PRO Read Intensive SATA 6Gb SSDs are general-purpose self-encrypting SSDs (SEDs) based on the Micron 5400 PRO platform and are available in capacities ranging from 240GB to 7.86TB. They are engineered for greater performance and endurance in a cost-effective design, and to support a broader set of workloads.This product guide provides essential presales information to understand the 5400 PRO SSDs, their key features and specifications, components and options, and configuration guidelines. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the 5400 PRO SSDs and consider their use in IT solutions.
LongProductName - ThinkSystem M.2 5400 PRO 480GB Read Intensive SATA 6Gb NHS
LongSummaryDescription - Lenovo 4XB7A82287. SSD capacity: 480 GB, SSD form factor: M.2, Component for: Server/workstation
Operational conditions - Non-operating shock - 1500 G
Operational conditions - Operating relative humidity (H-H) - 5 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 70 °C
Operational conditions - Storage temperature (T-T) - -40 - 85 °C
Other features - Compatible products - ThinkSystem
Power - Power consumption (read) - 2.5 W
Power - Power consumption (write) - 3.1 W
ProductName - 4XB7A82287
ShortSummaryDescription - Lenovo 4XB7A82287, 480 GB, M.2
Stck_Kart - 9998
Stck_Pal - 0
Storno - Y
Title - Lenovo 4XB7A82287 internal solid state drive 480 GB M.2 Serial ATA III 3D TLC NAND
URL - https://lenovopress.lenovo.com/lp1634-thinksystem-5400-pro-read-intensive-sata-6gb-ssds
WarrantyInfo -
Weight & dimensions - Depth - 80 mm
Weight & dimensions - Height - 3.9 mm
Weight & dimensions - Width - 22 mm
