Lexar NM710, 2TB, M.2 Gen4 x4

Name: Lexar NM710, 2TB, M.2 Gen4 x4
Brand: Lexar
SKU: 933076
Price: 173.36 EUR
Availability: InStock

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.

ID: 933076 Product code: LNM710X002T-RNNNG

Can be ordered 4 units Availability: 14 days after order approval

Warranty: 3 years

Compare

Delivery options More about shipping

Delivery to Smartpost free of charge: 11.12.2024
Delivery to Omniva parcel machine free of charge: 11.12.2024
Piegāde uz DPD Pickup Paku Skapi free of charge: 11.12.2024
Delivery to Latvian post office, parcel locker or Circle K free of charge: 11.12.2024
Delivery to address in Riga 3.99 €: 11.12.2024
Delivery to address in Latvia 6.99 €: 11.12.2024
Delivery to Dateks.lv parcel drop-off point at 9 Zemitāna Street: 09.12.2024 after 15:00

Main product parameters All parameters

Capacity: 2 TB
Type: NVMe
Read speed (sequential): 4850 MB/s
Write speed (sequential): 4500 MB/s
Form factor: M.2 80mm (2280)
Interface: PCIe 4.0 x4

Description

Available for purchase, the Lexar M.2 80mm (2280) format SSD disk with a large volume of 2 TB.

This disc uses the latest generation compact M.2 port.

This is a fast-acting NVME SSD drive, based on PCIe technology. It allows data to be transmitted in parallel over multiple channels, ensuring excellent performance. This type of drive is perfectly suited for activities such as processing large files, gaming, and video editing, where maximum data transmission speed is required.

This SSD disk read speed (Sequential read speed) is 4850 MB/s. Keep in mind that "fast" disks without a proper cooling solution may not reach the speeds indicated by the manufacturer.

4500 MB/s - this SSD drive is capable of achieving such data writing speed. The speed parameters promised by the manufacturer may not be reached if the "fast" disk is not provided with an appropriate cooling system.

This is an SSD disk in the M.2 80mm (2280) format.

The SSD drive has a PCIe 4.0 x4 interface. If it is inserted into an older interface slot, the potential speed of the drive will not be fully utilized, as the older interface will not provide sufficient data transfer bandwidth.

Basic information

Capacity 2 TB

The HDD capacity in Gigabytes indicates how much information can be stored by the HDD. The capacity of the HDD is fixed and cannot be increased after buying the HDD. Therefore, upon buying the HDD you should verify its compliance with your current volume requirements and provides a reserve for future needs.

Type : NVMe

Read speed (sequential) 4850 MB/s

Sequential read speed or the mean data reading speed is the most important criterion of the high-speed operation of the SSD. The data from the SSD will be read much more often than written to it because the operating system stores the processed data in the RAM in most cases.

If you want the reading speed of the purchased SSD to exceed the speed of the classic HDD considerably you should choose the SSD with the reading speed of 200 MB/s or above. The additional increase in the performance will be achieved on the account of the data search (SeekTime) which is of much higher level with SSDs than any HDD.

Write speed (sequential) 4500 MB/s

The writing speed is almost as important as the reading speed. Also this parameter determines the performance of the SSD, however, as the writing to the disc happens not as often as the data reading and average user will find it subjectively difficult to distinguish between any speed above 100 MB/s and higher indices, except the cases when the SSD is used in a server, for audio/video recording, etc.

Functionality

Radiators : Nav

Lighting : Nav

Ports and equipment

Form factor M.2 80mm (2280)

Thanks to the small size provided by the SSD technology the standard size of the discs is 2.5", and it is suitable for an average portable computer. It is possible to install the 2.5" disc in the desktop computer if the transition 2.5" -> 3.5" is used, and this transition can be bought at a low cost at Dateks.lv section"Adapteri". The discs with the format 2.5" + 3.5" have this transition included.

1.8" discs are intended for the ultra-compact class portable computers.

PCI-Express SSDs are intended for desktop computers with a free PCI-Express plug available. This technology in most cases is used for ensuring the performance that exceeds the possibilities of other types of connections.

Interface : PCIe 4.0 x4

Interface M.2

SSDs with SATAII and SATAIII connection are compatible with the connections of both types in the motherboard. Still, it has to be taken into account that the motherboard SATAII connection can provide maximum about 300 MB/s transmission capacity which can reduce the actual transmission capacity of the SSDs whose reading and/or writing speed exceeds this level to the capacity limits of the SATAII.

The situation is similar with the PCI-Express and SATAIII connection slots. Although the SATAIII standard can provide up to 600 MB/s data transmission capacity there are SSDs with the speed exceeding this limit, in this case the manufacturer chooses the PCI-Express connection slot with a higher transmission capacity. The PCI-Express discs cannot be connected to the portable computer.

Specifikācija

Memory type : TLC (Triple-Level Cell)

Random Read IOPS : Not indicated

Random Write IOPS : Not indicated

Endurance (TBW) : 1200 TB

More detailed specification

Box Weight Brutto (kg) - 0.61 kg
Category - Root/Electronics/PC parts/Hard drives
Category 1 - SSDs
Category 2 - Interne SSDs
Category Code - SSU
Category_1 - Hard Drives and Pendrives
Category_2 - Internal SSD - M.2
Code - LNM710X002T-RNNNG
Color - Not applicable
Combined (other) - 0.7000 g
Depth - 80 mm
Description -
Description - Lexar® NM710 M.2 2280 PCIe Gen4x4 NVMe SSD
Design > SSD form factor - M.2 2280
Device Location - Plug-in Module
dimension depth - 10 mm
dimension height - 160 mm
Dimensions - 80 x 22 x 2.45 mm
dimension weight - 72 g
dimension width - 100 mm
Disk type - SSD
Drive thickness - 2.45mm
Drive type - Internal
EAN - 843367129713
ean - 843367129713
EAN - 0843367129713
EAN Code - 843367129713
Eans - 843367129713
EAN_code - 0843367129713
Form Factor - M.2
Form Factor - M.2 22x80mm
Form factor (width) - M.2 2280
Full Description Line - SSD series NM710|2TB|Form Factor M.2|PCIe Gen4|NVMe|Write speed 4500 MBytes/sec|Read speed 4850 MBytes/sec|Drive thickness 2.45mm|TBW 1200 TB|MTBF 1500000 hours
guarantee - 60
guarantee_type - normal
HDD capacity - 2 TB
HDD interface - PCI-Express
Height - 2.45 mm
Image - https://content.it4profit.com/pimg/s/resize/750x750x750x750/230125170012748169.jpg
Included Accessories - Īsa lietotāja rokasgrāmata
Manufacturer - Lexar
Manufacturer - Lexar Media
Manufacturer_code - LNM710X002T-RNNNG
Maximum Sequential Read Rate - 4850 MB/s
Maximum Sequential Write Rate - 4500 MB/s
Memory Technology - 3D NAND
Model - LNM710X002T-RNNNG
Model - NM710
MPN - LNM710X002T-RNNNG
MTBF - 1.5e+006 hours
Name - Lexar NM710 2TB, SSD (PCIe 4.0 x4, NVMe 1.4, M.2 2280)
Name - Lexar NM710 Pci-e NVMe 2TB
Name - Lexar | M.2 NVMe SSD | NM710 | 2000 GB | SSD form factor M.2 2280 | Solid-state drive interface PCIe Gen4x4 | Read speed 4850 MB/s | Write speed 4500 MB/s
Name - M.2 2TB Lexar NM710 High Speed NVMe PCIe4.0 x 4
name - SSD drive NM710 2TB NVMe M.2 2280 4850/4500MB/s
NVMe - Yes
Other features -
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 88 mm
Package features > Gross height (mm) - 10 mm
Package features > Gross width (mm) - 22 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 500 pc(s)
Package features > Paper/Pasteboard - 20.00 g
Package features > PET - 1.7 g
Package features > Plastic (No PET) - 10.00 g
Package features > Tare weight (kg) - 0.03 kg
Package features > Volume (m3) - 0.00001936 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - No
Package Type - Retail
Packs in Box - 10
Pack Weight Brutto (kg) - 0.05 kg
PCIe Gen4 Interface - Yes
PDF - https://www.blobs.lt/products/2/7/2/9/8/3/64e2bc0bfdcb12d33d102dbe93c569f0/original.pdf
Performance > Read speed - 4850 MB/s
Performance > Solid-state drive capacity - 2000 GB
Performance > Solid-state drive interface - PCIe Gen4x4
Performance > Write speed - 4500 MB/s
Pieces in pack - 1
producer - Lexar
Producer - Lexar
ProducerCode - LNM710X002T-RNNNG
Producer product family - M.2 NVMe SSD
Producer product name - NM710
ProductCard - https://content.it4profit.com/itshop/itemcard_cs.jsp?ITEM=230118132621193576&THEME=asbis&LANG=lv
ProductCategory - SSD
ProductCode - LNM710X002T-RNNNG
ProductDescription - Lexar® 2TB High Speed PCIe Gen 4X4 M.2 NVMe, up to 4850 MB/s read and 4500 MB/s write, EAN: 843367129713
ProductType - SSD Client
Reading speed - 4850 MB/s
Read speed - 4850 MBytes/sec
Shipping Box Depth Shipping/Package Box Dimensions - 16.5 cm
Shipping Box Height Shipping/Package Box Dimensions - 1.5 cm
Shipping box quantity - 1
Shipping Box Weight Shipping/Package Box Dimensions - 0.05 kg
Shipping Box Width Shipping/Package Box Dimensions - 11 cm
ShortDescription - m2 | SSD | 2TB | 4850/4500 MB/s | PCI-e|NVME | TBW
Solid State Drive Features - NVMe Support
SSD Capacity - 2TB
SSD series - NM710
Storage Capacity - 2 TB
Supports Data Channel - PCIe NVMe 4.0 x4
TBW - 1200 TB
TBW - 1200 TB
Technical details > Gross weight - 0.08 kg
Technical details > Net weight - 0.05 kg
Technical details > Producer - Lexar
Technical details > Warranty - 36 month(s)
Unit Box Height - 0.015
Unit Box Length - 0.165
Unit Box Width - 0.11
Unit Brutto Volume - 0.0002722 cubm
Unit Gross Weight - 0.05 kg
Unit Net Weight - 0.007 kg
Vendor - LEXAR
Vendor Homepage - www.lexar.com/en/product/lexar-nm710-m-2-2280-pcie-gen4x4-nvme-ssd/
vendpn - LNM710X002T-RNNNG
Warranty - 36
Warranty - 60 months
Warranty Products Returnable - Yes
Warranty Term (month) - 60 mēneši
Warranty validation Criteria - Serial Number
Weight - 0,05
Weight - 0.04
Weight - 7 g
Width - 22 mm
Write speed - 4500 MBytes/sec
Writing speed - 4500 MB/s
